Help CenterChemical Industry Pipeline Plate Heat Exchanger for Acid Cooling, 316L, PN10
Product Spotlights
Related Products
-
Factory Direct Pipeline Plate Heat Exchanger With Free Technical Support and Installation GuideNegotiableMOQ: 1 Piece -
Plate Heat Exchanger for Pipeline 10m² Heat Transfer Area, 1.6MPa Working PressureNegotiableMOQ: 1 Piece
-
Pipeline Plate Heat Exchanger With Gasket Design, 304 SS, 0.5mm Plate Thickness, NPTNegotiableMOQ: 1 Piece
-
2-Year Warranty Pipeline Plate Heat Exchanger With Mill Test Report and MTCNegotiableMOQ: 1 Piece
-
Compact Pipeline Plate Heat Exchanger 50kW Capacity, 8m² Area, Standard CompliantNegotiableMOQ: 1 Piece
As a trusted manufacturer since 1998, Anping County Boli Hardware Wiremesh Products Factory offers the Chemical Industry Pipeline Plate Heat Exchanger for Acid Cooling, 316L, PN10 — a robust solution designed for demanding acid cooling processes in chemical plants. Our factory, located in Hengshui, Hebei, China, has over 25 years of experience in metal fabrication, and we export annually between US$5–10 million to markets worldwide including North America, Europe, and Southeast Asia. This heat exchanger leverages 316L stainless steel to resist corrosion from aggressive acids, while the PN10 rating ensures reliable performance under moderate pressure. We pride ourselves on delivering customized, high-quality industrial equipment that meets the exact needs of our clients.
Key Features & Technical Specifications
- Superior Corrosion Resistance: 316L stainless steel provides excellent resistance to sulfuric acid, hydrochloric acid, and other corrosive chemicals, extending service life in harsh environments.
- High Thermal Efficiency: Plate design with corrugated channels maximizes heat transfer area, achieving up to 5 times higher efficiency than shell-and-tube exchangers.
- Compact & Space-Saving: The pipeline plate configuration reduces footprint, making it ideal for retrofit projects or limited-space installations.
- Modular Design: Plates can be added or removed to adjust capacity, offering flexibility for changing process requirements.
- Easy Maintenance: Gasketed plates allow quick disassembly for cleaning or inspection, minimizing downtime.
- PN10 Pressure Rating: Designed for 10 bar (145 psi) operating pressure, suitable for many chemical process loops.
- Customizable Connections: Available with flanged or threaded connections to match your existing piping system.
- Gasket Options: Choose from EPDM, Viton, or PTFE gaskets based on temperature and chemical compatibility.
Technical Parameters (Typical)
| Parameter | Value |
| Material | 316L Stainless Steel |
| Design Pressure | PN10 (10 bar) |
| Design Temperature | -20°C to +200°C (depends on gasket) |
| Plate Thickness | 0.4 mm – 0.8 mm (optional) |
| Heat Transfer Area | Customizable (e.g., 1–500 m²) |
| Connection Size | DN25 – DN200 (or custom) |
| Gasket Material | EPDM, Viton, or PTFE |
Benefits for Your Application
- Reduced Operating Costs: Higher heat transfer efficiency lowers energy consumption and pumping costs.
- Extended Equipment Life: 316L material resists pitting and crevice corrosion, reducing replacement frequency.
- Faster Payback: Compact design and easy maintenance lead to lower total cost of ownership.
- Process Reliability: PN10 rating ensures steady operation under moderate pressure fluctuations.
- Global Compatibility: We ship from Tianjin, Qingdao, Shanghai, and other ports, meeting international standards.
Why Choose Anping Boli?
With a factory established in 1998, we have cultivated deep expertise in metal processing and heat exchanger manufacturing. Our annual export value of US$5–10 million reflects strong trust from clients across North America, South America, Europe, Asia, Africa, and Oceania. We serve 15+ markets, including the domestic Chinese market. Every unit undergoes strict quality control to ensure dimensional accuracy and leak-tightness. Furthermore, we offer customization options — from plate count to connection type — so you get exactly what your process needs. We are not just a supplier; we are your long-term partner in chemical processing.
Frequently Asked Questions
Q1: Can this heat exchanger handle concentrated sulfuric acid?
A: Yes, 316L stainless steel is suitable for dilute sulfuric acid at moderate temperatures. For highly concentrated or hot sulfuric acid, please consult our engineers for gasket and material compatibility advice.
Q2: What is the maximum plate count available?
A: The plate count can be customized based on your heat transfer area requirement. Typically, we offer from 5 plates up to 400 plates in a single frame. Contact us for your specific design.
Q3: Do you provide pressure testing certificates?
A: Yes, we can provide a hydrostatic pressure test certificate upon request. Each unit is tested before shipment.
Q4: What gasket material is recommended for hydrochloric acid cooling?
A: For hydrochloric acid, PTFE or Viton gaskets are recommended due to their excellent chemical resistance. EPDM is not suitable for strong acids.
Q5: Can the heat exchanger be used for both heating and cooling?
A: Yes, the same design can be used for both heating and cooling applications by reversing the flow direction. The plates are symmetrical.
Q6: What is the typical lead time?
A: Lead time depends on the size and customization. Standard models take 15–25 working days; customized orders may take 30–40 days. We ship from multiple Chinese ports.
Q7: Do you offer after-sales support?
A: Absolutely. We provide technical documentation, installation guidance, and spare parts support. Our team can assist with troubleshooting via email or video call.
Q8: Is the PN10 rating suitable for fluctuating pressure?
A: The PN10 design covers a maximum allowable working pressure of 10 bar at ambient temperature. For pressure surges, we recommend installing a pressure relief valve. Our engineers can advise on suitable safety margins.
Ready to optimize your acid cooling process? Contact Anping Boli today for a quote or technical consultation. With our 25+ years of manufacturing experience and global shipping network, we deliver solutions that work.
