CNG Truck

Name: CNG Truck
Brand: heto
SKU: 100048563
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Capacity (Load):

Other, 1-10T

Emission Standard:

Euro 4

Weifang Xiaer Imp. & Exp. Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Capacity (Load) Other, 1-10T

Emission Standard Euro 4

Fuel Type Petrol / Gasoline

Place of Origin Shandong, China

Brand Name heto

Model Number HT1041

CNG truck

Model:HT1041

Overall specification	overall length mm		5980	Engine	engine type	4100QN-2
	overall width mm		2100		manufacturer	Chengdu yunnei
	overall height mm		2360		engine position	Frong-mounted
					engine model	Four-cylinder, in line, water cooling
	wheel base mm		3300		Rated power (kw/rpm)	64/3200
	front/rear overhang mm		1420/1260		Max.torque (N.m/rpm)	225/1800-2000
	approaching and departure angle		25/28		displacement (ml)	3,610
	first step height mm				bore and stroke mm	102×115.
	Max. total mass (kg)		5530		fuel type	CNG
	rated payload(kg)		3000		emission standard	Euro II
	Max. speed km/h		90
Item		standard deploy					option
	chassis type	HT1041
	transmission	5T88, 5+1 speed
	front axle	3T, Hu Bei Bo Ying
	rear axle	pressed axle housing, single reduction, 5T, Hu Bei Bo Ying
	suspension	leaf spring, front 2/ rear2
	steering	Integral power steering
	braking	dual-circuit air braking /drum brake
	Gas cylinder	4 X50L, Bottom mounted
	tyre	7.50-16
	battery/alternator	1*105A 24V
Main body assembly	body structure	Rigid frame wide flange welded I section for resisting twist.The chassis is longitudinal and cross mumbers.
	interior trimming	Common interior trimming
	door	Two doors
	window and windscreen	Side window is toughened glass, windscreen is laminated glass
	rearview system	manual rearview mirror, inner view mirror
	Lighting	integral front/rear headlight
	wiper	wiper with washing function
	seat	common seat (no cloth cover),
	paint	domestic high grade paint
	others	skylights, Tilting cabin, A/C, Cargo box size:42701920390,Radio,white,RHD,6-wheel,without extra cabin..
