Anping Xinye Metal Wire Mesh Products Co., Ltd, based in Hengshui, Hebei, China, is a professional manufacturer of metal gratings. Our Hot Dipped Galvanized Flat Bar Steel Grating is engineered for heavy-duty flooring and trench covers, offering exceptional strength, corrosion resistance, and long service life. This product is designed to meet the rigorous demands of industrial environments, providing a reliable walking surface and secure cover for drainage channels, pits, and trenches.
Manufactured from high-quality steel flat bars, each panel undergoes a hot-dipped galvanizing process that delivers a thick, uniform zinc coating. This ensures superior protection against rust and harsh weather conditions, making it ideal for both indoor and outdoor applications. The open grid design allows for efficient drainage, light transmission, and ventilation, while the robust construction supports heavy loads, including forklifts and heavy machinery.
Below are the key features, technical specifications, and benefits of our product.
Key Features & Technical Specifications
- Material: High-strength carbon steel (Q235) or stainless steel (optional).
- Surface Finish: Hot-dipped galvanized per ASTM A123 or equivalent, providing a durable zinc coating of 50-85 microns.
- Bearing Bar Type: Flat bars, typically 25mm to 100mm in height, 3mm to 6mm in thickness.
- Cross Bar: Twisted square bars or round bars, welded at each intersection for maximum rigidity.
- Panel Size: Customizable dimensions, standard widths up to 1.2m, lengths up to 6m (or as per request).
- Load Capacity: Designed for heavy-duty loads, with deflection testing available upon request.
- Anti-Slip: Serrated flat bars can be supplied for enhanced slip resistance.
- Cutouts: Panel cutouts for pipes, columns, or other obstructions can be fabricated to order.
| Parameter | Standard Range | Notes |
|---|---|---|
| Bearing bar height | 25 mm – 100 mm | Customizable |
| Bearing bar thickness | 3 mm – 6 mm | Heavier duty available on request |
| Bar spacing (center to center) | 30 mm / 40 mm / 50 mm | Other spacing possible |
| Cross bar pitch | 50 mm – 100 mm | Standard 50 mm |
| Surface treatment | Hot dip galvanized | Option: painted or plain |
| Load capacity | 500 – 1000 kg/m² (typical) | Validated by calculation |
Advantages & Customer Benefits
- Exceptional Corrosion Resistance: The hot-dipped galvanized coating protects the steel from rust, extending service life even in wet, chemical, or marine environments.
- Heavy Load Bearing: Flat bar design provides high strength-to-weight ratio, suitable for industrial flooring, vehicle access, and trench covers in factories, warehouses, and parking lots.
- Safety Features: Open grid allows water, mud, and debris to fall through, reducing slip risks. Serrated options offer extra grip.
- Easy Installation: Panels are prefabricated to precise dimensions, ready for drop-in or welding onto support structures. Anchoring systems available.
- Low Maintenance: The galvanized finish requires no painting or regular maintenance, saving time and cost over the product's life.
- Customizable Design: We can tailor bar spacing, dimensions, cutouts, and load ratings to match your project requirements. Contact us for custom solutions.
- Versatile Applications: Ideal for walkways, mezzanines, drainage covers, machine platforms, and more.
Trust Anping Xinye – With years of experience in wire mesh and grating manufacturing, we are committed to delivering high-quality products at competitive prices. Our factory in Hengshui, Hebei, China, is equipped with advanced production lines and strict quality control. We serve clients worldwide, offering reliable packaging and timely delivery. Whether you need standard panels or custom designs, our team is ready to assist.
For heavy-duty flooring and trench covers that stand the test of time, choose our Hot Dipped Galvanized Flat Bar Steel Grating. We invite you to send us your inquiry or drawing for a quick quote. Experience the durability and performance that industry professionals trust.
Frequently Asked Questions (FAQ)
Q1: What is the load capacity of this grating?
A: The load capacity depends on the bearing bar size, spacing, and span. Typical heavy-duty panels can support up to 1000 kg/m². We provide load tables upon request.
Q2: Can I get non-standard dimensions or cutouts?
A: Yes, we offer full customization. You can specify panel length, width, bar spacing, and cutouts for pipes or columns. Please provide a drawing or detailed requirements.
Q3: Is the grating suitable for outdoor use?
A: Absolutely. The hot-dipped galvanized finish provides excellent weather resistance, making it ideal for outdoor applications like trench covers, platforms, and walkways.
Q4: How is the grating installed?
A: Panels can be welded to the supporting structure, secured with clips, or simply dropped into a frame. We can supply installation accessories if needed.
Q5: What is the typical lead time?
A: For standard sizes, lead time is around 15-20 working days after order confirmation. Custom orders may take longer depending on complexity. We aim to meet your schedule.
Q6: Do you offer samples?
A: Yes, samples are available for quality evaluation. Please contact our sales team with your requirements, and we will arrange shipment.
Q7: Can you provide a certificate of material or galvanizing?
A: Yes, material test certificates and galvanizing thickness reports can be provided upon request. We follow standard quality procedures.
Q8: What is the minimum order quantity (MOQ)?
A: MOQ is generally 50 square meters for standard products. For custom orders, we can discuss based on production feasibility.
