Medium Truck

Medium Truck thumbnail-1
Medium Truck photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Capacity (Load):
Other, 11-20T
Drive Wheel:
6x4
Contact Supplier Request Quote Chat Now
Weifang Xiaer Imp. & Exp. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Capacity (Load) Other, 11-20T
Drive Wheel 6x4
Horsepower Other, 150-250HP
Transmission Type Manual
Fuel Type Diesel
Place of Origin China
Brand Name Heto
Model Number HT1120P

Medium truck



model HT1120p  ..
1.Direct drive floor mounted gear liver transmission.
2.Excellent road grip tyre,suitable for On/Off use in hilly territory.

MODEL                      HETO1120P
Seating capacity 3 DIMENSION AND WEIGHT
Method of driving 4x2 Wheel Base: 4700 mm
Steering position RIGHT or LEFT Ground Clearance: 260mm
ENGINE   Turning Radius 14m
Model CA4110 Front Track: 1800 mm
Type Direct injection Rear Track: 1700 mm
  water Cooled Overall Length: 8550 mm
  diesel engine Overall Width: 2330 mm
Cylinder 4 Cylinder in line Overall Heights: 2780 mm
  4 stroke Cargo Body Length: 6210 mm
Bore & Stroke (mm ) 110& 125 Cargo Body Width: 2160 mm
Displacement 4752 Cargo Body Height: 550 mm
Power (kw) 100kw/2700RPM PERFORMANCE
Compression ratio   Curb Weight: 5920 Kg
Torque (Nm) 392Nm/1600-1800RPM Load Weight: 10000KG
Cooling system Heavy-duty radiator Max. Speed: 90 Km/Hr
  with cooling fan &  Gradeability: 30%
  watar pump. FUEL TANK
TRANSMISSION Capacity: 160 Liter
Gear Box LC6t46 Fuel Consumption: 16 Litre/100 Km
Type 6Forward+1reverse  Paint Superior quality spray paint
  with synchronizers   with protective primer.
  gearbox&manaul shift ELECTRIC SYSTEM
STEERING Battery 24 Volt
Type Power steering with  Alternator 24 Volt, 1000 w
  steering lock Starter 24 Volt, 5 kw
Driving method R or L hand drive TYRES
Suspension Semi elliptical alloy steel leaf Quantity 2 Front + 4 Rear
  leaf spring
Shock absorber Double action  Size 9.00-20R
  Hydraulic type    (ON / OFF Highway Capability)
CHASSIS Accessories (a)Ammeter
Type Rigid frame-wide flanged    (b)Head Light, Back Light,
  welded I-section for resisting   Packing Light, Fog Light
   twist the chassis is longitudinal   Reverse Light,
  and cross members    Drivers Cabin Light
CLUTCH   (c)Water temperature Indicator
Type Single dry plate Hydraulically   (d)    Engine oil pressure gauge
  Operated &    (e)   Hydraulic Jack & Wheel Wrench
  Pneumatically Assisted.   (f)    Fuel level meter
BRACK SYSTEM   (g)   Ammeter
Type Hydraulic dual circuit drum    (h)    Radiator Protection Grill
  brack   (i)   Reversing alarm
Service Brake Air Brake   (j)    Rear view mirrors
      (k)   Tools set
Parking Brake Mechanical (In rear wheel    (l)Standard Accessories &
  drum its, lever controlled) ...   Safety Devices for beam lifter

....
