Indoor GPON Terminal for SOHO

Shenzhen Netcore Industrial Ltd.
Indoor GPON Terminal for SOHO thumbnail-1
Indoor GPON Terminal for SOHO photo-1
Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
netis
Model Number:
GP8501G
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name netis
Model Number GP8501G

Indoor GPON Terminal for SOHO

Product Description

The GP8501G is an indoor optical network terminal designed for home users and small office and home office (SOHO) users, providing one GPON port and oneGE/FE auto-negotiation and auto-MDI/MDIX Ethernet port. By using the Gigabit-capable Passive Optical Network (GPON) technology, the GP8501G provides a high-speed data channel through a single optical fiber with an upstream rate of 1.25Gbps and a downstream rate of 2.5Gbps. In this way, you can enjoy the high-speed dataservice, quality voice service, superior video service.



Features

  • Complies with ITU-T G.984.2 CLASS B+
  • Up to 1.25Gbps for upstream and 2.5Gbps for downstream speed
  • Maximum transfer distance up to 20Km
  • Multiple traffic mapping modes supported
  • IGMP V2&V3 Snooping, IGMP proxy
  • Support VLAN filtering & VLAN transparent transmission, VLAN N:1 aggregation and VLAN 1:1 translation
  • Local management through Web-based GUI and efficient remote management function
  • 1* SC/APCGPON port, 1* 10/100/1000Mbps auto-negotiation and auto-MDI/MDIX RJ45 LAN port

Specification

Indoor GPON Terminal for SOHO
Hardware
Interface1* SFF/SC PON port
1* 10/100/1000Mbps auto-negotiation and MDI/MDIX RJ45 LAN port
Data RateUpstream 1.25Gbps
Downstream 1.25Gbps
Distance0-20KM
Splitting Ratio1:32(20KM)  1:64(10KM)
Optical Power-1~+4dBm
Receive Sensitive-25.5dBm
LEDLAN PON LOS PWR
ButtonPower on/off
Default
Power AdapterExternal 9V500MA
Power consumption<5W (MAX)
Dimensions(L x W x H )     115(L)*87.95(W)*48.5(H)mm
Weight111g
Software
StandardIEEE 802.3-2005, IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX,
IEEE 802.3ab 1000Base-T,  IEEE 802.1p, IEEE 802.1q
QoSService Flow Classification based on MAC Address/VLAN/ IP Address
/DSCP /L4 port,
802.3x flow control,
Schedule rules Support SP/WRR/SP+WRR,
Upstream Priority Label Support 802.1p User Priority,
Rate Limit and Traffic shaping,
Congestion Control Support Tail-Drop/WRED/RED
VLAN802.1Q tag VLAN,
VLAN transparent mode/VLAN translation mode/VLAN trunk mode
Advanced Features Authentication based on Loid and Password,or base on MAC
Upstream and Downstream FEC,
Dynamic Bandwidth Allocation(DBA) ,
Optical power detection, Dying Gasp,
Terminal Silent mechanism,
Ethernet port loop testing
SecurityAES Encryption,
Triple churning
Illegal Frame/Illegal Multicast Filtering
Management                        Managed by Web and OAM,
Specified the management IP/MAC,
Reset to Factory default by Reset button or Web UI,
Real-time statistics, Optical Diagnostic, System Log
IGMPIGMP v2/v3
IGMP Snooping
Others
Environment          Operating Temperature: 0℃~40℃(32°F~104°F)
Storage Temperature: -40℃~70℃(-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Package1 * EP8101G
1 * 9V/500MA Power Adapter
1 * Ethernet Cable
1 * Quick Installation Guide



Application

Indoor GPON Terminal for SOHO
