Welcome to Tianjin ZhuoLiNeng (ZLN) Technology Co., Ltd. – a professional manufacturer specializing in advanced water treatment solutions. Our RO Reverse Osmosis Membrane Filtration Equipment (220V, 1.5kW, 99.5% Salt Rejection, Automatic Operation) is designed to deliver high-efficiency desalination and purification for industrial, commercial, and municipal applications. With a salt rejection rate of up to 99.5%, this system ensures exceptional water quality, meeting stringent purity requirements. The automated control panel simplifies operation, reducing labor costs and human error, while the robust construction guarantees long-term reliability. Whether you need to treat brackish water, seawater, or process wastewater, our RO equipment offers a cost-effective and sustainable solution.
Product Features & Technical Specifications
- High Salt Rejection: 99.5% removal of dissolved salts, heavy metals, and contaminants, ensuring permeate water quality suitable for drinking, pharmaceutical, or industrial reuse.
- Automatic Operation: PLC-based control system with touch screen interface, enabling automatic start/stop, flush, and alarm functions. Minimal manual intervention required.
- Energy Efficiency: 1.5kW power consumption, optimized for low operating costs. Equipped with high-efficiency pump and energy recovery device (optional).
- Robust Construction: Frame made of stainless steel (304 or 316L) for corrosion resistance. Membrane housing rated for high pressure (up to 1000 psi).
- Compact Design: Skid-mounted unit saves floor space; easy to install and maintain. Preassembled and tested before shipment.
- Customizable Options: Flow rate, membrane type, pre-treatment (multimedia filter, carbon filter, softener), and post-treatment (UV, remineralization) can be tailored to your feed water and target quality.
- Durable Membrane Elements: Uses industry-leading thin-film composite (TFC) membranes, known for long service life and stable performance.
| Parameter | Specification |
| Model | ZLN-RO-220-1.5 |
| Rated Voltage | 220V AC, 50/60Hz |
| Rated Power | 1.5 kW |
| Salt Rejection Rate | ≥ 99.5% |
| Operating Pressure | 150–450 psi (adjustable) |
| Recovery Rate | 50%–75% (depending on feed water) |
| Membrane Quantity | 1–4 (customizable) |
| Feed Water TDS | ≤ 5000 ppm (higher with pre-treatment) |
| Permeate Flow | 0.5–2 m³/h (depending on configuration) |
| Dimensions (L×W×H) | 1200×800×1600 mm (approx.) |
| Weight | ~250 kg |
Key Benefits for Your Business
- Reduced water purchase costs – produce your own high-purity water on-site.
- Lower maintenance – automatic flush and cleaning cycles extend membrane life.
- Compliance with global water quality standards – suitable for food & beverage, pharmaceutical, electronics, and power generation industries.
- Scalable design – multiple units can be combined for higher capacity.
- Environmentally friendly – minimal chemical usage compared to conventional ion exchange.
Why Choose Tianjin ZLN Technology?
As a manufacturer based in Tianjin, China, we have over a decade of experience in water treatment equipment. We serve clients across North America, South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and domestic markets. Our products are shipped from Tianjin Port, ensuring fast and reliable logistics. Each RO system undergoes rigorous testing before delivery, and we offer comprehensive after-sales support, including technical documentation, spare parts, and remote troubleshooting. Our team of engineers can customize the system to match your specific feed water analysis and desired output. With a commitment to quality and innovation, ZLN is your trusted partner for sustainable water solutions.
Frequently Asked Questions (FAQ)
-
Q: What is the typical lifespan of the RO membrane?
A: Under normal operating conditions (proper pre-treatment and regular cleaning), the membrane can last 2–5 years. Our automatic flush function helps prolong membrane life. -
Q: Can this equipment handle seawater desalination?
A: The standard model is designed for brackish water with TDS up to 5000 ppm. For seawater desalination (TDS ~35,000 ppm), we recommend a high-pressure version with special membranes. Contact us for customization. -
Q: What is the required feed water pressure?
A: The system includes a built-in high-pressure pump, so the minimum feed water pressure is 0.2 MPa (2 bar). The pump will boost the pressure to the required level. -
Q: Is the system easy to install?
A: Yes, the unit is skid-mounted and pre-piped. You only need to connect feed water inlet, product water outlet, concentrate drain, and power supply. A detailed installation manual is provided. -
Q: Do you offer spare parts and after-sales support?
A: Absolutely. We provide replacement membranes, filters, O-rings, and other consumables. Our technical team is available via email, phone, or video call for troubleshooting. -
Q: Can I get a sample or test the system before ordering?
A: We can arrange a pilot test with your feed water at our factory, or provide a small-scale unit for trial. Please contact our sales team for details. -
Q: What is the warranty period?
A: Standard warranty is 12 months from the date of shipment. Extended warranty options are available upon request. -
Q: How do I choose the right model for my capacity?
A: We recommend providing your feed water quality report and required permeate flow (m³/h or GPD). Our engineers will design the optimal configuration for you.
Contact us today for a quotation or technical consultation. Tianjin ZhuoLiNeng Technology Co., Ltd. – your reliable partner in water purification. We look forward to serving you!
