As a trusted manufacturer with over 25 years of expertise in wire mesh products, Anping County Boli Hardware Wiremesh Products Factory (established 1998) proudly presents our Sintered Mesh Filter Panel – 500x500mm, crafted from premium 304 Stainless Steel with a precise 50 micron filtration rating. Each panel is supplied with a Mill Test Report to guarantee material traceability and performance consistency. Ideal for demanding industrial filtration applications, this sintered filter panel combines high strength, excellent corrosion resistance, and long service life.
Our sintered mesh filter panels are produced using advanced sintering technology, where multiple layers of wire mesh are bonded under high temperature and pressure. This creates a rigid, porous structure that offers superior mechanical stability and uniform pore distribution. The 500x500mm standard size simplifies integration into existing filter systems, and the 304 SS material ensures reliable performance in corrosive environments.
Key Features & Technical Specifications
- Durable Sintered Construction: Multi-layer mesh fused into a monolithic panel – no delamination, high resistance to vibration and pressure surges.
- Accurate 50 Micron Filtration: Consistent pore size ensures reliable particle removal (down to 50 μm) with minimal pressure drop.
- 304 Stainless Steel: Excellent corrosion resistance against water, acids, alkalis, and many industrial fluids. Suitable for food-grade and pharmaceutical environments.
- Mill Test Report Included: Provides certified material composition and mechanical properties for quality assurance and regulatory compliance.
- Easy to Clean & Reusable: Can be backwashed, ultrasonically cleaned, or chemically regenerated – long service life reduces replacement costs.
- Customizable Options: Available in different thicknesses, frame materials, and dimensions upon request. Edge sealing or welding available.
| Parameter | Specification |
|---|---|
| Panel Size | 500 x 500 mm (±2 mm) |
| Material | 304 Stainless Steel |
| Filtration Rating | 50 Micron (absolute) |
| Thickness (typical) | 1.5 – 3.0 mm (customizable) |
| Max Operating Temperature | Up to 450°C (in oxidizing atmosphere) |
| Max Differential Pressure | Up to 20 bar (depending on support structure) |
| Frame Option | Without frame / with 304 SS frame / with gasket |
| Included Certificate | Mill Test Report (chemistry & mechanical properties) |
Typical Applications
- Chemical Processing: Catalyst recovery, liquid filtration, gas distribution.
- Pharmaceutical & Bio-tech: Sterile filtration, powder conveying, tablet compression.
- Food & Beverage: Beer / wine polishing, juice clarification, edible oil filtration.
- Water & Wastewater Treatment: Pre-filtration, membrane protection, sludge dewatering.
- Oil & Gas: Sand control, wellhead filtration, refinery process filters.
- General Industrial: Hydraulic oil filtration, compressed air cleaning, dust collection.
Each sintered mesh filter panel undergoes rigorous quality control before shipment. Our in-house testing includes pore size verification, burst pressure testing, and visual inspection to ensure defect-free surfaces. The included Mill Test Report provides full traceability of the raw material, giving you confidence in the product's consistency.
Why Choose Boli Wiremesh?
With over 26 years of manufacturing experience (since 1998) and an annual export value of US$5–10 million, Anping County Boli Hardware Wiremesh Products Factory is a reliable partner for global buyers. Our factory is located in Hengshui, Hebei, China – the famous “Wire Mesh Capital” – which gives us access to premium raw materials and skilled labor. We ship from major ports including Tianjin, Qingdao, Shanghai, and Foshan, serving markets across North America, South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and more.
We are committed to delivering high-quality sintered filters at competitive prices. Our team can assist with custom sizes, special micron ratings, and frame configurations to meet your exact needs. Whether you require a single panel for testing or bulk orders for industrial projects, we are ready to support you with fast lead times and professional after-sales service.
Contact us today to request a quote, sample, or technical drawing. We look forward to building a long-term partnership with you.
Frequently Asked Questions
-
Q: Can this filter panel be used for high-temperature applications?
A: Yes, 304 stainless steel sintered panels can withstand temperatures up to approximately 450°C in oxidizing environments. For higher temperatures, we recommend 316L or 310S materials. -
Q: What is the typical thickness of the 500x500mm panel?
A: Standard thickness ranges from 1.5mm to 3.0mm, depending on the number of layers and filtration requirements. We can customize the thickness to meet your mechanical strength needs. -
Q: How do I clean the filter panel?
A: The panel can be cleaned by backwashing, ultrasonic cleaning, or chemical soaking (e.g., dilute acid for scale removal). Avoid using harsh mechanical abrasion that might damage the mesh structure. -
Q: Is the 50 micron rating absolute or nominal?
A: The 50 micron rating is absolute, meaning it will retain 99% of particles larger than 50 μm. Actual performance may vary slightly depending on the fluid and operating conditions. -
Q: Can you provide a sample for testing before bulk order?
A: Yes, we offer samples (e.g., 100x100mm or 200x200mm) at a reasonable cost. Please contact our sales team to discuss sample requirements and lead time. -
Q: What is the minimum order quantity?
A: For standard 500x500mm panels, the MOQ is typically 10 pieces. For custom sizes, MOQ may be higher. We can negotiate based on your project volume. -
Q: Does the Mill Test Report include chemical composition and mechanical properties?
A: Yes, the Mill Test Report (MTR) provides the exact chemical analysis (C, Mn, P, S, Si, Cr, Ni) and tensile/yield strength of the 304 SS material used. It is issued by the mill and traceable to the heat number. -
Q: How long is the delivery time?
A: For standard panels in stock, shipment can be arranged within 7-10 working days. For custom orders, lead time is usually 15-25 working days depending on quantity and complexity.
