Anping County Boli Hardware Wiremesh Products Factory, established in 1998 with an annual export value of US$5–10 million, presents this Compact Stainless Steel Oil Cooler Unit designed for reliable heat dissipation in demanding industrial environments. Engineered with a 220V 0.5kW fan motor and 50Hz frequency, this unit delivers efficient cooling for hydraulic oils, lubricants, and other fluids while maintaining a compact footprint. Our decades of manufacturing expertise and global export experience to markets across North America, South America, Europe, Asia, and Africa ensure that every unit meets rigorous quality standards.
This oil cooler is built with a stainless steel core and housing, offering exceptional corrosion resistance and durability even in harsh conditions. The integrated fan motor provides forced air circulation, enhancing heat transfer and maintaining stable operating temperatures. Whether used in hydraulic power units, industrial machinery, or lubrication systems, this unit helps extend equipment life and reduce downtime.
Key Features & Technical Specifications
- Stainless Steel Construction: Resists rust, corrosion, and chemical attack, ideal for long-term use in oil cooling applications.
- 220V 0.5kW Fan Motor: Provides adequate airflow for efficient heat dissipation while maintaining low noise levels.
- 50Hz Frequency: Optimized for regions with 50Hz power supply; 60Hz versions are available upon request.
- Compact Design: Space-saving dimensions allow easy integration into existing systems or tight spaces.
- Easy Installation: Standard inlet/outlet ports and mounting brackets simplify setup.
- Low Maintenance: Sealed fan motor and durable fins reduce the need for frequent servicing.
| Parameter | Value |
| Material | Stainless Steel (304/316 optional) |
| Rated Voltage | 220V AC |
| Motor Power | 0.5 kW (0.67 HP) |
| Frequency | 50 Hz (60 Hz available) |
| Cooling Capacity | Up to 5 kW (depending on oil flow and temperature difference) |
| Max Oil Flow Rate | 30 L/min |
| Max Operating Pressure | 1.5 MPa (15 bar) |
| Noise Level | < 55 dB(A) |
| Dimensions (L x W x H) | 400 x 200 x 250 mm (customizable) |
Benefits for Your Operations: By maintaining optimal oil temperature, this cooler prevents thermal degradation of lubricants, reduces wear on seals and components, and improves overall system efficiency. The stainless steel construction ensures long service life even in humid or corrosive environments, while the compact size leaves room for other equipment. With the 0.5kW fan motor, it delivers consistent airflow without excessive power consumption.
Frequently Asked Questions (FAQ)
-
What types of oil can this cooler handle?
It is suitable for hydraulic oils, lubricating oils, gear oils, and other industrial fluids with viscosity up to 100 cSt. For high-viscosity applications, please consult our technical team. -
Can this unit work with a 60Hz power supply?
Yes, we offer a 60Hz version. Please specify your requirement when ordering, and we will adjust the motor accordingly. -
What is the maximum ambient temperature for operation?
This cooler is designed to operate in ambient temperatures from -20°C to 50°C. For extreme conditions, we recommend additional protection. -
Is the stainless steel grade 304 or 316?
Standard is grade 304. Grade 316 is available as an option for enhanced corrosion resistance, especially in marine or chemical environments. -
How do I install the oil cooler?
Mount the unit using the provided brackets and connect the oil inlet/outlet to your system. Ensure proper airflow around the fan. Detailed installation instructions are included. -
Does the motor require any maintenance?
The fan motor is sealed and maintenance-free under normal conditions. Periodic cleaning of the cooling fins is recommended to maintain efficiency. -
Can I get a custom size or cooling capacity?
Absolutely. We offer customization options for dimensions, cooling capacity, and port configurations. Contact us with your requirements. -
What is the warranty period?
We provide a 12-month warranty against manufacturing defects. Extended warranty options are available upon request.
Why Choose Anping County Boli Hardware Wiremesh Products Factory? With over 25 years of manufacturing experience (since 1998), we have supplied reliable cooling solutions to clients across the globe, including North America, South America, Europe, Oceania, and Asia. Our annual export value of US$5–10 million reflects our commitment to quality and customer satisfaction. We ship from major ports: Tianjin, Qingdao, Shanghai, and Foshan, ensuring timely delivery. Every oil cooler unit undergoes strict quality control before shipment. We are confident that our Compact Stainless Steel Oil Cooler will meet your performance expectations. Contact us today for a quote or to discuss your specific cooling needs.
