Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd., a leading manufacturer with over 10 years of experience in wastewater treatment and evaporation systems. Our 1 Year Warranty Vacuum Evaporator-Crystallizer is designed to deliver reliable, high-efficiency concentration and crystallization of industrial wastewater, ensuring zero liquid discharge (ZLD) while recovering valuable by-products. With on-site commissioning and training included, you can be confident that your team will operate the system safely and effectively from day one.
This advanced evaporator-crystallizer combines vacuum evaporation technology with forced circulation crystallization, enabling the treatment of high-salinity, high-hardness, and corrosive waste streams. The system operates under reduced pressure to lower the boiling point of the liquid, significantly reducing energy consumption compared to atmospheric evaporators. The crystallizer section then separates pure crystals from the concentrated brine, achieving a solid waste that is easy to handle or reuse.
Key Features & Technical Specifications
- Energy-Efficient Vacuum Operation – Operates at 40-80°C, reducing steam or electricity consumption by up to 30% compared to traditional evaporators.
- High Recovery Rate – Achieves over 95% water recovery, with the crystallizer producing dry, free-flowing crystals.
- Robust Construction – Made from high-grade stainless steel (SS304/SS316L) or other corrosion-resistant alloys, ensuring long service life even in aggressive chemical environments.
- Fully Automatic Control – PLC-based system with HMI touch screen allows for real-time monitoring, alarm management, and remote operation.
- Low Maintenance Design – Anti-scaling and anti-fouling features reduce cleaning frequency; all components are accessible for easy service.
- Customizable Capacity – Available in various sizes from 200 L/h to 20,000 L/h, tailored to your specific flow rate and concentration requirements.
| Parameter | Specification |
|---|---|
| Operating Temperature | 40-80°C (adjustable) |
| Vacuum Degree | -0.08 to -0.095 MPa |
| Evaporation Capacity | 200-20,000 L/h (custom) |
| Crystal Purity | ≥95% |
| Power Consumption | 0.5-1.5 kWh per liter of water evaporated |
| Heating Source | Steam, thermal oil, or electricity (optional) |
| Cooling Water Consumption | 0.5-1.5 m³/h (depending on capacity) |
Benefits for Your Business
- Reduce Waste Disposal Costs – By converting liquid waste into dry solids, you minimize the volume of waste sent to landfills or deep well injection, saving up to 70% on disposal fees.
- Recover Valuable Resources – The crystallizer can recover high-purity salts (e.g., NaCl, Na₂SO₄, NH₄Cl) that can be reused in industrial processes or sold as by-products.
- Comply with Environmental Regulations – Achieve zero liquid discharge (ZLD) standards, avoiding fines and meeting strict discharge permits.
- Easy Operation & Training – Our team provides on-site commissioning and thorough training for your operators, ensuring smooth startup and long-term performance.
- Peace of Mind with 1-Year Warranty – All components are covered by a comprehensive warranty, with replacement parts available from our global warehouse.
Why Choose Qingdao Conqinphi Environmental Technology?
Founded in 2015, we have grown into a ISO9001 and HACCP certified manufacturer with a factory spanning 10,000-30,000 sqm. Our team of 201-300 employees includes over 50 R&D engineers dedicated to continuous innovation. With an annual export value exceeding US$10 million, we have supplied our evaporation systems to clients in North America, Europe, Southeast Asia, Africa, and the Middle East. Our main markets cover all major continents, and we have a proven track record of delivering reliable, custom-engineered solutions for challenging wastewater streams.
Every unit undergoes rigorous quality testing before shipment, and we offer lifetime technical support. Our on-site commissioning service ensures that your system is installed correctly and optimized for your specific conditions. The included training program covers operation, maintenance, troubleshooting, and safety procedures, empowering your team to achieve maximum uptime and efficiency.
Contact us today to discuss your project requirements. Our sales engineers will provide a free process design and quotation tailored to your wastewater characteristics. With the 1-Year Warranty and dedicated after-sales support, you can invest with confidence in a sustainable solution.
Frequently Asked Questions (FAQ)
-
What types of wastewater can this evaporator-crystallizer handle?
It is suitable for high-salinity brines, RO concentrates, industrial effluents from chemical, pharmaceutical, textile, food processing, and mining industries. The system can handle solutions with high TDS, hardness, and corrosive components. Please provide a water analysis for a customized recommendation. -
How long does the on-site commissioning take?
Typically 5-10 working days, depending on the system size and site conditions. Our engineers will also train your operators for 2-3 days during the commissioning period. -
What is the energy consumption?
Energy consumption varies based on capacity and heating source. For a typical steam-driven system, the steam consumption is about 0.4-0.6 kg per kg of water evaporated. For electric heating, the power consumption is approximately 0.8-1.5 kWh per liter. We can provide energy recovery options to further reduce costs. -
Do you offer customization for different crystal sizes?
Yes, the crystallizer design can be adjusted to produce specific crystal size distribution by controlling the supersaturation, residence time, and agitation. Our process engineers can optimize the system for your target crystal quality. -
What is the maintenance requirement?
Routine maintenance includes periodic cleaning of heat exchanger surfaces, inspection of vacuum pumps, and replacement of seals. The system is designed with easy access points. We provide a detailed maintenance manual and spare parts list. -
How does the 1-year warranty work?
The warranty covers all manufacturing defects for 12 months from the date of commissioning. It includes free replacement of faulty parts (excluding consumables) and remote technical support. Extended warranty options are available. -
Can this system achieve zero liquid discharge?
Yes, combined with a pre-treatment step (if needed), the evaporator-crystallizer can achieve ZLD by evaporating all water and producing dry solids. The condensate water can be reused in your process. -
What is the delivery time?
Standard units: 30-45 days. Custom systems: 45-60 days, depending on complexity. We can also arrange expedited shipping for urgent projects.
