Help CenterSteel Grating Used for Drainage Trench Cover in Chemical Plant 250mm Width 3m Span
Product Spotlights
Related Products
-
Heavy Duty Steel Grating Load Rating 6.0kN/m2 50x5mm Bar 100mm Center for WarehouseNegotiableMOQ: 50 Cubic Centimeters -
Steel Grating Stair Tread 25x5mm Serrated Surface With 100mm Nosing for Industrial PlatformNegotiableMOQ: 50 Cubic Centimeters
-
Steel Grating With 1 Year Warranty and Mill Test Report for Material Grade VerificationNegotiableMOQ: 50 Cubic Centimeters
-
Steel Grating Compliant With ASTM A36 and Supplied With Free Sample for Quality CheckNegotiableMOQ: 50 Cubic Centimeters
-
Carbon Steel Steel Grating Serrated Surface 25x5mm 40x100mm Load 2 TonNegotiableMOQ: 50 Acres
As a leading manufacturer from Anping Xinye Metal Wire Mesh Products Co., Ltd in Hengshui, Hebei, China, we specialize in producing high-quality steel gratings for demanding industrial environments. Our Steel Grating Used for Drainage Trench Cover in Chemical Plant (250mm width, 3m span) is engineered to provide reliable, long-lasting performance under heavy loads and corrosive conditions. Each grating is fabricated with precision to ensure a perfect fit, safe walking surface, and efficient drainage – making it an ideal choice for chemical processing facilities, refineries, and other harsh settings.
We understand the critical importance of safety and durability in chemical plants. That is why our steel gratings undergo strict quality control at every stage – from material selection to final surface treatment. With over 20 years of experience in the wire mesh industry, we deliver products that meet the highest standards of strength and corrosion resistance, giving you peace of mind and long service life.
Below you will find detailed specifications, product features, benefits, and answers to frequently asked questions. We are confident that our steel grating will exceed your expectations for your drainage trench cover needs.
Product Specifications
| Parameter | Details |
| Material | Low carbon steel (Q235), optional stainless steel |
| Width | 250 mm (standard), custom widths available |
| Span Length | 3 m (up to 6 m possible upon request) |
| Bar Thickness | 3 mm – 6 mm (load dependent) |
| Bar Spacing (center to center) | 30 mm / 40 mm / 50 mm (optional) |
| Surface Treatment | Hot dip galvanized (HDG), painted, or plain |
| Load Capacity | Customizable per design – up to 5 kN/m² or higher |
| Weight per Piece (approx.) | ~15 kg (varies with bar size and spacing) |
Key Features and Benefits
- High Load-Bearing Capacity: Designed to withstand heavy traffic, equipment loads, and impact in chemical plant environments. The 3m span ensures minimal deflection under load.
- Corrosion Resistance: Hot dip galvanized coating provides excellent protection against chemicals, moisture, and rust. Suitable for exposure to acids, alkalis, and solvents commonly found in chemical plants.
- Slip Resistance: The serrated surface (optional) and open grid design offer superior traction even when wet or oily, reducing the risk of slips and falls.
- Efficient Drainage: Open area up to 70% allows rapid water and liquid flow, preventing ponding and reducing the risk of chemical spills accumulating.
- Easy Installation & Maintenance: Lightweight yet strong, these gratings can be quickly cut and fitted on site. They require minimal maintenance – just occasional cleaning.
- Customizable Dimensions: Width, length, bar thickness, and spacing can be tailored to your specific trench dimensions and load requirements. Contact us for custom quotes.
- Durable Construction: Manufactured using advanced forging or welding techniques (press-locked or welded). Each joint is strong and secure.
Why Choose Our Steel Grating?
Our steel grating is produced by Anping Xinye Metal Wire Mesh Products Co., Ltd, a trusted manufacturer with decades of experience in the wire mesh industry. We have supplied gratings to numerous chemical plants, refineries, and industrial facilities worldwide. Our factory is equipped with modern production lines and strict quality control systems.
Each batch of steel grating is tested for dimensional accuracy, flatness, and load capacity. We use only high-quality steel coils sourced from reputable mills. Our hot dip galvanizing process follows industry standards to ensure a uniform, thick coating that lasts for years.
We also offer the following advantages:
- Competitive Pricing: Direct factory pricing eliminates middleman costs.
- Fast Lead Times: Standard sizes are in stock; custom orders ship within 7–15 days.
- Global Shipping: We export to over 50 countries with reliable logistics partners.
- Technical Support: Our engineers can help you select the right grating for your load and corrosion requirements.
Don't compromise on safety and durability. Contact us today for a quote or sample. Our team is ready to assist you with your drainage trench cover project.
Frequently Asked Questions (FAQ)
-
Q: What is the standard bar thickness for this grating?
A: The standard bar thickness ranges from 3 mm to 6 mm, depending on the load rating required. For chemical plant applications, we recommend at least 5 mm for heavy loads. -
Q: Can I get the grating in stainless steel?
A: Yes, we offer stainless steel 304 or 316 options for environments with extreme corrosion. Please specify your requirement when ordering. -
Q: How do I cut the grating to fit my trench?
A: The grating can be cut with a standard angle grinder or band saw. We can also pre-cut to your exact dimensions at the factory for an additional fee. -
Q: What is the maximum span length you can produce?
A: Our standard span is up to 3 m, but we can produce up to 6 m upon request, depending on the load and bar size. For spans longer than 3 m, we recommend using thicker bars or additional support. -
Q: Is the galvanized coating safe for food or potable water?
A: Hot dip galvanized coating is not recommended for direct contact with food or potable water. For such applications, we suggest stainless steel or epoxy-coated gratings. -
Q: How do I install the grating in a trench?
A: Typically, the grating sits on a supporting frame or ledge built into the trench walls. It can be secured with clips, bolts, or welding. We provide installation advice upon request. -
Q: What is the weight of one piece of 250mm x 3m grating?
A: Approximately 15 kg for a standard 30mm spacing with 5mm bars. Exact weight depends on the configuration. We can provide a weight calculation for your specific design. -
Q: Do you offer a warranty?
A: Yes, we provide a limited warranty against manufacturing defects. Please contact our sales team for warranty terms.
With over 20 years of experience and a dedicated team of 50+ skilled workers, Anping Xinye Metal Wire Mesh Products Co., Ltd has become a reliable partner for industrial grating solutions. Our factory covers an area of 10,000 m², and we produce more than 500,000 pieces of grating annually. We are committed to delivering high-quality products that meet your exact specifications. Order your steel grating today and experience the difference of working with a professional manufacturer.
