1. Product Overview
This 35kV prefabricated substation is an all-in-one compact power distribution unit compliant with IEC international standards. It integrates 35kV high-voltage switchgear, power transformer, low-voltage distribution system, protection and metering devices with full factory pre-assembly and pre-commissioning. Featuring plug-and-play operation, small footprint and high reliability, it is widely used in new energy stations, industrial parks, municipal works, railways and mining projects.
2. Core Technical Parameters
Rated High Voltage: 35kV (40.5kV)
Rated Low Voltage: 0.4kV / 6kV / 10kV (Optional)
Frequency: 50Hz
Capacity: 630kVA – 4000kVA (Customizable)
Protection Grade: IP33 / IP54 (Outdoor)
Working Temperature: -40℃ ~ +40℃
Max Working Altitude: 3500m
3. Outstanding Product Advantages
1. Full Factory Prefabrication & Fast Delivery
All assembly, wiring and testing are completed in the factory. On-site installation only needs foundation fixation and cable connection, which greatly saves construction time and labor costs.
2. Integrated Compact Structure & Space-saving
Integrated HV, transformer and LV design minimizes floor space, only 1/10 size of traditional substations, perfect for limited and scattered construction sites.
3. Multi-layer Safety Protection & High Stability
Equipped with complete over-current, over-voltage and short-circuit protection. Independent compartment structure prevents fault spread. Waterproof, dustproof and anti-corrosion housing adapts to all harsh outdoor conditions.
4. Low Loss & Energy Saving
Adopts low-loss transformer and optimized busbar design to reduce power consumption. Low noise and high efficiency for long-term continuous operation.
5. Intelligent Monitoring & Easy Maintenance
Supports intelligent monitoring and remote fault alarm. Simplified internal structure enables easy daily inspection and low maintenance cost.
4. Main Configuration & Functions
35kV high-voltage incoming & protection unit
Custom capacity low-loss power transformer
LV distribution, reactive compensation & metering system
Relay protection & DC control system
Intelligent remote monitoring & communication module
Waterproof, heat dissipation & anti-corrosion system
5. Factory Service & Purchase Advantages
✅ Customizable: Support non-standard size, capacity and functions with free solution design
✅ Premium Quality: Top-grade components with strict full factory testing
✅ Factory Direct Supply: No middleman, competitive price & complete certification
✅ One-stop Service: Professional technical guidance and long-term after-sales support
6. Wide Application Scenarios
Suitable for photovoltaic & wind power stations, industrial parks, municipal power supply, railway, mining, residential and commercial power distribution projects.
