Help CenterSintered Copper Powder Filter Element 10 Micron 200°C 2" Flange ASME Standard
Product Spotlights
Related Products
-
Sintered Copper Powder Filter Element 0.5 Micron 3000 PSI 316L Stainless Steel End CapsNegotiableMOQ: 1 Piece -
Sintered Copper Powder Filter Element for Oil and Gas Industry Fluid FiltrationNegotiableMOQ: 1 Piece
-
High Capacity Sintered Copper Powder Filter Cartridge, 20 Micron Nominal, 200°C Max Operating TemperatureNegotiableMOQ: 1 Piece
-
Sintered Copper Powder Filter Cartridge With Factory Warranty, Mill Test Report Included, Standard CompliantNegotiableMOQ: 1 Piece
-
Sintered Copper Powder Filter Cartridge Used in Pharmaceutical Industry for Sterile Filtration, 0.2 MicronNegotiableMOQ: 1 Piece
As a trusted manufacturer with over 25 years of experience, Anping County Boli Hardware Wiremesh Products Factory (established 1998) offers a high-performance Sintered Copper Powder Filter Element designed for demanding industrial filtration applications. With an annual export value exceeding US$5 million and serving markets across North America, Europe, and Asia, we bring expertise and reliability to every product. This 10 micron filter element, rated for 200°C and featuring a 2-inch flange conforming to ASME standards, delivers exceptional durability and efficiency in liquid and gas filtration.
Our sintered copper powder filter elements are manufactured using advanced powder metallurgy technology, creating a uniform porous structure that ensures consistent filtration performance. The 10 micron rating effectively removes fine particulates while maintaining high flow rates, making it ideal for applications in chemical processing, petrochemical, water treatment, and food & beverage industries. The 200°C temperature tolerance allows operation in hot fluid streams without degradation.
The 2-inch flange connection, designed to ASME standards, provides easy installation and a secure seal in existing piping systems. Unlike disposable filters, this sintered element can be cleaned and reused multiple times through backwashing or ultrasonic cleaning, significantly reducing operational costs and waste. The copper material offers excellent thermal conductivity and corrosion resistance in many environments.
Key Technical Specifications
| Parameter | Value |
| Filtration Grade | 10 Micron (absolute) |
| Maximum Operating Temperature | 200°C (392°F) |
| Connection Type | 2-inch Flange (ASME B16.5) |
| Material | Sintered Copper Powder |
| Porosity | 30% – 50% (customizable) |
| Pressure Drop | Low, depends on flow rate |
| Cleaning Method | Backwash, ultrasonic, or chemical |
Product Features & Benefits
- High precision filtration: 10 micron absolute rating ensures removal of fine particles, protecting downstream equipment and improving product purity.
- Temperature resistance: Rated for continuous operation up to 200°C, suitable for hot process streams.
- ASME standard flange: 2-inch flange design complies with ASME B16.5, enabling direct replacement in existing systems.
- Reusable & cost-effective: Sintered structure allows multiple cleaning cycles, extending service life and reducing replacement costs.
- Corrosion resistance: Copper material offers good resistance to many chemicals and environments.
- High mechanical strength: Sintered powder construction provides structural integrity even under high differential pressure.
- Customizable dimensions: Available in various lengths, diameters, and flange configurations upon request.
- Eco-friendly: Reduces waste compared to disposable filter cartridges.
Applications
This filter element is widely used in:
- Chemical and petrochemical processes
- Oil and gas filtration
- Water and wastewater treatment
- Food and beverage processing
- Pharmaceutical manufacturing
- Hydraulic and lubrication systems
- Gas filtration (steam, compressed air, etc.)
Why Choose Anping County Boli Hardware Wiremesh Products Factory?
Since 1998, we have been a dedicated manufacturer of wire mesh and sintered filter products. Our annual export value of US$5–10 million demonstrates our global reach and consistent quality. We ship from major ports including Tianjin, Qingdao, and Shanghai, ensuring timely delivery to customers worldwide. Our main markets cover North America, South America, Europe, Southeast Asia, Africa, and Oceania. We are committed to providing reliable filtration solutions backed by decades of engineering experience.
Each filter element undergoes strict quality control to ensure dimensional accuracy, filtration performance, and pressure integrity. We offer customization options including different micron ratings, flange sizes, and overall dimensions to meet specific system requirements. Contact us today for a quote or technical consultation.
Frequently Asked Questions (FAQ)
Q1: What is the maximum pressure rating for this filter element?
The pressure rating depends on the specific design and operating conditions. Typically, sintered copper powder filter elements can withstand up to 10–20 bar (150–300 psi) at room temperature. Please provide your system parameters for a precise recommendation.
Q2: Can this filter be cleaned and reused?
Yes, the sintered structure allows cleaning via backwashing, ultrasonic cleaning, or chemical cleaning. The element can be reused many times, making it a cost-effective solution compared to disposable filters.
Q3: Is the flange compatible with other standards like DIN or JIS?
This model is designed to ASME B16.5 Class 150. We also offer flanges according to DIN, JIS, or other standards as custom options. Please specify your requirement when ordering.
Q4: What is the typical flow rate for a 10 micron element?
Flow rate depends on the element size, viscosity of the fluid, and pressure drop. For water at 20°C, a standard 10-inch element can handle approximately 5–15 L/min. We can provide detailed flow curves based on your application.
Q5: Can this filter be used for aggressive chemicals?
Copper has good resistance to many chemicals but is not suitable for strong acids or oxidizing agents. Please consult our technical team for chemical compatibility analysis.
Q6: What are the available dimensions for this filter element?
Standard lengths include 10, 20, 30, and 40 inches, with outer diameters from 60mm to 100mm. The 2-inch flange is standard, but we can customize dimensions to fit your housing. Contact us for non-standard sizes.
Q7: How is the filter element packaged for shipping?
Each element is individually wrapped in protective material to prevent damage during transit. We use export-grade packaging with sturdy cartons or wooden crates as required.
Q8: What is the lead time for bulk orders?
Typical lead time is 15–25 working days after order confirmation, depending on quantity and customization. We maintain a certain inventory for standard models to ensure fast delivery.
