Help CenterElectric Blast Drying Oven Laboratory Drying Oven/Laboratory Small Industrial High Temperature Drying Oven
Product Spotlights
Heating method:Electric Heating
Material:SUS304, SUS304L, Other
Core components:Bearing, PLC, Other
Application:Chemicals Processing, Plastics Processing, Food Processing, Industrial Procession
Voltage:220v/380v
Related Products
-
16L Wholesale Electric Industrial Laboratory Constant Temperature Hot Air Circulating Heating Convection Drying OvenNegotiableMOQ: 1 Piece -
Capacity 16L-1000L Customizable Cabinet Size Blower Drying Equipment Industrial or Laboratory Specific OvenNegotiableMOQ: 1 Piece
-
Hot Air Circulating Industrial Oven High Temperature Cabinet Drying & Curing OvenNegotiableMOQ: 1 Piece
-
Industrial 200 250 300 Degree Drying Oven 25L 50L 150L Hot Air Circulating Laboratory Oven MachineNegotiableMOQ: 1 Piece
-
Laboratory High Temperature Oven Stainless Steel Circulating Oven Curing Industrial OvenNegotiableMOQ: 1 Piece
Highlights at a glance
1. The chamber is made of high-temperature resistant stainless steel, ensuring it won't deform at high temperatures. The double-layered inner liner with rounded corners is aesthetically pleasing and easy to clean.
2. It uses an intelligent PID temperature controller with timer, alarm, and over-temperature protection functions.
3. Finned stainless steel heating elements combined with an air-jacketed heating system and high-temperature fan circulation ensure more uniform temperature distribution.
4. The sealing strip uses aerospace-grade sealing material with a temperature resistance up to 1000°C.
5. Constant temperature method: Forced fan circulation.
6. Temperature range: Adjustable from room temperature +50-500°C.
7. The inner liner is made entirely of high-quality, thickened 316L and 310S stainless steel.
Product Paramenters
INNER SIZE |
EXTERNAL SIZE |
TEMPERATURE |
HEATING UP |
ACCURACY |
UNIFORMITY |
POWER |
POWER OF WORK |
|
W*H*D(CM) |
W*H*D(CM) |
RANGE(°C) |
TIME |
(°C) |
(°C) |
(KW) |
||
VORIL-72L |
45×40×40 |
66×82×52 |
(A-D)A:200°C |
RT~100°C |
±0.3 |
±1% |
220V |
2.2 |
VORIL-125L |
50×50×50 |
69×100×64 |
4.6 |
|||||
VORIL-270L |
60×90×50 |
93×125×70 |
5.5 |
|||||
VORIL-600L |
100×100×60 |
133×165×80 |
6 |
|||||
VORIL-1000L |
100×100×100 |
120×160×120 |
8 |
High Temperature Oven Features
1. Outside SECC steel, fine powder coating treatment. Inner SUS#304 stainless steel.
2. Use a new high temperature-resistant long shaft motor.
3. Turbine fan.
4. Silicone forced tight.
5. Over temperature protection, super load automatic power system.
6. Circulation system: air force level cycle.
7. Heating system: PID+S.S.R.
8. The thermostat: PID microcomputer control, automatic constant temperature, the temperature quickly compensation function.
9. Timer: temperature to time, when the power failure alarm indication.
10. According to customer demand matching glass windows can be customized.
