Welcome to XiAn Wisdom Computer Info&tech Co., Ltd – your trusted partner for advanced industrial automation solutions. Since 2015, we have been supplying high-performance robotic systems to global markets, including North America, Europe, and Southeast Asia. Our JZJ06C-200 Long Reach 6 Axis Industrial Welding Robot is engineered to deliver precision, durability, and versatility for both laser cutting and arc welding applications. With an IP67-rated body, this robot withstands harsh environments, ensuring reliable operation in dusty, humid, or splash-prone workshops. Backed by our ISO9001 quality management system and a dedicated team of 51–100 professionals, we offer a product that combines long reach, six-axis flexibility, and robust construction – ideal for manufacturers seeking to upgrade their production efficiency.
Key Features & Technical Specifications
Six-Axis Articulation – Provides exceptional flexibility and a wide working envelope, allowing the robot to reach complex weld seams and laser cutting paths.
Long Reach Design – The JZJ06C-200 offers an extended arm length, covering large workpieces without the need for repositioning, reducing cycle time.
IP67 Protection Grade – Fully sealed body resistant to dust and water jets, suitable for welding spatter, coolant, and high-humidity environments.
Dual-Application Capability – Optimized for both arc welding and laser cutting, easily switchable with appropriate end-effectors.
High Repeatability – Achieves precise positioning, ensuring consistent weld quality and cut accuracy.
Rugged Construction – Built with durable materials (cast iron/steel) to withstand continuous industrial use.
Easy Integration – Compatible with major welding power sources and laser cutting controllers; supports standard communication protocols (Ethernet, Profinet, etc.).
User-Friendly Programming – Intuitive teach pendant and offline simulation software reduce setup time.
| Parameter | Specification |
|---|---|
| Model | JZJ06C-200 |
| Number of Axes | 6 |
| Protection Grade | IP67 |
| Maximum Reach | 2000 mm (approx.) – Long Reach |
| Repeatability | ±0.05 mm (typical, upon request) |
| Maximum Payload | 20 kg (approx., customizable) |
| Applicable Processes | Arc Welding (MIG/MAG/TIG), Laser Cutting |
| Mounting Options | Floor, Ceiling, Wall (available upon request) |
Advantages & Benefits for Your Business
Increased Productivity – The long reach minimizes the need for robot repositioning, allowing faster cycle times and higher throughput.
Enhanced Weld/Cut Quality – High repeatability and six-axis flexibility ensure uniform weld beads and precise laser cuts, reducing rework.
Reliability in Harsh Conditions – IP67 rating means the robot can operate in environments with dust, metal shavings, and coolant splashes, reducing downtime.
Versatile Application – One robot handles both welding and cutting tasks, saving equipment cost and floor space.
Lower Total Cost of Ownership – Durable construction and easy maintenance extend service life, while energy-efficient servo motors reduce power consumption.
Easy Integration & Scalability – Can be integrated into existing production lines or used as part of a new automated cell; supports multiple end-effectors.
Why Choose XiAn Wisdom Computer Info&tech Co., Ltd?
With over 8 years of experience in the industrial automation field, we have established a strong reputation for delivering reliable robotic solutions worldwide. Our company holds ISO9001, ISO9004, and ISO14000 certifications, ensuring our processes meet international quality and environmental standards. We maintain an overseas office to provide prompt technical support and after-sales service. Our team of 51–100 skilled professionals handles everything from product selection to installation guidance. Although our factory is compact (under 1,000 sqm), we focus on rigorous quality control and customization to meet specific customer needs. We ship from Shanghai port to markets across North America, South America, Europe, Asia, Africa, and Oceania. Choose the JZJ06C-200 robot – a reliable, long-reach, IP67-rated solution that elevates your welding and laser cutting operations.
Frequently Asked Questions (FAQ)
Q: What is the advantage of IP67 protection for welding robots?
A: IP67 means the robot is completely dust-tight and can withstand temporary immersion in water (1 meter depth for 30 minutes). In welding environments, this protects internal components from metal dust, spatter, and coolant, preventing premature failure and reducing maintenance frequency.Q: Can this robot be used for both laser cutting and arc welding simultaneously?
A: The robot can perform both tasks, but not simultaneously. You can equip it with a quick-change tool changer to switch between a welding torch and a laser cutting head. The robot's controller supports multiple process programs for easy switching.Q: What is the maximum payload of the JZJ06C-200?
A: The typical maximum payload is around 20 kg, depending on the reach and mounting configuration. For specific payload requirements, please contact us for a customized solution.Q: Does the robot come with a controller and teach pendant?
A: Yes, the robot is supplied with a matching controller, teach pendant, and necessary cables. The controller features a user-friendly interface and supports standard communication protocols (Ethernet/IP, Profinet, etc.).Q: What kind of welding power sources are compatible?
A: The robot is compatible with most major arc welding power sources (e.g., Fronius, Lincoln, Miller, Panasonic) via analog or digital interface. We can also provide interface integration support upon request.Q: Is programming difficult for operators without robotics experience?
A: Our teach pendant uses an intuitive menu-driven interface, and we provide offline simulation software to simplify programming. Additionally, we offer training and technical documentation to help your team get started quickly.Q: What is the delivery time and shipping method?
A: Standard delivery time is 30–45 days after order confirmation. We ship from Shanghai port via sea freight, air freight, or express courier, depending on your location and urgency. We can arrange door-to-door shipping for many destinations.Q: How do you ensure product quality before shipment?
A: Every robot undergoes a thorough factory acceptance test (FAT) including run-in, accuracy verification, and functional checks. We also provide test reports and video evidence upon request. Our ISO9001 quality system ensures consistent quality control.
Ready to automate your welding and cutting processes? Contact XiAn Wisdom Computer Info&tech Co., Ltd today for a quote or technical consultation. We look forward to supporting your success!
