Help CenterShell and Tube Type Evaporator, Copper Tube, 316L Stainless Steel Shell, 15kW Cooling Capacity
Product Spotlights
Related Products
-
Double Tube Type Evaporator, 316L Stainless Steel, 1.5m2 Heat Transfer Area, 10 Bar Working PressureUS$ 7520 - 185000MOQ: 1 Combo -
Brine Evaporation and Crystallization Equipment With 2-Year Warranty Free On-Site Commissioning and TrainingUS$ 6270 - 758000MOQ: 1 Combo
-
Multi-Effect Brine Evaporation and Crystallization Unit 0.5-2 Ton/Day 304 Stainless Steel Shell and Tube DesignUS$ 6270 - 758000MOQ: 1 Combo
-
Automatic 316L Stainless Steel Brine Evaporation and Crystallization Equipment With PLC Control 220V 50HzUS$ 6270 - 758000MOQ: 1 Combo
-
Industrial Brine Evaporation and Crystallization Machine 380V Three Phase IP65 Protection Standard CompliantUS$ 6270 - 758000MOQ: 1 Combo
Qingdao Conqinphi Environmental Technology Group Co., Ltd. is a professional manufacturer specializing in heat exchange equipment since 2015. Our Shell and Tube Type Evaporator features high-quality copper tubes and a 316L stainless steel shell, delivering a reliable 15kW cooling capacity for demanding industrial applications. With a factory size of 10,000–30,000 square meters and over 200 skilled employees, we ensure precision engineering and strict quality control. This evaporator is designed to maximize heat transfer efficiency while resisting corrosion, making it an ideal choice for refrigeration, HVAC, and process cooling systems.
Our shell and tube evaporator stands out for its robust construction and optimized thermal performance. The use of copper tubes ensures excellent thermal conductivity, while the 316L stainless steel shell provides superior corrosion resistance in harsh environments. Whether you need a compact unit for a chiller or a heavy-duty evaporator for industrial cooling, this model offers consistent performance and long service life.
Key Features & Benefits
- High Thermal Efficiency: Copper tubes with enhanced surface area promote rapid heat transfer, reducing energy consumption.
- Corrosion Resistance: 316L stainless steel shell withstands aggressive media and extends equipment lifespan.
- Compact Design: Space-saving footprint suitable for installation in confined areas.
- Easy Maintenance: Removable tube bundle design allows simple cleaning and inspection.
- Customizable Options: Available in various tube lengths, baffle configurations, and connection types to meet specific requirements.
- Reliable Performance: Tested under rigorous conditions to ensure stable operation at rated capacity.
Technical Specifications
| Cooling Capacity | 15 kW |
| Evaporator Type | Shell and Tube (Flooded or Dry expansion – optional) |
| Tube Material | Copper (seamless, annealed) |
| Shell Material | 316L Stainless Steel |
| Design Pressure | Up to 30 bar (customizable) |
| Operating Temperature Range | -20°C to +120°C |
| Connection Size | DN25 – DN80 (flanged or threaded) |
| Weight (approx.) | 80–120 kg (depending on configuration) |
Applications
- Industrial Refrigeration: Cold storage, food processing, and beverage cooling.
- HVAC Systems: Chillers for commercial buildings, data centers, and hospitals.
- Process Cooling: Chemical, pharmaceutical, and manufacturing industries.
- Heat Recovery: Waste heat utilization and energy-saving systems.
The shell and tube design ensures excellent heat transfer even under varying loads. Copper tubes are mechanically expanded into the tube sheets to prevent leakage, and the 316L shell is welded by certified welders to meet international standards. Each unit undergoes a hydrostatic pressure test and a helium leak test before shipment to guarantee zero defects.
Our factory, located in Qingdao, China, covers 10,000–30,000 square meters and employs 201–300 skilled workers. With an annual export value of US$10–50 million, we serve customers across North America, South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and domestic markets. We hold certifications including ISO9001, ISO14001, OHSAS18001, HACCP, SA8000, TS16969, TL900, QS9000, and others, demonstrating our commitment to quality, safety, and social responsibility.
Why choose Conqinphi? We offer competitive pricing, fast delivery, and comprehensive after-sales support. Our engineering team can customize the evaporator to match your specific refrigerant, pressure, and connection requirements. With over 8 years of experience, we have built a reputation for reliable products and customer satisfaction. Contact us today for a quotation or technical consultation.
Frequently Asked Questions
-
Q: What refrigerants are compatible with this evaporator?
A: The evaporator is compatible with common refrigerants such as R22, R134a, R404A, R407C, R410A, and R717 (ammonia). Please specify your refrigerant when ordering for optimal design. -
Q: Can the shell and tube evaporator be used for flood-fed or DX expansion?
A: Yes, we offer both flooded and dry expansion (DX) versions. The internal design can be adjusted to match the expansion device type. -
Q: What is the typical lead time for a 15kW unit?
A: Standard lead time is 15–25 working days, depending on order quantity and customization. Rush orders can be arranged upon request. -
Q: How do you ensure the quality of the 316L stainless steel shell?
A: We source 316L material from certified suppliers and perform material test reports (MTR) for each batch. Welding is done by certified welders per ASME or equivalent standards. -
Q: Is the tube bundle replaceable?
A: Yes, our design allows easy removal and replacement of the tube bundle without cutting the shell, simplifying maintenance. -
Q: What is the maximum operating pressure for this model?
A: The standard design pressure is up to 30 bar, but higher pressures are available through customization. Contact our technical team for details. -
Q: Do you provide installation or commissioning support?
A: Yes, we offer technical documentation, remote support, and on-site commissioning assistance for international customers. Additional services can be arranged. -
Q: What certifications do your products hold?
A: Our factory is certified with ISO9001, ISO14001, OHSAS18001, HACCP, SA8000, TL900, QS9000, TS16969, and more. Individual product certifications can be customized based on destination market requirements.
Contact us to discuss your specific cooling needs. Our team is ready to provide a tailored solution with competitive pricing and fast delivery.
