FRP Grating With Clips for Secure Installation - Lightweight Composite Fiberglass Gratings
Product Spotlights
Secure installation with pre-matched stainless steel or galvanized clips; lightweight composite fiberglass (only 1/4 weight of steel); excellent corrosion resistance and slip-proof surface; customizable size, thickness, color, and resin type; non-conductive and low maintenance; suitable for industrial platforms, walkways, trench covers, and marine environments.
Negotiable
MOQ: 300 Blades (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Fiberglass Reinforced Plastic (FRP)
Surface Type:
Concave-Convex / Grit Top
Color:
Yellow, Gray, Green, Orange (Customizable)
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin/ Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
FRP Molded Grating for Bridge Walkways - Corrosion Resistant, High Strength, Low MaintenanceNegotiableMOQ: 300 Blades -
Pultruded FRP Composite Grating for Pedestrian Decking - Fiberglass GRP Walkway PanelsNegotiableMOQ: 300 Blades
-
FRP Plastic Grating With Gritted or Concave Surface - Slip-Resistant Fiberglass CompositeNegotiableMOQ: 300 Blades
-
FRP Walkway Grating for Platform & Carwash Floor - Small Hole Fiberglass Grille PanelNegotiableMOQ: 300 Blades
-
Lightweight FRP Grating for Easy Installation and Long-Lasting Durability - Fiberglass CompositeNegotiableMOQ: 300 Blades
Material
Fiberglass Reinforced Plastic (FRP)
Surface Type
Concave-Convex / Grit Top
Color
Yellow, Gray, Green, Orange (Customizable)
Panel Size
Customizable: 1220mm x 3660mm (Standard)
Thickness
25mm, 30mm, 38mm (Other thicknesses available)
Load Capacity
Light to Heavy Duty (Customizable)
Clip Type
Stainless Steel or Galvanized Steel Clips
Resin Type
Polyester / Vinyl Ester / Phenolic
Application
Industrial Platform, Walkway, Trench Cover, Stair Tread
Fire Resistance
Class C (Optional Class B available upon request)
Welcome to Hengshui Ruibin New Materials LLC – a professional manufacturer founded in 2019, dedicated to producing high-quality composite materials. Our factory spans 1,000–3,000 square meters and employs 101–200 skilled workers. We export products worldwide, including North America, South America, Europe, Southeast Asia, Africa, and Oceania, with an annual export value between US$2.5 million and US$5 million. Our FRP Grating with Clips for Secure Installation is designed to provide safe, durable, and lightweight flooring solutions for various industrial and commercial applications. Made from fiberglass-reinforced plastic, this grating offers excellent corrosion resistance, low maintenance, and easy installation. The included stainless steel clips ensure panels stay firmly in place, even in high-traffic or vibration-prone environments.
Key Features & Benefits
- Lightweight yet Strong: Only 1/4 the weight of steel grating, reducing shipping costs and simplifying installation without compromising load capacity.
- Corrosion Resistance: Impervious to moisture, chemicals, and UV exposure – ideal for wastewater treatment plants, chemical processing, offshore platforms, and marine environments.
- Slip-Resistant Surface: Concave-convex pattern or grit top provides excellent traction even when wet, enhancing worker safety.
- Secure Clips Included: Our specially designed clips (stainless steel or galvanized) lock panels together and to the substructure, preventing movement and rattling.
- Customizable Options: Available in multiple colors (yellow, gray, green, orange), thicknesses (25–38mm), and resin types (polyester, vinyl ester, phenolic) to match your specific requirements.
- Non-Conductive & Non-Magnetic: Safe for electrical rooms, MRI facilities, and areas where static discharge must be avoided.
- Low Maintenance: No need for painting, coating, or rust treatment – simply wash with water to keep clean.
- Easy Drilling & Cutting: Can be field-cut with standard carbide tools for on-site adjustments.
Technical Specifications
| Property | Value |
| Panel Standard Size | 1220 x 3660 mm (customizable) |
| Thickness | 25 mm, 30 mm, 38 mm |
| Load Capacity | From 200 kg/m² to 800 kg/m² (custom) |
| Resin Types | Polyester, Vinyl Ester, Phenolic (upon request) |
| Surface Finish | Concave-convex / Grit top |
| Clip Material | Stainless Steel (SS304/SS316) or Hot-Dip Galvanized Steel |
| Fire Resistance | Class C (ASTM E84); Class B available for flame-retardant applications |
| Operating Temperature | -40°C to +80°C (polyester), up to +110°C (phenolic) |
Why Choose Hengshui Ruibin?
Since our establishment in 2019, we have built a reputation for delivering consistent quality across global markets. Our 101–200 employees work in a factory covering 1,000–3,000 square meters, equipped with compression molding and pultrusion lines. We ship from Port of Tianjin and Port of Qingdao to major destinations worldwide, including North America, South America, Europe, Southeast Asia, Africa, and Oceania. Our annual export value of US$2.5 million–US$5 million reflects the trust our customers place in us. Every FRP grating panel and clip undergoes strict quality control to ensure dimensional accuracy and strength. We offer free sample testing and customized cutting services. Contact us today for competitive pricing and professional technical support!
Frequently Asked Questions
-
Q: Are the clips included in the standard package?
A: Yes, each grating panel comes with matching stainless steel or galvanized steel clips for secure installation. The quantity of clips depends on panel size and load requirements. -
Q: Can these gratings be used for heavy-duty vehicle access?
A: Our standard thicknesses (25–38 mm) are suitable for pedestrian walkways and light vehicles. For heavy-duty truck or forklift traffic, we recommend customized thicker panels (up to 50 mm) with additional reinforcement. -
Q: What colors are available?
A: Standard colors include yellow, gray, green, and orange. Custom colors can be matched using RAL or Pantone codes with minimum order quantity. -
Q: Is the grating slip-resistant when wet?
A: Yes, the concave-convex surface design provides excellent slip resistance even in oily or wet conditions. Grit top surface is also available for additional traction. -
Q: How do you cut the grating on site?
A: Use a circular saw with a carbide-tipped blade or a jigsaw with fine teeth. We recommend wearing safety glasses and a dust mask during cutting. -
Q: What is the typical lead time for a standard order?
A: For standard sizes and colors, production takes 10–15 working days. Custom orders may require 15–20 working days depending on complexity. Urgent orders can be arranged upon request. -
Q: Do you offer free samples?
A: Yes, we provide free sample pieces (approx. 10x10 cm) for quality evaluation. Customers only need to pay shipping costs.
