Automatic Multi-effect Evaporation Crystallization System, 304 SS, PLC Control, Standard Compliant
Product Spotlights
Multi-effect evaporation crystallization system with 304 SS construction and PLC automatic control. High energy efficiency, customizable capacity, integrated crystallization for ZLD or resource recovery. Compliant with international standards, backed by a certified manufacturer with global export experience.
US$ 218000 - 664900
MOQ: 1 Combo
Key Specifications
Get Latest Price
Material:
304 Stainless Steel
Control Type:
PLC Automatic
Operation Mode:
Multi-effect Evaporation + Crystallization
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
50 days
Related Products
-
Industrial Multi-effect Evaporation Crystallization System, 500kg/h, Automatic, 304 Stainless SteelUS$ 218000 - 664900MOQ: 1 Combo -
Touch Screen PLC Controlled Multi-effect Evaporation Crystallization System, 316L Stainless SteelUS$ 218000 - 664900MOQ: 1 Combo
-
Multi-effect Evaporation Crystallization System for Pharmaceutical Industry With CIP/SIP DesignUS$ 218000 - 664900MOQ: 1 Combo
-
Multi-effect Evaporation Crystallization System With 1 Year Warranty and Factory Direct SupportUS$ 218000 - 664900MOQ: 1 Combo
-
Multi-effect Evaporation Crystallization System With Free Installation and Technical TrainingUS$ 218000 - 664900MOQ: 1 Combo
Material
304 Stainless Steel
Control Type
PLC Automatic
Operation Mode
Multi-effect Evaporation + Crystallization
Application
Wastewater Treatment, Chemical Processing
Capacity
Customizable (100-5000 L/h)
Voltage
380V/415V/220V (Customizable)
Power
Customizable
Standard Compliance
International Industry Standards
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – a professional manufacturer specializing in advanced evaporation and crystallization solutions since 2015. Our Automatic Multi-effect Evaporation Crystallization System is designed to deliver high-efficiency concentration and salt recovery for industrial wastewater and process liquids. Built with 304 stainless steel and equipped with PLC control, this system offers reliable automation, energy savings, and consistent output quality. Whether you need zero liquid discharge or valuable byproduct recovery, our equipment provides a robust and compliant solution.
Key Features & Technical Specifications
- Multi-effect evaporation design – maximize energy efficiency by reusing vapor from the previous effect, reducing steam consumption by up to 60% compared to single-effect systems.
- 304 stainless steel construction – excellent corrosion resistance for handling acidic, alkaline, or saline feed streams; long service life and easy cleaning.
- PLC automatic control – touch-screen interface monitors temperature, pressure, flow rate, and liquid level in real time; automatic start/stop, alarm, and data logging.
- Crystallization function – integrated forced circulation or fluidized bed crystallizer produces separable solid salts, enabling zero liquid discharge (ZLD) or resource recovery.
- Standard compliant design – meets international safety and performance standards; customizable to local regulations.
- Modular and compact footprint – skid-mounted or containerized options for easy installation and maintenance.
| Parameter | Typical Range | Notes |
|---|---|---|
| Evaporation capacity | 100 – 5000 L/h | Customizable based on feed concentration |
| Number of effects | 2 – 7 effects | More effects = higher energy efficiency |
| Operating temperature | 40 – 120 °C | Adjustable per application |
| Material of construction | 304 SS (316L optional) | Higher grades available for aggressive media |
| Control system | PLC + HMI touch screen | Remote monitoring optional |
Advantages & Benefits for Your Business
- Reduced operating costs – multi-effect design significantly lowers steam and cooling water consumption; PLC automation minimizes labor and human error.
- Higher product purity – precise control of evaporation and crystallization parameters yields consistent crystal size and high purity salts, suitable for reuse or sale.
- Environmentally friendly – enables zero liquid discharge (ZLD) or near-ZLD, helping you meet stringent environmental regulations and reduce wastewater disposal fees.
- Flexible customization – we tailor the system to your specific feed composition, target concentration, and space constraints; options include CIP, anti-fouling coatings, and explosion-proof design.
- Robust after-sales support – our team of 200+ engineers provides installation supervision, commissioning, training, and remote troubleshooting.
Frequently Asked Questions
-
What types of wastewater can this system handle?
It is suitable for high-salinity, high-COD, or acidic/alkaline streams such as landfill leachate, chemical industry effluents, desulfurization wastewater, and brine from RO systems. Please provide a water analysis for a customized recommendation. -
How does the crystallization process work?
The system concentrates the solution until supersaturation, then crystals form in the integrated crystallizer. A forced circulation loop ensures uniform crystal growth. The slurry is then discharged and separated by a centrifuge or filter. -
What is the typical energy consumption?
With 3 effects, steam consumption is about 0.4–0.5 kg steam per kg of water evaporated. For 5 effects, this drops to 0.25–0.3 kg. Electricity consumption is mainly for pumps and control system, typically 10–30 kWh per ton of evaporation. -
Can I use this system for non-aqueous solvents?
Yes, but please inform us about the solvent properties. The standard 304 SS may not be compatible with certain solvents; we can upgrade to 316L or other alloys, and adjust seals and gaskets accordingly. -
What maintenance is required?
Regular inspection of seals, gaskets, and pumps; periodic cleaning of heat transfer surfaces (CIP system optional). Our PLC logs maintenance reminders. Annual professional service recommended. -
How long does delivery take?
Lead time depends on size and customization level. Typically 45–90 days after order confirmation. We provide project timeline updates during manufacturing. -
Does the system comply with international standards?
Yes, our design follows ASME, PED, GB150, and relevant safety codes. We can also certify to specific standards requested by your region. Our factory holds ISO9001, ISO14001, and OHSAS18001 certifications. -
Can I integrate it with my existing plant?
Absolutely. Our engineers will conduct a site survey and provide piping and electrical integration solutions. We also offer remote monitoring via SCADA/DCS integration.
Trusted by global clients – With a factory area of 10,000–30,000 m², over 200 employees, and annual export value exceeding US$10 million, Qingdao Conqinphi Environmental Technology Group has delivered evaporation and crystallization systems to North America, Europe, Southeast Asia, Africa, and the Middle East. Our products are backed by certifications including ISO9001, ISO14001, OHSAS18001, and others. We are committed to providing reliable, energy-saving, and compliant solutions for your challenging liquid treatment needs. Contact us today to discuss your project and request a free quotation or technical proposal.
