At Anping Xinye Metal Wire Mesh Products Co., Ltd, we specialize in manufacturing high-quality Reverse Dutch Woven Stainless Steel Mesh Belt Filter Screens designed for demanding industrial filtration applications. Our expertise in precision weaving ensures that each belt delivers exceptional filtration efficiency, mechanical strength, and long service life. Whether you need to separate solids from liquids, dewater slurries, or filter fine particles, our mesh belt screens are engineered to meet your exact requirements.
The Reverse Dutch Woven weave structure features a tight, fine mesh with a high density of warp wires, creating a smooth surface and excellent particle retention. This design allows for optimal flow rates while capturing even the smallest contaminants. Below, we detail the key features, specifications, and benefits of our product.
Key Features & Benefits
- High Filtration Precision: The reverse Dutch weave provides a precise filtration rating from 10 to 100 microns, ensuring effective removal of fine particles in various industrial processes.
- Exceptional Mechanical Strength: Made from high-quality stainless steel (304, 316, or 316L), our belts withstand high tensile loads, abrasion, and continuous operation under harsh conditions.
- Excellent Permeability: The unique weave design balances filtration efficiency with high flow rates, reducing pressure drop and improving throughput.
- Customizable Dimensions: We offer belts in any width (from 500mm to 3000mm) and length, with customizable edge finishes (clasp, spiral, or welded) to fit your equipment.
- Corrosion & Heat Resistance: Stainless steel construction ensures resistance to chemicals, moisture, and temperatures up to 600°C (depending on grade), making it suitable for aggressive environments.
- Easy Maintenance & Long Lifespan: The smooth surface and robust weave reduce clogging and facilitate cleaning, extending the belt's operational life.
Technical Specifications
| Parameter | Details |
|---|---|
| Weave Type | Reverse Dutch Woven (also known as Dutch Twill) |
| Material | Stainless Steel 304, 316, 316L (other alloys available on request) |
| Mesh Count (Warp x Weft) | 20 x 100, 30 x 150, 40 x 200, 50 x 250, 60 x 300 (customizable) |
| Wire Diameter (Warp) | 0.2mm – 1.0mm |
| Wire Diameter (Weft) | 0.1mm – 0.8mm |
| Belt Width | Customizable (typically 500mm – 3000mm) |
| Belt Length | Customizable per customer specifications |
| Filtration Rating | 10 – 100 microns (depending on mesh count) |
| Maximum Operating Temperature | Up to 600°C (for SS 316L) |
| Surface Finish | Annealed, pickled, or polished (optional) |
| Edge Connection | Clasp, spiral, or welded (optional) |
Detailed Product Description
Our Reverse Dutch Woven Stainless Steel Mesh Belt Filter Screen is a precision-engineered product used in continuous filtration processes such as sludge dewatering, food processing, chemical manufacturing, mineral processing, and wastewater treatment. The reverse Dutch weave (also known as Dutch twill) creates a dense, smooth filtering surface with a high percentage of warp wires, which provides a high level of particle retention while maintaining good flow permeability.
The belt is manufactured by weaving stainless steel wires in a special pattern where the warp wires are thicker and more numerous than the weft wires, resulting in a tight, wedge-shaped gap that traps particles effectively. This design allows for high cake discharge efficiency and low blinding, making it ideal for applications where consistent filtration performance is critical.
Each belt is custom-made to fit your specific filtration equipment, whether it is a belt filter press, vacuum belt filter, or other continuous filtration system. We can produce belts with various edge connections: clasp edges for easy installation, spiral edges for enhanced flexibility, or welded edges for maximum strength. The belt can also be supplied with guide pins or perforations if required.
Key advantages of using our Reverse Dutch Woven mesh belt:
- Superior particle capture with minimal pressure drop, improving overall system efficiency.
- High tensile strength (up to 30 kN/m depending on specification) for heavy-duty industrial use.
- Excellent resistance to chemicals, acids, alkalis, and high temperatures, ensuring long-term reliability.
- Smooth surface reduces wear on seals and scraper blades, lowering maintenance costs.
- Customizable weave patterns allow optimization for specific particle sizes and flow rates.
- Available in a range of stainless steel grades to suit different environments (304 for general use, 316 for chloride resistance, 316L for enhanced weldability).
We also offer additional processing options such as annealing (to relieve stress and improve flexibility), pickling (to remove surface impurities), and polishing (to achieve a smoother finish). These treatments can be tailored to your specific application needs.
Why Choose Anping Xinye?
Anping Xinye Metal Wire Mesh Products Co., Ltd is a leading manufacturer based in Hengshui, Hebei, China, with over 20 years of experience in wire mesh production. We have a dedicated R&D team, advanced weaving looms, and strict quality control processes to ensure that every mesh belt meets the highest standards. Our products are exported to more than 30 countries and are widely used in mining, chemical, food, and environmental protection industries.
We have a production capacity of over 200,000 square meters per year, allowing us to handle both small custom orders and large-volume contracts. Our quality management system includes incoming material inspection, in-process monitoring, and final testing of mesh count, tensile strength, and filtration accuracy. We also provide free samples for evaluation and offer technical support to help you select the best belt for your application.
Contact us today to discuss your filtration requirements. Our team is ready to provide a customized solution with competitive pricing and fast delivery. Choose Anping Xinye for reliable, durable, and high-performance mesh belt filter screens.
Frequently Asked Questions (FAQ)
Q1: What is the difference between Reverse Dutch Woven and Plain Dutch Woven mesh?
A: Reverse Dutch Woven has a higher number of warp wires per inch, creating a denser filtration surface with smaller openings. It is ideal for fine filtration, while Plain Dutch Woven has a more open weave for coarser filtration.
Q2: Can I get a custom mesh count for my specific application?
A: Yes, we offer customizable mesh counts and wire diameters to meet your exact filtration requirements. Please provide your desired particle size or flow rate, and we will recommend the optimal specification.
Q3: What edge types are available for the belt?
A: We offer clasp, spiral, and welded edges. Clasp edges are easy to install and replace; spiral edges provide flexibility for belts that need to track around pulleys; welded edges offer maximum strength for heavy loads.
Q4: How do I determine the correct belt width for my filter press?
A: The belt width should match the width of your filter press or conveyor. We recommend measuring the existing belt or providing the machine model. We can also manufacture belts slightly wider to allow for trimming.
Q5: What is the maximum temperature the belt can withstand?
A: For stainless steel 316L, the belt can operate continuously at temperatures up to 600°C. For 304 grade, the maximum temperature is around 500°C. Higher temperatures may require special alloys.
Q6: Do you offer samples for testing before bulk order?
A: Yes, we provide free samples of small mesh pieces (e.g., 300mm x 300mm) for evaluation. You only need to pay for shipping. Larger sample belts can be provided at cost.
Q7: What is the typical lead time for a custom belt?
A: Lead time depends on complexity and quantity. For standard specifications, production takes 10–15 working days. For custom orders with special edges or dimensions, allow 15–25 working days. We can expedite for urgent projects.
Q8: How do I clean and maintain the mesh belt?
A: The belt can be cleaned with water or mild detergents. For stubborn residues, use a soft brush or high-pressure water jet. Avoid using harsh chemicals that may damage the stainless steel. Regular inspection for wear is recommended.
