Help CenterSintered Mesh Filter Tube, 60mm OD, 304 SS, 100 Micron, for Compressed Air Systems
Product Spotlights
Related Products
-
304 Stainless Steel Sintered Mesh Filter With 5μm Filtration Rating for Chemical ProcessingNegotiableMOQ: 1 Piece -
Sintered Porous Metal Filter Tube, 304 SS, 25mm OD, 20bar Pressure Rating, Standard CompliantNegotiableMOQ: 1 Piece
-
Sintered Filter Element for Pharmaceutical Filtration, 1μm, 304L, CIP/SIP CompatibleNegotiableMOQ: 1 Piece
-
Sintered Metal Fiber Felt Filter, 316L, 10μm, 0.5mm Thickness, High Porosity for Gas FiltrationNegotiableMOQ: 1 Piece
-
Sintered Mesh Filter With 1 Year Warranty, Mill Test Report Included, Custom Diameter AvailableNegotiableMOQ: 1 Piece
From Anping County Boli Hardware Wiremesh Products Factory — a trusted manufacturer established in 1998 with annual export value exceeding US$5 million — we proudly present our Sintered Mesh Filter Tube, designed specifically for compressed air systems. With a 60mm outer diameter, 304 stainless steel construction, and 100 micron filtration rating, this filter tube delivers reliable particle removal and long service life. Our products are exported to over 20 countries including North America, Europe, and Southeast Asia, backed by decades of sintering expertise.
This sintered mesh filter element is manufactured using multi-layer stainless steel wire mesh that is bonded through a high-temperature sintering process, creating a rigid, porous structure with exceptional mechanical strength and uniform pore distribution. The 100 micron rating ensures efficient removal of solid contaminants such as dust, rust, and pipe scale from compressed air, protecting downstream equipment like pneumatic tools, valves, and instruments.
Key Features & Technical Specifications
- Material: Premium 304 stainless steel — corrosion-resistant, suitable for moist compressed air environments.
- Outer Diameter: 60mm (other diameters available upon request).
- Filtration Rating: 100 micron (nominal, absolute filtration performance available).
- Temperature Resistance: Capable of operating up to 450°C (depending on seal material, optional high-temp seals).
- Reusable & Cleanable: Can be backwashed or ultrasonically cleaned for extended service life.
- Customizable Ends: End caps can be welded, threaded, or flanged to match your system.
- Length Options: Standard lengths from 100mm to 1500mm; custom lengths available.
- Low Pressure Drop: Optimized mesh structure minimizes flow resistance, saving energy.
| Parameter | Value |
| Outer Diameter | 60mm |
| Inner Diameter | Customizable (typically 50mm) |
| Filtration Rating | 100 microns |
| Operating Pressure | Up to 10 bar (higher available) |
| Temperature Range | -20°C to +450°C (with proper seals) |
| Connection Type | Customizable |
| Standard Length | 500mm (other lengths available) |
Benefits for Your Compressed Air System
- Enhanced Equipment Protection: Removes particles down to 100 microns, preventing wear in pneumatic tools and actuators.
- Reduced Maintenance Costs: Cleanable design reduces replacement frequency compared to disposable filters.
- Consistent Air Quality: Uniform pore structure ensures stable filtration performance over time.
- Energy Efficiency: Low pressure drop design minimizes compressor workload.
- Versatile Mounting: End connections can be customized to fit existing filter housings.
Backed by Anping County Boli Hardware Wiremesh Products Factory, which has been serving global clients since 1998, our sintered mesh filter tubes are manufactured in our own facility in Hengshui, Hebei, China. With an annual export value of US$5-10 million and shipments to major markets worldwide (North America, Europe, Asia, Africa, Oceania), we have the capacity and expertise to meet your volume and quality requirements. We offer flexible customization options, competitive pricing, and reliable delivery via Tianjin, Qingdao, Shanghai, or Foshan ports.
Contact us today to discuss your specific filtration needs — we can provide samples, technical drawings, and bulk pricing. Choose Boli for durable, high-performance sintered mesh filter tubes that keep your compressed air systems running smoothly.
FAQ
- What is the difference between sintered mesh and woven mesh filter tubes? Sintered mesh is made by bonding multiple layers of woven wire mesh under high temperature and pressure, creating a rigid, porous structure with higher strength and more uniform pore size. It is ideal for high-pressure and high-temperature applications like compressed air systems.
- Can this filter tube be cleaned and reused? Yes, the 304 stainless steel sintered mesh can be cleaned by backwashing, ultrasonic cleaning, or chemical cleaning. Proper cleaning can restore most of the filtration capacity, reducing replacement costs.
- What is the maximum operating temperature? The sintered mesh itself can withstand up to 450°C, but the temperature limit of the complete assembly depends on the end cap seals. We offer various seal materials (e.g., silicone, Viton) to match your temperature requirements.
- Do you offer custom lengths and diameters? Yes, we provide customization. Standard outer diameter is 60mm, but we can produce other sizes. Lengths can be tailored from 100mm to 1500mm. Please contact us with your specifications.
- How do I install this filter element into my existing housing? The filter tube can be supplied with end caps that match your housing — threaded, flanged, or plain ends for compression fittings. We recommend providing your housing dimensions so we can recommend the best connection type.
- What is the pressure drop across this filter at typical flow rates? The pressure drop depends on the flow rate, fluid viscosity, and filter length. For a 500mm long tube at 100 microns, the pressure drop in air at 7 bar is typically less than 0.2 bar at recommended flow rates. We can provide a detailed pressure drop curve upon request.
- Can this filter be used for liquids other than compressed air? Yes, the 304 stainless steel construction is suitable for many liquids (water, oils, chemicals) as long as they are compatible with stainless steel. However, always verify material compatibility for your specific fluid.
- What is the minimum order quantity (MOQ)? MOQ depends on the size and customization. For standard size 60mm OD x 500mm length, MOQ is typically 50 pieces. For custom sizes, please inquire.
