As a leading manufacturer based in Qingdao, China, Qingdao Conqinphi Environmental Technology Group Co., Ltd. specializes in designing and fabricating high-efficiency Sugar Concentration Evaporation Systems for the sugar refinery and food processing industry. With over 10 years of experience and a modern factory covering 10,000–30,000 square meters, we deliver reliable, energy-saving solutions that help you maximize yield and reduce operational costs. Our systems are trusted by clients across North America, Europe, Southeast Asia, and beyond.
This evaporation system is engineered to concentrate sugar solutions, fruit juices, dairy products, and other liquid foods through gentle, efficient evaporation. It features multiple-effect design to reuse steam energy, significantly lowering energy consumption. Whether you need to increase brix value from 15% to 65% or more, our system can be customized to meet your exact production requirements.
Key Features & Technical Advantages
- Multi-Effect Evaporation Design – Up to 7 effects available, reducing steam consumption by 40–60% compared to single-effect systems.
- Low-Temperature Concentration – Operates under vacuum to evaporate at low temperatures (60–80°C), preserving product quality and preventing sugar caramelization.
- High Thermal Efficiency – Heat recovery system preheats incoming feed, further improving energy utilization.
- Automatic PLC Control – Touch screen interface with real-time monitoring of temperature, pressure, flow rate, and brix value. Minimal manual intervention required.
- Sanitary Design – All product contact parts are made of SS304/SS316L with mirror polishing (Ra ≤ 0.8 μm), meeting HACCP and food safety standards.
- Flexible Configuration – Options include falling film, rising film, forced circulation, or hybrid types to suit different viscosity and fouling characteristics.
- Compact Footprint – Modular skid-mounted design reduces installation space and time.
Technical Specifications (Typical Model)
| Parameter | Specification |
|---|---|
| Evaporation capacity | 1,000 – 50,000 kg/h (customizable) |
| Feed concentration (Brix) | 10% – 30% |
| Final concentration (Brix) | Up to 70% |
| Operating temperature | 60°C – 120°C (depending on vacuum level) |
| Steam consumption | 0.3 – 0.5 kg steam per kg water evaporated (multi-effect) |
| Heating medium | Saturated steam (0.2 – 1.0 MPa) or thermal oil |
| Material of construction | SS304 / SS316L / Duplex (custom) |
Benefits for Your Business
- Reduced Energy Costs – The multi-effect heat recovery cuts steam consumption by up to 60%, directly lowering your operating expenses.
- Higher Product Quality – Gentle vacuum evaporation prevents thermal degradation, preserving color, flavor, and nutritional value.
- Increased Production Capacity – Continuous operation with automatic cleaning-in-place (CIP) options ensures minimal downtime.
- Easy Maintenance – Modular design with quick-access manholes and inspection windows simplifies cleaning and servicing.
- Compliance with International Standards – Our systems are manufactured under ISO9001, HACCP, and OHSAS18001 certified processes, ensuring safety and reliability.
Trust & Credibility
Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been a trusted partner for global clients since 2015. Our factory spans 10,000–30,000 m² with a dedicated team of 201–300 professionals. We export annually US$10–50 million to over 15 countries across North America, Europe, Africa, and Asia. Our products are certified under multiple quality management systems including ISO9001, HACCP, SA8000, and more. We provide comprehensive after-sales support, including installation guidance, commissioning, and remote troubleshooting. Choose Conqinphi for a reliable, customized evaporation solution that delivers measurable results.
Frequently Asked Questions
Q1: What is the typical lead time for a sugar concentration evaporation system?
Standard lead time is 60–90 days depending on capacity and complexity. Custom orders may require additional time. We will provide a detailed schedule upon inquiry.
Q2: Can the system handle high-viscosity sugar syrups?
Yes, we offer forced circulation and falling film configurations that are suitable for high-viscosity and fouling-prone liquids. Our engineering team will recommend the optimal design based on your product characteristics.
Q3: What is the minimum evaporation capacity available?
We can design systems as small as 500 kg/h for pilot plants or R&D, up to 50,000 kg/h for large-scale industrial production.
Q4: Do you provide installation and training services?
Yes, we offer on-site installation supervision, commissioning, and operator training. Remote support via video call is also available.
Q5: How do you ensure the system meets food safety standards?
All wetted parts are made of food-grade stainless steel with sanitary polishing. The system is designed for easy cleaning (CIP) and meets HACCP requirements. Our factory is ISO9001 and HACCP certified.
Q6: What is the warranty period?
We offer a standard 12-month warranty from the date of commissioning. Extended warranty options are available upon request.
Q7: Can the system be integrated with existing plant automation?
Yes, our PLC control system supports standard communication protocols (Modbus, Profibus, etc.) and can be integrated with your DCS or SCADA system.
Q8: Do you have references from sugar refineries?
Absolutely. We have supplied evaporation systems to multiple sugar refineries in Southeast Asia, South America, and Africa. References and case studies can be provided under NDA.
Contact us today for a customized proposal and technical consultation. Let Conqinphi help you achieve optimum concentration efficiency with minimal energy consumption.
