We are Xi'an Wisdom Computer Info&tech Co., Ltd, a professional trading company with over 8 years of experience in industrial automation. Our Reliable Automatic Six Axis Industrial Packing Robot with Self Diagnostic System is engineered to streamline your packaging operations while minimizing unplanned downtime. This advanced robot combines precision, flexibility, and intelligent diagnostics to meet the demanding requirements of modern production lines.
The six-axis design offers exceptional dexterity, allowing the robot to handle complex packing tasks such as picking, placing, palletizing, and wrapping with high speed and accuracy. Its built-in self-diagnostic system continuously monitors key components, predicting potential failures before they occur, which significantly reduces maintenance costs and improves overall equipment effectiveness (OEE).
Key Features
- Six-Axis Articulation – Provides full flexibility for intricate packing patterns, reaching around obstacles and optimizing space utilization.
- Self-Diagnostic Capability – Real-time health monitoring of motors, drives, joints, and sensors. Alerts operators via the HMI panel, enabling predictive maintenance.
- High Payload Capacity – Designed to handle items from a few kilograms up to 20 kg, suitable for a wide range of packaging applications.
- Robust Construction – Built with high-strength aluminum alloy and steel, ensuring durability in harsh industrial environments.
- Easy Integration – Compatible with standard PLCs and conveyor systems. Comes with pre-configured software templates for common packing tasks.
- Energy Efficient – Servo motors with regenerative braking reduce power consumption, lowering operational costs.
- Comprehensive Safety – Equipped with emergency stop, collision detection, and safety zone monitoring, meeting international safety standards.
Technical Specifications
| Parameter | Value |
| Number of Axes | 6 |
| Payload Capacity | 10–20 kg (customizable) |
| Repeatability | ±0.1 mm |
| Working Radius | 1500 mm (optional) |
| Power Supply | 380V/50Hz, 3-phase |
| Control System | PLC with self-diagnostic module |
| Protection Class | IP54 (IP65 optional) |
| Weight | Approx. 500 kg |
Customer Benefits
- Increased Productivity – Automates repetitive packing tasks, freeing up human workers for higher-value activities.
- Reduced Downtime – Self-diagnostic system alerts you to issues before they cause stoppages, allowing proactive maintenance.
- Consistent Quality – High repeatability ensures each package is handled uniformly, reducing product damage.
- Lower Operating Costs – Energy-efficient design and reduced scrap rates contribute to a fast return on investment.
- Scalability – Multiple robots can be coordinated to handle increased production volumes.
At Xi'an Wisdom Computer Info&tech Co., Ltd, we have been serving the global market since 2015. Our dedicated team of 51–100 employees, together with our overseas office, ensures prompt and professional support for clients across North America, South America, Europe, Asia, Africa, and Oceania. We ship from Shanghai port with flexible logistics options. Despite our modest annual export value below US$1 million, we pride ourselves on personalized service and high-quality automation solutions tailored to your needs.
We invite you to experience the reliability and efficiency of our six-axis packing robot. Whether you need a standard model or a customized configuration, our technical team is ready to assist. Contact us today for a detailed proposal or a virtual demonstration.
Frequently Asked Questions
Q1: What is the maximum payload of this robot?
A: The standard payload capacity is 10 kg, but it can be customized up to 20 kg depending on your application. Please provide your specific requirements for a tailored solution.
Q2: How does the self-diagnostic system work?
A: The system continuously monitors motor temperature, vibration, current draw, and joint positioning. Data is analyzed in real-time, and any anomaly triggers a warning on the HMI. This allows operators to schedule maintenance before a breakdown occurs.
Q3: What are the installation requirements?
A: The robot requires a flat, stable foundation. It connects to a standard 380V/50Hz three-phase power supply. Our team can provide a detailed installation manual and remote guidance. Optional on-site installation support is available upon request.
Q4: Is programming difficult?
A: The robot comes with a user-friendly teach pendant and pre-loaded software for common packing tasks. Basic programming can be learned within a few days. We also offer training sessions for your operators.
Q5: What maintenance is required?
A: Routine maintenance includes periodic lubrication of joints, checking electrical connections, and cleaning air filters. The self-diagnostic system helps schedule these tasks. A detailed maintenance schedule is provided in the user manual.
Q6: Can the robot be customized for different packaging formats?
A: Yes, the robot's end-effector can be changed to accommodate different grippers, vacuums, or clamps. The control software allows easy reconfiguration for new packing patterns.
Q7: What is the typical lead time?
A: Standard models are typically shipped within 30–45 days after order confirmation. Customized versions may take longer. Please contact our sales team for an accurate lead time based on your specifications.
Q8: What after-sales support do you provide?
A: We offer one-year warranty, remote technical support, and spare parts availability. Our overseas office can assist with local service coordination. Extended warranty and on-site service contracts are optional.
