50m³ Above Ground Horizontal Fuel Storage Tank
Product Description
Section 1: Product Overview
The 50m³ Above Ground Horizontal Fuel Storage Tank is a frequent production item engineered specifically for gasoline and diesel storage. Manufactured at our Hebei source factory, this tank features a compact horizontal cylindrical structure, making it the ideal solution for sites with limited space or height restrictions. It is widely utilized in small-scale gas stations, industrial backup generator rooms, construction sites, and agricultural fueling stations. With a standardized design and streamlined production cycle, we guarantee reliable delivery within 30 days.
Section 2: Product Features
-
Frequent Production Stock: Standardized sizes ensure short lead times.
-
Compact Horizontal Design: Low center of gravity and minimal vertical clearance required.
-
Robust Construction: Fabricated from high-grade Q235B carbon steel.
-
Superior Corrosion Protection: Sa2.5 blasting followed by epoxy coal tar or polyurethane coating.
-
Customizable Configuration: Supports dual compartments, heating jackets, and specialized accessories.
Section 3: Technical Specifications
Parameter
Specification
Product Name
50m³ Above Ground Horizontal Fuel Tank
Capacity
50m³ (50,000 Liters)
Storage Medium
Gasoline, Diesel, Kerosene
Material
Q235B Carbon Steel (SS304/SS316 Optional)
Design Pressure
Atmospheric Pressure
Tank Type
Horizontal Cylindrical
Corrosion Protection
Sa2.5 Blasting + Epoxy Coal Tar / PU Coating
Design Standard
GB 50341 / API 650 (Optional)
Accessories
Manhole, Inlet/Outlet Valves, Vent Pipe, Level Gauge
Section 4: Product Advantages
-
Factory Direct Pricing: Eliminating middlemen for competitive market rates.
-
Rapid Deployment: Frequent production status ensures fast delivery.
-
Structural Integrity: Automatic submerged arc welding guarantees leak-proof seams.
-
Low Maintenance: Durable coating system reduces long-term upkeep costs.
-
Global Compliance: Meets international standards for safety and environmental protection.
Section 5: Manufacturing Capability
Our integrated manufacturing process ensures precision and quality control at every stage:
Engineering Design → Plate Rolling → Automatic Submerged Arc Welding → NDT Inspection → Hydrostatic Test (24h) → Surface Coating → Final Assembly → Packaging.
Section 6: Quality Control
-
Material Verification: Raw material mill certificates checked upon arrival.
-
Weld Integrity: 100% Radiographic Testing (RT) on longitudinal and circumferential seams.
-
Pressure Testing: 24-hour hydrostatic test at 100% design capacity.
-
Coating Inspection: Dry Film Thickness (DFT) verified to be ≥200μm.
-
Final QA: Comprehensive dimensional and visual inspection prior to dispatch.
Section 7: Applications
-
Small Gas Stations & Petrol Depots
-
Backup Power Systems (Generator Fuel Tanks)
-
Construction & Mining Sites
-
Agricultural Machinery Fueling
-
Remote Industrial & Logistics Sites
Section 8: Custom Services
-
Dual-Compartment Tanks: Separate storage for gasoline and diesel in one unit.
-
Heating Jackets: For operations in cold climates or high-viscosity fuels.
-
Skid-Mounted Systems: Integrated pumping, metering, and filtration systems.
-
Leak Detection: Advanced monitoring systems for environmental safety.
-
Installation Support: Provision of on-site supervision and technical guidance.
Section 9: FAQ
Q1: Is this tank suitable for gasoline storage?
A: Yes, it is specifically designed for both gasoline and diesel storage, with optional vapor recovery accessories available to meet environmental regulations.
Q2: What is the typical lead time?
A: As a frequent production item, the standard lead time is approximately 30 days after deposit confirmation.
Q3: Can this tank be installed underground?
A: No, this specific model is engineered exclusively for above-ground installation. We offer dedicated underground storage tank models upon request.
Section 10: Why Choose Us
-
Hebei Source Factory: Direct control over production quality and schedules.
-
Certified Manufacturer: ISO 9001 & ISO 14001 certified management systems.
-
Proven Expertise: Professional welding and engineering teams with 20+ years of experience.
-
Global Track Record: Successful projects and shipments to Southeast Asia, the Middle East, Africa, and South America.
-
Responsive Support: Dedicated project managers ensuring fast communication.
Section 11: Contact
Contact: Project Manager
Mobile / WeChat: +86 15203283906
Email: 2247450686@qq.com
Website:
Meta Keywords: 50m³ Fuel Tank, Above Ground Horizontal Tank, Diesel Storage Tank, Gasoline Storage Tank Manufacturer, Horizontal Oil Tank, 50 Cubic Meter Fuel Tank
