Netis Wireless Outdoor Access Point Router
Negotiable
MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
netis
Model Number:
WF2322
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Netis Long Range Wireless Outdoor Access Point WF2301NegotiableMOQ: 1000 Pieces -
Netis Wireless AC1200 Dual Band Gigabyte Gaming Router WF2681NegotiableMOQ: 1000 Pieces
-
Netis Long Range Wireless N Router for GamingNegotiableMOQ: 1000 Pieces
-
Netis Wireless Gaming Router WF2631NegotiableMOQ: 1000 Pieces
-
Netis 300Mbps Wireless N High Power Outdoor AP RouterNegotiableMOQ: 1000 Pieces
Place of Origin
Guangdong, China
Brand Name
netis
Model Number
WF2322
netis Wireless Outdoor Access Point Router
Product Description
The netis 300Mbps Wireless N High Power Outdoor AP Router WF2322 provides long range, high performance wireless Internet access over long distance. The maximum 1000mW transmit power enables you long range connectivity. Also, with 15kV ESD protection and IP55 Waterproof for case, WF2322 is suitable for harsh environment, providing users a stable and smooth networks connection.
Features
- Comply with 802. 11b/g/n standard, data rate up to 300Mbps
- Maximum 1000mW Transmit Power enabling long range connectivity
- Internal High gain 10dBi directional antenna, dual-polarity
- IP55 Waterproof for case
- Various WAN connection types- DHCP, PPPoE, Static IP, Russia PPPoE, Unifi PPPoE,L2TP/Russia L2TP, PPTP/Russia PPTP, WISP
- Multiple wireless modes- AP, Router, WISP, AP + Client,AP + Repeater, WISP + Client, WISP + Repeater
- ESD protection up to 15KV
- Remote reset from power adapter
Specification
| netis Wireless Outdoor Access Point Router | |
| Wireless | |
| Standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Signal Rate | Up to 300Mbps |
| Frequency Range | 2.4-2.4835GHz |
| Transmit Power | 30dBm(Maximum) |
| Receive Sensitivity | -99dBm(Maximum) |
| Data Transfer Rates |
802.11n: 40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps) 20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) 801.11g: (54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps, 6Mbps) 802.11b: (11Mbps, 5.5Mbps, 2Mbps, 1Mbps) |
| Wireless Modes | AP, Router, WISP, AP + Client, AP + Repeater, WISP + Client, WISP+ Repeater |
| Wireless Security |
64/128-bit WEP, WPA-PSK/WPA2-PSK (TKIP/AES) SSID Broadcast Enable/Disable Wireless MAC Filtering |
| Hardware | |
| Standards | IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX |
| Interface | 2*10/100Mbps LAN Port |
| LED Indicators | Power, WLAN, LAN-Main, LAN-Secondary, Wireless Signal 1-4 |
| Buttons | Reset |
| Antenna | 1*10dBi directional Antenna, Dual-polarity |
| Power Supply | Proprietary PoE, DC 24V/0.5A |
| Software | |
| WAN Type | DHCP, PPPoE, Static IP, Russia PPPoE, Unifi PPPoE, L2TP/Russia L2TP, PPTP/Russia PPTP, WISP |
| Port Forwarding | Virtual Servers, UPnP, DMZ |
| QoS | Bandwidth Control |
| Access Control | MAC Filtering |
| Others | Dynamic DNS, PSE |
| Others | |
| Certification | FCC, CE |
| Environment |
Operation Temperature: -30℃~70℃ (estimated) Storage Temperature: -30℃~80℃ (estimated) Humidity: 0~90% non-condensing ESD conductive: 15kV ESD Air: 10kV |
| Package |
1* WF2322 1* 24V/500mAPassive PoEPower Adapter 1* AC Power Cord 2* Cable Ties 1* Quick Installation Guide |
