Help CenterPultruded Fiberglass Drainage Channel 300mm x 3000mm, 6mm Thick, Corrosion Resistant for Chemical Plants
Product Spotlights
Related Products
-
FRP Drain Trench 200mm x 1000mm, Slot Width 20mm, Anti-Slip Surface, UV-Stabilized ResinNegotiableMOQ: 300 Meters -
Fiberglass Drainage Channel for Parking Lot Drainage Water Collection System With High Flow CapacityNegotiableMOQ: 300 Meters
-
Fiberglass Drainage Channel 1.2m Length 150mm Width With 304 Stainless Steel Grating E600 Load RatingNegotiableMOQ: 300 Meters
-
FRP Fiberglass Drainage Channel 100mm Width 200mm Depth With Galvanized Steel Grating Class C250 Load CapacityNegotiableMOQ: 300 Meters
-
UV Resistant Fiberglass Drainage Channel 200mm Wide 300mm Deep With Bolted Connections for Easy InstallationNegotiableMOQ: 300 Meters
As a leading manufacturer based in Hengshui, Hebei, China, Hengshui Ruibin New Materials LLC specializes in producing high-quality composite drainage solutions. Our Pultruded Fiberglass Drainage Channel 300mm x 3000mm, 6mm Thick is engineered to withstand the harshest chemical environments, offering exceptional corrosion resistance and long-term durability. With over 100 skilled employees and an annual export value reaching US$5 million, we ensure every product meets rigorous international standards.
This drainage channel is crafted using advanced pultrusion technology, which combines continuous fiberglass strands with thermosetting resins to create a dense, void-free profile. The result is a lightweight yet extremely strong channel that resists attack from acids, alkalis, solvents, and other corrosive substances commonly found in chemical plants. Its 6mm thick wall provides structural integrity while maintaining a low profile for easy integration into flooring systems.
Key Features & Technical Specifications
- Corrosion Resistance: Unaffected by most chemicals, including sulfuric acid, hydrochloric acid, and sodium hydroxide.
- Lightweight Design: Weighs approximately 70% less than traditional steel or concrete channels, reducing installation labor and costs.
- High Strength-to-Weight Ratio: Pultruded fiberglass offers tensile strength comparable to steel, yet with superior impact resistance.
- Non-Conductive: Safe for use in electrical environments; does not conduct electricity.
- Low Thermal Expansion: Maintains dimensional stability across a wide temperature range (-40°C to +120°C).
- UV Protection: Optional UV-stabilized surface layer for outdoor applications.
- Easy Installation: Can be cut, drilled, and fastened with standard tools; interlocking systems available for continuous runs.
| Parameter | Value |
|---|---|
| Material | Fiberglass Reinforced Polymer (FRP) – E-glass / Vinyl Ester or Polyester resin |
| Dimensions | 300mm (width) x 3000mm (length) x 6mm (thickness) |
| Color | Standard: Gray / Yellow / Custom (RAL colors available) |
| Load Rating | Up to 8 kN/m² (tested per EN 124 or equivalent, contact for details) |
| Surface Finish | Smooth interior for optimal flow; anti-slip options available |
| Certifications | ISO9001:2015, ISO9000 |
| Fire Resistance | Class 1 (BS 476) or equivalent upon request |
Advantages for Chemical Plant Applications
Chemical plants demand drainage systems that can handle aggressive spillages, constant moisture, and heavy loads. Our pultruded fiberglass channel outperforms traditional materials in several ways:
- Long Service Life: Unlike steel, it won't rust; unlike concrete, it won't spall or crack due to chemical attack.
- Reduced Maintenance: The smooth interior surface prevents buildup of debris and chemical residues, minimizing cleaning frequency.
- Safe Handling: Lightweight sections reduce the risk of worker injury during installation and maintenance.
- Customizable Lengths: We can supply channels up to 6 meters, or cut to your exact requirements.
- Accessories Available: Gratings, covers, end caps, and junction boxes are offered in matching materials.
Frequently Asked Questions (FAQ)
- What is the exact material composition? The channel is made of pultruded fiberglass using E-glass fibers and a vinyl ester resin matrix, which provides superior chemical resistance compared to standard polyester.
- Can this product withstand concentrated sulfuric acid? Yes, it is resistant to many acids, including sulfuric acid up to 30% concentration at room temperature. For higher concentrations or elevated temperatures, please consult our technical team.
- How is the channel installed? It can be embedded in concrete or mounted on a prepared base. Interlocking joints and adhesive bonding ensure a leak-proof system. Detailed installation guides are provided with each order.
- What is the maximum load capacity? Standard load rating is up to 8 kN/m², but we can design channels for higher loads (e.g., forklift traffic) using thicker walls or additional reinforcement. Contact us for load calculations.
- Do you offer custom colors or sizes? Yes, we can customize colors (RAL), lengths, and widths. Minimum order quantities may apply for custom products.
- Is the product UV resistant? Standard channels are not UV stabilized, but we offer an optional UV protective coating for outdoor use. Please specify when ordering.
- What certifications does your company hold? We are ISO9001 and ISO9000 certified. Our products are manufactured under strict quality control procedures.
- How long is the delivery time? Typical lead time for standard sizes is 15-20 working days after order confirmation. For large quantities or custom orders, please inquire.
At Hengshui Ruibin New Materials LLC, we have been serving global markets since 2019, with a factory spanning 1,000-3,000 square meters and a dedicated team of 101-200 professionals. Our annual export value of US$2.5 million to US$5 million reflects the trust of clients across North America, South America, Europe, Asia, Africa, and Oceania. We ship from the Port of Tianjin and Port of Qingdao, ensuring reliable logistics worldwide.
Choosing our pultruded fiberglass drainage channel means investing in a product that minimizes downtime, reduces replacement costs, and enhances safety in your chemical plant. We stand behind every channel with comprehensive technical support and after-sales service. Contact us today for a quote or to discuss your specific drainage requirements!
