Help CenterPLC Controlled Vacuum Evaporator-Crystallizer for High Efficiency 60°C Operation
Product Spotlights
Related Products
-
Reliable Rubber Additive Wastewater Treatment System With Mill Test Report and After-Sales ServiceUS$ 21500 - 877400MOQ: 1 Combo -
Vacuum Evaporator-Crystallizer With Mill Test Report and Standard Compliant QualityUS$ 5480 - 87900MOQ: 1 Combo
-
1 Year Warranty Vacuum Evaporator-Crystallizer With On-Site Commissioning and TrainingUS$ 5480 - 87900MOQ: 1 Combo
-
Vacuum Evaporator-Crystallizer for Chemical Industry Concentrating Sodium Sulfate SolutionUS$ 5480 - 87900MOQ: 1 Combo
-
1-Year Warranty Rubber Additive Wastewater Treatment System With Free Technical TrainingUS$ 21500 - 877400MOQ: 1 Combo
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – a trusted manufacturer with over 8 years of experience in designing and producing advanced environmental equipment. Our PLC Controlled Vacuum Evaporator-Crystallizer for High Efficiency 60°C Operation represents the pinnacle of low-temperature evaporation technology, specifically engineered to treat industrial wastewater with minimal energy consumption. By combining vacuum evaporation and crystallization in a single, automated unit, this system achieves up to 90% water recovery while converting dissolved solids into dry, manageable crystals. Whether you are dealing with RO concentrate, metal finishing wastewater, or chemical process streams, our evaporator-crystallizer offers a reliable, cost-effective solution for zero liquid discharge (ZLD) applications.
Built with precision and durability in mind, this equipment features a PLC-based control system that ensures consistent operation at a stable 60°C, significantly reducing scaling and fouling compared to traditional high-temperature evaporators. The vacuum environment lowers the boiling point of water, allowing evaporation to occur at a gentle 60°C – ideal for heat-sensitive liquids and reducing energy costs by up to 30%. Our unit is fully customizable to match your specific flow rate, space constraints, and automation requirements, making it a versatile choice for industries ranging from pharmaceuticals to food processing.
Key Features & Technical Specifications
- PLC Automation: Touch-screen interface with real-time monitoring of temperature, vacuum, feed rate, and crystal discharge. Full remote control capability via optional SCADA integration.
- Low-Temperature Operation (60°C): Minimizes energy consumption, reduces corrosion, and prevents thermal degradation of sensitive compounds. Ideal for heat-sensitive wastewater.
- Integrated Crystallization: Continuous or batch crystallization module produces dry, free-flowing crystals that can be collected and disposed of easily – reducing waste volume by up to 95%.
- High Efficiency Vacuum System: Multi-stage vacuum pump ensures stable operation under -0.08 to -0.095 MPa, achieving rapid evaporation rates.
- Corrosion-Resistant Construction: Main body made of SS304 or SS316L (optional), with PTFE-lined piping for aggressive chemicals. All wetted parts are fully compatible with acidic or alkaline streams.
- Energy Recovery Option: Optional heat pump or mechanical vapor recompression (MVR) module can further reduce operating costs by 40-60%.
- Compact Footprint: Skid-mounted design saves floor space – typical dimensions: 3m x 2m x 2.5m (for 100 L/h unit).
- Easy Maintenance: Modular design with quick-access covers for cleaning and inspection. Automatic CIP (clean-in-place) system available.
| Parameter | Specification |
|---|---|
| Model | CQ-VEC-60 (Customizable) |
| Evaporation Capacity | 50 – 500 L/h (per unit) |
| Operating Temperature | 60°C (adjustable ±5°C) |
| Vacuum Level | -0.085 MPa (typical) |
| Power Consumption | 15 – 45 kW (depending on capacity) |
| Heating Source | Steam (0.3-0.6 MPa) or Electric (optional) |
| Product Dimensions (L×W×H) | 3000×2000×2500 mm (base) |
| Control System | Siemens PLC + HMI Touch Screen |
| Material of Construction | SS304 / SS316L / Hastelloy (optional) |
Customer Benefits
- Reduced Operating Costs: Low-temperature operation cuts energy bills by up to 30% compared to conventional evaporators. The optional MVR module can further reduce steam consumption by 60%.
- Zero Liquid Discharge (ZLD) Compliance: Achieve near-total water recovery and solid waste minimization – perfect for meeting stringent environmental regulations.
- Minimal Maintenance: The 60°C operation significantly reduces scaling and fouling, extending cleaning intervals to 2-3 months. The PLC auto-diagnosis alerts you to potential issues before they cause downtime.
- Scalable & Flexible: Modular design allows easy expansion by adding more units. Customizable to handle different feed compositions (TDS up to 250,000 ppm).
- High-Quality Crystals: The integrated crystallizer produces dry, non-hazardous crystals that can be sold as by-products or disposed of at lower cost.
Trust & Reliability
As a manufacturer with a 10,000-30,000 m² factory and over 200 skilled employees, Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been delivering high-quality industrial equipment since 2015. Our annual export value exceeds US$10 million, serving customers across North America, South America, Europe, Asia, Africa, and Oceania. We are proud to operate under ISO9001, ISO14000, and OHSAS18001 certified management systems, ensuring every product meets rigorous quality and safety standards. Our engineering team provides comprehensive after-sales support, including installation guidance, commissioning, and remote troubleshooting.
Ready to optimize your wastewater treatment process? Contact us today for a customized solution tailored to your specific flow rate, space constraints, and budget. Our experts will provide a detailed proposal and a free consultation to help you achieve efficient, sustainable operation. Choose Conqinphi – your partner in environmental technology.
Frequently Asked Questions (FAQ)
-
Q: What types of wastewater can this evaporator-crystallizer handle?
A: It is suitable for high-salinity industrial wastewater, including RO concentrate, metal finishing rinse water, chemical process streams, pharmaceutical waste, and landfill leachate. The system can handle total dissolved solids (TDS) up to 250,000 ppm. For extremely corrosive fluids, we recommend optional Hastelloy or PTFE lining. -
Q: How does the 60°C operation benefit my process?
A: Operating at a low temperature (60°C) reduces energy consumption by up to 30% compared to traditional evaporators running at 100°C. It also minimizes scaling, corrosion, and thermal degradation, making it ideal for heat-sensitive liquids. The vacuum environment ensures efficient evaporation even at this low temperature. -
Q: Is the PLC control system easy to operate?
A: Yes, the system features a user-friendly touch-screen HMI with intuitive menus. Operators can monitor and adjust parameters such as feed rate, vacuum level, and temperature in real time. Remote monitoring and data logging are optional. We provide on-site training and detailed manuals. -
Q: What is the typical maintenance schedule?
A: Due to the low-temperature operation, cleaning intervals are typically 2-3 months. The system includes automatic draining and flushing ports. An optional CIP (clean-in-place) system can further reduce maintenance downtime. We recommend annual inspection of vacuum pumps and seals. -
Q: Can I customize the capacity or materials?
A: Absolutely. Our evaporator-crystallizers are modular and customizable. Standard capacities range from 50 L/h to 500 L/h per unit. Multiple units can be combined for higher throughput. Material options include SS304, SS316L, Hastelloy, and duplex stainless steel. We also offer different heating methods (steam, electric, or thermal oil). -
Q: What certifications does the equipment comply with?
A: Our products are manufactured in an ISO9001, ISO14000, and OHSAS18001 certified facility. We can also provide CE, ATEX, or other certifications upon request (subject to verification). The control panel meets UL/CE standards depending on the destination. -
Q: How long does the delivery take?
A: Typically, lead time is 30-45 days after order confirmation, depending on customization complexity. We offer expedited shipping for standard models. All equipment is shipped from our Qingdao port (China) with proper export packaging. -
Q: What after-sales support do you provide?
A: We provide full technical support, including installation guidance, commissioning, and operator training. Our team offers remote troubleshooting via video call and a 12-month warranty on parts. Spare parts are available for quick shipment.
