Help CenterFRP Drainage Channel With 304 Stainless Steel Bolts 50mm Width 100mm Depth for Pedestrian Areas
Product Spotlights
Related Products
-
Fire Retardant FRP Drainage Channel Class B2 Standard 120mm Width 160mm Depth for Industrial FloorsNegotiableMOQ: 300 Blades -
FRP Drainage Channel With Technical Support and Installation Manual 5-Year Warranty on CorrosionNegotiableMOQ: 300 Blades
-
FRP Drainage Channel for Food Processing Plants With Antimicrobial Resin Smooth InteriorNegotiableMOQ: 300 Blades
-
Lightweight FRP Drainage Channel E600 Load Class 200mm Wide 300mm Deep Bolted ConnectionNegotiableMOQ: 300 Blades
-
1 Year Warranty FRP Drainage Channel With Mill Test Report Standard Compliant EN1433NegotiableMOQ: 300 Blades
As a leading manufacturer based in Hengshui, Hebei, China, Hengshui Ruibin New Materials LLC specializes in producing high-quality FRP drainage solutions. Our FRP Drainage Channel with 304 Stainless Steel Bolts (50mm width, 100mm depth) is meticulously engineered for pedestrian areas, combining durability, corrosion resistance, and ease of installation. With over 5 years of industry experience and a factory spanning 1,000–3,000 square meters, we ensure every product meets stringent quality standards, backed by our ISO9001 and ISO9000 certifications.
This drainage channel is designed to efficiently manage surface water in pedestrian zones such as walkways, plazas, parks, and sidewalks. The integration of 304 stainless steel bolts guarantees a secure and long-lasting connection, while the FRP material offers superior strength-to-weight ratio, making it an ideal alternative to traditional concrete or metal channels. Our product is exported to over 10 global markets, including North America, Europe, and Southeast Asia, reflecting our commitment to international quality benchmarks.
Key Features and Technical Specifications
- Material: Premium FRP (Fiberglass Reinforced Plastic) – resistant to UV, chemicals, and moisture, ensuring a service life of over 20 years.
- Bolt Specification: All bolts are made of 304 stainless steel, providing excellent corrosion resistance even in harsh outdoor environments.
- Dimensions: Channel width of 50mm and depth of 100mm, optimized for pedestrian drainage without compromising aesthetics.
- Load Capacity: Designed for pedestrian loads (up to 1.5 kN, meeting EN 1433 Class A 15), suitable for areas with light vehicle access if specified.
- Surface Texture: Anti-slip top surface for pedestrian safety, with optional grating or cover.
- Installation: Pre-drilled holes for 304 stainless steel bolts enable quick and secure assembly; modular design allows easy customization of length.
- Maintenance: Smooth inner surface reduces debris buildup, and the FRP material is non-porous, making cleaning simple.
| Parameter | Value |
| Channel Width | 50mm |
| Channel Depth | 100mm |
| Standard Length | 1m (customizable upon request) |
| Bolt Material | 304 Stainless Steel |
| Load Class | A 15 (pedestrian, optional up to C 250) |
| Weight per Meter | Approx. 2.5 kg |
| Color | Gray (RAL 7035) or custom |
The FRP material offers a 60% weight reduction compared to concrete channels, reducing transportation and installation costs. The 304 stainless steel bolts are pre-installed at the factory, ensuring consistent quality and saving on-site labor. Additionally, the channel's inert nature makes it suitable for use in environmentally sensitive areas, as it does not leach chemicals into the soil.
Benefits for Your Projects
- ✔ Longevity: Non-corrosive FRP endures freeze-thaw cycles, saltwater, and chemical exposure, ideal for coastal and urban pedestrian zones.
- ✔ Safety: Anti-slip top surface and rounded edges reduce tripping hazards; lightweight design prevents accidental crushing.
- ✔ Cost-Effective: Lower installation time (no heavy machinery needed) and minimal maintenance over the product life.
- ✔ Aesthetic Flexibility: Can be color-matched to surrounding pavers, and the low profile design integrates seamlessly with paving.
- ✔ Eco-Friendly: 100% recyclable FRP material and reduced carbon footprint due to lighter transport weight.
With a dedicated team of 101–200 employees and an annual export value of US$2.5–5 million, Hengshui Ruibin New Materials LLC has established a strong presence in global markets. Our ISO9001 and ISO9000 certifications ensure strict quality control from raw material sourcing to final inspection. We ship from the Ports of Tianjin and Qingdao, with reliable logistics partners covering North America, Europe, Asia, and beyond. Our factory's 1,000–3,000 square meter facility enables rapid production and customization, allowing us to meet urgent project deadlines.
Whether you are a contractor, architect, or municipal planner, our FRP drainage channel with 304 stainless steel bolts delivers a robust, long-lasting solution for pedestrian drainage. We welcome OEM/ODM inquiries and bulk orders with competitive pricing. Contact us today for a quote or to request samples – your satisfaction is our priority.
Frequently Asked Questions
-
Q: What is the maximum load capacity of this channel?
This channel is rated for pedestrian loads (Class A 15, up to 1.5 kN). For occasional light vehicle access, we can supply a reinforced version (Class C 250) upon request. -
Q: Can the channel be cut to a custom length?
Yes, the FRP material can be easily cut on-site using a standard saw. We also offer pre-cut sizes in multiples of 1m. Please specify your required length when ordering. -
Q: Are the 304 stainless steel bolts included with the channel?
Yes, all bolts are supplied pre-installed or in a separate kit, depending on the order quantity. They are made of 304 stainless steel for maximum corrosion resistance. -
Q: Is this product suitable for use in cold climates?
Absolutely. FRP has low thermal conductivity and is resistant to freeze-thaw damage. The bolts are also stainless steel, which remains stable in sub-zero temperatures. -
Q: What colors are available?
Standard color is gray (RAL 7035). Custom colors (e.g., black, green, beige) can be produced for minimum order quantities (MOQ). Contact us for details. -
Q: How do I install the drainage channel?
Installation is straightforward: prepare a trench, place the channel sections, connect them using the bolts, and backfill with concrete or gravel. A detailed installation manual is provided with each order. -
Q: Do you offer product samples?
Yes, we can provide a 30cm sample for evaluation. Shipping costs are negotiable. Please contact our sales team for sample requests. -
Q: What is the warranty period?
We offer a standard 2-year warranty against manufacturing defects. The FRP material itself has a service life exceeding 20 years under normal conditions.
