Specifications
20m Dongfeng Telescoic Boom Hydraulic Aerial Cagesingle row
euro 2 emission stanard
engine power 120hp
7.50-16 tire
20m Dongfeng Telescoic Boom Hydraulic Aerial Cage
this hydraulic aerial cage is telescopic boom type , with a max working height 20m , is consisted of DongFeng second type chassis , 3 section of booms , hydraulic part , and a bucket at the end , which rated load 200kg. this overhead working truck can be operated by workers , also can be operated by remote-control.
one of the most professional truck mounted aerial platform manufacturer in China , our aerial platform truck have a wide range optional , the quality have been approved by CCC, ISO9001:2008 .
Vehicle name |
20m Dongfeng Telescoic Boom Hydraulic Aerial Cage |
||
Cabin |
Crew cab , 5 seats , luxury cabin |
||
Drive type |
4x2 , left hand drive |
||
Wheel base |
3800mm |
||
Overall dimension (L*W*H) |
8100x2320x3350 mm |
||
Weight |
GVW |
7490 kg |
|
Curb weight |
7295 kg |
||
Engine |
Engine model |
CY4102-CE4B |
|
Make |
DongFeng Chaoyang Diesel Engine Co., Ltd |
||
Rated power / Displacement |
100 kw /3856 ml |
||
Emission standard |
Euro 4 |
||
Tire type |
7.50-16, 6 PCS |
||
Max working height |
20m |
||
Max working radius |
11.5 m |
||
Boom type |
telescopic boom , 3 section of boom |
||
Bucket rated load |
200 kg |
||
Operation |
manual or electricl or remote control |
||
Our factory main products:
fire truck, aerial work platform truck, refrigerated truck, truck mounted crane, garbage truck, vacuum sewage suction truck, fecal sucking truck, fuel tanker truck, water tanker truck, road sweeper, semi-trailer, tractor, concrete mixer truck, road wrecker/ tow truck / recovery truck , van truck , cargo truck
