| Item | Aluminum Die-casting Rental(480*480) | |
| Pixel Pitch: | 4mm | 5mm |
| Driving Method : | 1/15 | 1/12 |
| LED type : | SMD3528 | SMD3528 |
| Pixel configuration: | 1R1G1B | 1R1G1B |
| Brightness: | >1300cd/m 2 | >1300cd/m 2 |
| Pixel density : | 62500pix/m 2 | 40000pix/m 2 |
| Viewing angle: | 140°H and 120°v | 140°H and 120°v |
| Module Size(W*H*D): | 240*240*20 | 240*240*20 |
| Cabinet Size(W*H*D): | 480*480*80 | 480*480*80 |
| Cabinet weight: | 8.5kg | 8.5kg |
| Cabinet Material: | Aluminum Die-casting | Aluminum Die-casting |
| Avarage Power Consumption: | 420 W/m 2 | 320 W/m 2 |
| Max Consumption : | 1050 W/m 2 | 850 W/m 2 |
| Refresh rate: | >1200HZ | >1200HZ |
| Color Depth: | 14bit | 14bit |
| voltage : | 200-240V | 200-240V |
| IP Rrating: | IP31 | IP31 |
| Operating temperature : | -20-60 degree | -20-60 degree |
| Storage temperature: | -40-70 degree | -40-70 degree |
| Operation humidity: | 10-90% | 10-90% |
| Storage humidity: | 10-90% | 10-90% |
| Life span (hrs): | >50000 | >50000 |
| MTBF (hrs) : | >3500 | >3500 |
| Control system: | Linsn/Nova | Linsn/Nova |
| Source compatibility (with video processor): | YC, VGA, DVI, YUV, SDI, RGB,CVBS,GD-SDI | YC, VGA, DVI, YUV, SDI, RGB,CVBS,GD-SDI |
| Compliant standard: | CE,FCC,RoHS,ETL,CCC | CE,FCC,RoHS,ETL,CCC |
Features:
1. Modular design
Guarantee high overall system availability and easy maintenance.
2. Designed for reliable operation in video play and live broadcast applications.
Best possible adaptation to local display needs.
3. Ambient light control
Extended display lifetime by automatic adjustment of brightness depending on the actual ambient light conditions.
4. Using SMT or AI automatic production line
It reduces manufacturing variation and improves product performance.
5. Good uniformity and consistency
It provides for amazingly sharp, vivid and clear images.
Relevant Market:
Three in One SMD Indoor Full Color Display has been specially designed for applications in public information systems, Adverting, Media and Entertainment.
Airports, Border ports, Seaports
Railway stations, subways, bus terminals, coach stations
Schools, banks, stock exchanges
Stage setting, television studio
Hotel lobbies, casinos, disco, bar
- Pre-sale service
1.We offered technical advises to our customers before buying our led screen
2.Help customers to choose suitable product within budget most economy benefit.
3.We offered software customization for our customer a specific usage.after-salesservice
-
1.We promise our customer more than just two years warrantly service!We provide free maitenance services including remote configuration,technical consultation,and trouble shooting for our costomer.
2.We promise a life time follow-up service for all the equipment supply by our company.these include continuously improve of system functions and upgrade of system software.
3.We offered training to our customer which include operating and maintenance of our products
RYHAM OPTOELECTRONICS set up 8 years,we are specializing in the production of outdoor and indoor led display,flexible/soft curtain display screen,etc.
We can offer you excellent service.
1)The most comprehensive fashion luxury advertising taxi light box.
2)Good Quality , resonable price and quick deilivery.
3)All kinds of led product can be customized according to your requirements.
