Welcome to Hengshui Ruibin New Materials LLC – your trusted manufacturer of high-performance FRP drainage solutions. Our Lightweight FRP Drainage Channel E600 Load Class 200mm Wide 300mm Deep Bolted Connection is engineered to deliver exceptional durability, corrosion resistance, and ease of installation. As a factory established in 2019 with a 1,000-3,000 sqm facility and an annual export value of US$2.5-5 million, we combine modern production techniques with rigorous quality control to bring you a product that meets the highest standards of performance and safety.
This drainage channel is designed to handle heavy traffic loads up to E600 class (60 tons), making it ideal for highways, airports, ports, and industrial zones. The bolted connection system ensures secure, leak-proof joints, while the lightweight FRP material reduces transportation and handling costs. Whether you need a reliable solution for stormwater management or surface drainage, our product offers a long service life with minimal maintenance.
Key Features & Benefits
- Lightweight Design: FRP is up to 75% lighter than traditional concrete or steel channels, enabling faster installation without heavy equipment.
- High Load Capacity: Rated E600 per EN 1433, suitable for areas with heavy vehicle traffic, including trucks and forklifts.
- Corrosion & Chemical Resistance: Non-metallic material resists rust, salt, acids, and UV degradation, perfect for coastal or chemical plant environments.
- Bolted Connection: Pre-drilled flanges and stainless steel bolts provide strong, watertight joints; easy to assemble and disassemble for maintenance.
- Smooth Interior Surface: Optimized hydraulic profile ensures high flow capacity and self-cleaning effect, reducing clogging risks.
- Customizable Lengths: Available in standard 1m, 2m, or custom lengths to match project requirements.
- Low Maintenance: No need for painting or coating; simple periodic cleaning ensures long-term performance.
Technical Specifications
| Parameter | Value |
| Load Class | E600 (EN 1433) |
| Internal Width | 200 mm |
| Depth | 300 mm |
| Standard Length | 1000 mm (customizable) |
| Material | Fiberglass Reinforced Polymer (FRP) |
| Connection Type | Bolted with stainless steel hardware |
| Weight (approx.) | ~12 kg per meter (varies by length) |
| Operating Temperature | -40°C to +80°C |
| Color | Gray (RAL 7040), other colors available on request |
Detailed Product Description
The Lightweight FRP Drainage Channel E600 is manufactured using a pultrusion process that ensures consistent fiber orientation and high strength-to-weight ratio. The channel features a U-shaped profile with reinforced ribs for added rigidity. The bolted connection system includes pre-drilled holes on the flanges, allowing quick alignment and fastening with supplied stainless steel bolts, nuts, and washers. Each joint is sealed with an EPDM gasket (optional) to prevent leakage.
This drainage channel is particularly suitable for projects where weight limitations exist, such as rooftop drainage, pedestrian bridges, or elevated platforms. It also excels in corrosive environments like wastewater treatment plants, chemical factories, and marine applications. The smooth interior surface minimizes friction loss, enabling efficient water conveyance even at low slopes.
Why choose our FRP channel over concrete or steel? Concrete channels are heavy and prone to cracking; steel channels corrode over time. FRP offers a perfect balance of strength, lightness, and durability. With a lifespan exceeding 30 years under normal conditions, it provides excellent return on investment. Our product is backed by ISO9001 certification, ensuring consistent quality from raw material procurement to final inspection.
Trust & Credibility
Hengshui Ruibin New Materials LLC has been serving global clients since 2019, with a dedicated team of 101-200 employees and an annual export value of US$2.5 million - US$5 million. Our products are shipped to North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. We are located in Hengshui, Hebei – a major FRP production hub in China, giving us access to high-quality raw materials and skilled labor. Our factory is equipped with advanced pultrusion lines and testing facilities to ensure each channel meets the E600 load class requirements. We also offer custom lengths, colors, and bolt configurations to suit your specific project needs. Contact us today for a quote or technical consultation – we are ready to support your next drainage project with reliable, lightweight, and cost-effective FRP solutions.
Frequently Asked Questions
-
Q: What does E600 load class mean?
A: E600 is a load class defined by EN 1433, indicating the channel can withstand a static load of 60 tons (600 kN) and is suitable for areas with heavy traffic, including highways, airports, and industrial yards. -
Q: Can this channel be used in corrosive environments?
A: Yes, FRP is highly resistant to corrosion from chemicals, saltwater, and UV radiation, making it ideal for wastewater treatment plants, chemical plants, coastal areas, and other harsh environments. -
Q: How is the bolted connection installed?
A: The channel ends come with pre-drilled flanges. Simply align two sections, insert the stainless steel bolts, and tighten with nuts. An optional EPDM gasket can be placed between flanges for a watertight seal. -
Q: What is the standard length? Can I order custom lengths?
A: Standard length is 1000 mm. We also offer 2000 mm and custom lengths up to 6000 mm upon request. Please contact our sales team for customized sizes. -
Q: Does the channel require any special maintenance?
A: No special maintenance is needed. Periodic cleaning to remove debris is sufficient. The material does not rust, decay, or require painting. Inspect bolts periodically for tightness. -
Q: Is the product certified?
A: Yes, our factory is ISO9001:2015 certified. The channels are manufactured under strict quality control procedures. Load class testing is performed per EN 1433 standards. -
Q: What is the weight of a 1-meter section?
A: Approximately 12 kg for the 200mm wide x 300mm deep profile. Exact weight may vary slightly depending on length and reinforcement configuration. -
Q: Can I get a sample before bulk order?
A: Yes, we provide sample channels for evaluation. Please contact us to discuss sample requirements and shipping arrangements.
