Help Center304 Stainless Steel Vacuum Evaporator-Crystallizer With 0.1MPa Vacuum Degree
Product Spotlights
Related Products
-
Semi-Automatic Vacuum Evaporator-Crystallizer 200L/h Capacity 316L MaterialUS$ 5480 - 87900MOQ: 1 Combo -
220V 380V Industrial Vacuum Evaporator-Crystallizer With 0.5m³/h Evaporation RateUS$ 5480 - 87900MOQ: 1 Combo
-
Vacuum Evaporator-Crystallizer With 10kW Heating Power and Automatic DischargeUS$ 5480 - 87900MOQ: 1 Combo
-
Pharmaceutical Grade Vacuum Evaporator-Crystallizer for API Recovery and Wastewater TreatmentUS$ 5480 - 87900MOQ: 1 Combo
-
Automatic Vacuum Evaporator-Crystallizer 304 Stainless Steel PLC Control 100L CapacityUS$ 5480 - 87900MOQ: 1 Combo
Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015, is a professional manufacturer specializing in environmental and chemical equipment. With a factory area of 10,000-30,000 square meters and over 200 skilled employees, we have been exporting to more than 20 countries and regions worldwide, with an annual export value exceeding US$10 million. Our 304 Stainless Steel Vacuum Evaporator-Crystallizer with 0.1MPa Vacuum Degree is designed to meet the demanding needs of evaporation and crystallization processes in the chemical, pharmaceutical, and food industries. This equipment combines robust construction with advanced vacuum technology to achieve efficient separation and concentration of solutions, ensuring high purity and minimal energy consumption.
Built entirely from 304 stainless steel, the evaporator-crystallizer offers excellent corrosion resistance and durability, making it suitable for handling aggressive media. The vacuum system maintains a stable 0.1 MPa vacuum degree, which lowers the boiling point of liquids, allowing gentle evaporation at lower temperatures to preserve heat-sensitive materials. The integrated crystallizer design facilitates the formation of crystals under controlled conditions, providing consistent particle size and high yield. Our equipment is widely used in the recovery of solvents, concentration of solutions, and crystallization of salts, acids, and other chemical products.
Key Features & Technical Specifications
- High-Quality 304 Stainless Steel: All wetted parts are made of 304 stainless steel, ensuring long service life and easy cleaning.
- 0.1MPa Vacuum Degree: Achieves efficient evaporation at low temperatures, reducing thermal degradation of products.
- Integrated Evaporation and Crystallization: Combines two processes in one unit, saving space and operational costs.
- Customizable Capacity: Available in standard sizes from 50L to 5000L, with custom configurations upon request.
- User-Friendly Control: Optional PLC touch screen interface for precise monitoring of temperature, pressure, and flow rate.
- Energy-Efficient Design: Optimized heat transfer surfaces and insulation reduce energy consumption.
- Compliance with International Standards: Manufactured in accordance with ISO9001, ISO14000, and OHSAS18001 quality management systems.
| Parameter | Specification |
|---|---|
| Material | 304 Stainless Steel |
| Vacuum Degree | 0.1 MPa (absolute) |
| Working Temperature | ≤ 150°C (adjustable) |
| Evaporation Capacity | Customizable (e.g., 100 L/h, 500 L/h) |
| Power Supply | 380V / 220V, 50/60 Hz (3-phase) |
| Control System | Manual or PLC Touch Screen (optional) |
| Installation | Skid-mounted / Floor-standing |
The 304 Stainless Steel Vacuum Evaporator-Crystallizer offers significant advantages for your production line. By operating under vacuum, it reduces the boiling point of solvents, which minimizes energy consumption and protects heat-sensitive compounds. The crystallizer section ensures that the concentrated solution forms uniform crystals, which can be easily separated and dried. This combination results in higher product purity and reduced waste. Whether you are concentrating pharmaceutical intermediates, recovering valuable solvents, or producing crystalline salts, this equipment delivers consistent performance with minimal maintenance.
Frequently Asked Questions (FAQ)
1. What is the maximum operating temperature of the evaporator-crystallizer?
The standard design allows working temperatures up to 150°C. For higher temperature requirements, we can customize the unit with appropriate materials and insulation.
2. Can this equipment handle corrosive chemicals?
Yes, the 304 stainless steel construction provides excellent resistance to a wide range of corrosive media, including acids, alkalis, and salt solutions. For extremely aggressive chemicals, we recommend upgrading to 316L stainless steel (available upon request).
3. What is the typical evaporation capacity?
The capacity depends on the model and specific process conditions. Standard capacities range from 50 L/h to 5000 L/h. We can design a custom system based on your requirements.
4. Does the equipment come with a vacuum pump?
The vacuum pump is usually sold separately, but we can provide a complete package including a vacuum pump, condenser, and receiver. Please contact our sales team for a tailored solution.
5. How is the crystallization process controlled?
The crystallization can be controlled by adjusting the cooling rate, agitation speed, and vacuum level. Our optional PLC system allows precise regulation of these parameters for consistent crystal size and morphology.
6. What certifications does your company hold?
Our manufacturing facilities are certified under ISO9001, ISO14000, OHSAS18001, and other international standards such as HACCP, TL900, and SA8000. We comply with strict quality control procedures.
7. Do you provide installation and after-sales support?
Yes, we offer on-site installation guidance, commissioning, and training. Our technical team is available for remote support throughout the warranty period and beyond. We also provide spare parts supply.
8. What is the lead time for delivery?
Standard models typically ship within 30-45 days after order confirmation. Customized designs may require 60-90 days depending on complexity. We can expedite for urgent orders upon request.
As a trusted manufacturer with over 8 years of experience, Qingdao Conqinphi Environmental Technology Group Co., Ltd. has supplied evaporator-crystallizers to clients across North America, South America, Europe, Africa, and Asia. Our factory, spanning 10,000-30,000 square meters, is equipped with advanced welding and machining facilities. We have a dedicated R&D department that continuously improves our product designs. With an annual export value of US$10 million to US$50 million, we have proven our ability to deliver high-quality equipment on time. We are confident that our 304 Stainless Steel Vacuum Evaporator-Crystallizer will exceed your expectations in terms of performance, durability, and cost-effectiveness. Contact us today for a quotation or technical consultation – we look forward to partnering with you!
