P7.62 Outdoor Single/dual/full Color Double Side Led Moving Signs

Name: P7.62 Outdoor Single/dual/full Color Double Side Led Moving Signs
Brand: Liyi
SKU: 100373171

P7.62 Outdoor Single/dual/full Color Double Side Led Moving Signs thumbnail-1

P7.62 Outdoor Single/dual/full Color Double Side Led Moving Signs photo-1

US$ 200 - 500 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Liyi

Model Number:

liyi-R-p7.625

Contact Supplier Request Quote Chat Now

Shenzhen Liyi Optoelectronic Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen/Hongkong

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Liyi

Model Number liyi-R-p7.625

Usage Outdoor

Tube Chip Color Red

Display Function Video

Pixels 7mm

Screen Dimension 1000

Specifications

1. Big size LED chips;
2. Good Color mixture;
3. Good Color consistency;
4. Energy-saving;
5. CE.ROHS

Specifications

1. Big size LED chips;
2. Good Color mixture;
3. Good Color consistency;
4. Energy-saving;
5. CE.ROHS

P7.62 outdoor single/dual/full color led moving signs

Description	Technical parameter
Unit module	Module size	244*122mm
	Pixel pitch	7.62mm
	Pixel density	17222dots/m2
	Pixel configuration	1R1G1B
	Led specification	346 DIP
	Pixel resolution	W:244dots*H:122dots
Cabinet	Dimension	976mm976mm150mm
	Quantities of module	32pcs
	Power supply	4pcs
	Thermal discharge	Fan*2pcs
	Total weight	40kg
	Best viewing angle	2-100m
	Temperature	Storage: -35°C~+85°C
	Temperature	Working: -35°C~+85°C
	Thickness	15cm can adjustable
	Remarks: cabinet size can changed, upon project need.
Power	Working voltage	AC220V/110V±10%
	Average power consumption	200-300W
	Max. Power consumption	≤320W/sqm
	Current	≤20mA(single LED)
Control system	CPU	Pentium4 or above
	Operating system	WIN98/2000/NT/XP
	Control method	Synchronization
Main technical parameter	Driving device	1/16scanning
	Drive type	Constant Current driver IC
	Refresh frequency	≥300Hz
	Grey scale/colors	256 levels of each color(R/G/B)/16.7M color
	Brightness of white balance	More than 2200cd/sqm
	Brightness adjustment	256 levels of each color(R/G/B)by software
	Operating ambient humidity	10%--95%
	Video signal	PAL/NTSC
	Control system	DVI display card+full color controller card
	MTBF	≥10,000hours
	Life span	≥100,000hours
	Flatness	Tolerance of interpixel ≤0.3mm
	Flatness	Tolerance of modules clearance≤0.6mm
	Power switch	Automatic switch
	Display mode	1024*768
	Communication distance	Unshielded twisted pair net line transmission distance 100m, max transmission distance 200m. Multi-mode Optic fiber transmission distance 500m;Single-mode optic fiber transmission distance 10KM
Software	LED media player

♣ Application of led display:

Wide applied in stadiums,advertisement,banks,securities exchange,stations,shoping

♣ Colorful

outdoor led screen, single color led screen , red color led screen, led message screen , led moving screen , led screen billboard,led video screen,sport led screen

♣ Varieties of LED screen products

P6mm,P7.62mm,P8mm,P10mmI,P10mmO,P12mm,P14mm,P16mm,P18mm,P20mm

♣Widely Use

Widely used in advertising, sports, industrial enterprises, transportation, stations, terminals, airports, construction, education system,hospitals and other public places

♣Our service
1.Your inquiry related to our products or price will be replied in 24hrs
2.the size can be change as you give ,your customized lightings we can help you to design and put into product
3.what we show is some of our current models,welcome to give us your own ideas.
4.Protection of your sales area,ideas of design and all your private information

5.(Top Quality) + (Reasonable Price) + (Responsible After Service) = (Successful & Win)
