Full color indoor P5 hire led display with fact lock cabinets
1. Function and Technology Character
(1) Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive.
(2) Information source can be camera, video, VCD, DVD, LD, TV and so on.
(3) Clear picture without flicker and distortion.
(4) Brightness, contrast, saturation can be adjust by itself and manual.
(5) Show everything with your PC does synchronously.
(6) Super correcting technology for distortion.
(7) One interface for sound signal and two for video signal at least.
(8) Connected and controlled by PC via Lan and remote control.
(9) Multiform language editions, such as English, French, Germany, Greek, Russian and so on
2. Spec and Parameters
Display and Control Feature |
Structure Feature |
||
Spec |
Parameter |
Specification |
Parameter |
Pixel Pitch |
5mm |
Module size |
160mm*160mm |
Pixel composing |
1R1G1B |
Display resolution/module |
16 dots*16 dots |
Wavelength (R) |
625±5 |
Standard cabinet size |
800mm*640 |
Wavelength (G) |
522±3 |
Weight per sqm |
45 Kg/sqm |
Wavelength (B) |
567±3 |
Protection classification |
--- |
Wave Angle (H) |
140°(H)/140°(V) |
Install mode |
Wallmount, hung and stand structure |
LED package |
SMD 0603 |
SMD TYPE |
SMD 1in1 |
Density |
40,000 |
Working Power |
|
Display color |
256*256*256 |
Specification |
Parameter |
Whiteness brightness |
≥1600cd |
Working voltage |
AC 220v/380v±10% 47~64Hz |
Brightness level |
128 grade |
Max power/sqm |
1500W/sqm |
Changing frame frequency |
60 Hz |
Average power/sqm |
700W/sqm |
Refresh |
400 Hz |
Short circuit protection |
Yes |
Driving method |
Constant driving 1/8 |
|
|
Control mode |
synchronous |
Working Environment |
|
Display port |
DVI |
Specification |
Parameter |
Display mode |
1024*768 1024*1024 |
Environment |
Indoor |
Out of control |
1/10,000 ( scattered) |
Working temperature |
--5~50°C |
lifetime |
100,000 hours |
Working Humidity |
10~90% |
Any interest, welcome to Skype:cymsnow or Whats app:+8618665370510
