Help CenterGGJ Low-Voltage Power Distribution Reactive Power Compensation Integrated Cabinet
Related Products
-
GGD Type AC Low Voltage Distribution CabinetNegotiableMOQ: 10 Pieces -
Dual Power Control Cabinet Automatic Switching Box Fixed Low-voltage Complete Set of Power Distribution Cabinet Non-standard CustomizationNegotiableMOQ: 2 Pieces
-
Low-voltage Complete Power Distribution Cabinet PLC Automation Control Cabinet Frequency Conversion Cabinet Electric Control Cabinet Non-standard CustomizationNegotiableMOQ: 10 Pieces
-
Outdoor Integrated Stainless Steel Distribution CabinetNegotiableMOQ: 10 Sets
-
ATS Dual Power Automatic Transfer Switch Distribution Cabinet Complete Set of Electrical Non-standard CustomizationNegotiableMOQ: 5 Sets
GGJ type no-power automatic compensation is suitable for power distribution systems with AC 50Hz, three-phase 380V, 100KVA-1000KVA transformer capacity in industrial and mining enterprises and civil residences as reactive power compensation. GGJ is used in conjunction with GGD type low voltage distribution panel. According to the demand for reactive power compensation by the power grid, the grouped capacitors can be automatically controlled to be put into or cut out of the power grid in 4-12 groups (steps) within 10-120S interval, so as to realize automatic reactive power compensation and stabilize the voltage quality of the power supply network. , reduce the loss of power transmission and distribution systems and transformers, and achieve the purpose of saving energy and improving the quality of power supply of the power grid.
Scope of application: GGJ capacitor cabinet, suitable for all kinds of wet and dusty workshops. Applicable to light textile, metallurgy, chemical, mining, machinery and other factories and mines, as a power supply in a three-phase three-wire, four-wire or five-wire low-voltage power distribution system with AC 50Hz, rated voltage 380V or 660V, and rated current up to 630A and lighting distribution. At the same time, it can also be used for partial control in the low-voltage control system.
