Anping Xinye Metal Wire Mesh Products Co., Ltd, based in Hengshui, Hebei, China, is a professional manufacturer specializing in light steel structures and metal grating products. Our Light Steel Structure Platform with Grating, Handrails, and Treads is designed to provide a safe, durable, and cost-effective solution for elevated walkways, industrial catwalks, mezzanine floors, and maintenance platforms. Combining high-strength light steel framing with anti-slip grating and secure handrails, this platform ensures both reliability and ease of installation.
Each platform is fabricated from high-quality steel, with options for hot-dip galvanizing or durable paint finishes to resist corrosion in harsh environments. The integrated grating surface offers excellent drainage, light transmission, and slip resistance, while the handrails and treads meet standard safety requirements. Whether for indoor factories, outdoor plants, or commercial buildings, our platform can be customized to fit your specific dimensions and load needs.
Key Features & Benefits
- Lightweight yet Strong – The use of light steel sections reduces overall weight without compromising structural integrity, making transport and assembly easier.
- Anti-Slip Grating – Welded steel grating with serrated or plain bars provides a safe walking surface, even in wet or oily conditions.
- Secure Handrails & Treads – Handrails (height optional) and chequered plate treads at entry points ensure worker safety and compliance with workplace safety standards.
- Corrosion Resistance – Hot-dip galvanized finish offers long-term protection against rust and weathering, ideal for outdoor use.
- Modular Design – Prefabricated components with bolt-together connections allow quick on-site assembly, reducing labor costs and downtime.
- Customizable Dimensions – Length, width, height, load capacity, and accessory options can be tailored to your project requirements.
Technical Specifications
| Parameter | Details |
|---|---|
| Main Frame Material | Q235 / Q345 light steel channel, angle, or H-beam |
| Grating Type | Welded steel grating (25×3, 30×3, 40×4, etc.) |
| Surface Treatment | Hot-dip galvanized, epoxy paint, or powder coating |
| Load Capacity | Customizable, typically 200 – 500 kg/m² (higher available) |
| Handrail Height | 1.0m or 1.2m (standard), with mid-rail and toe board |
| Tread | Chequered steel plate or expanded metal, anti-slip |
| Connection | Bolted or welded, with all mounting hardware included |
Typical Applications
- Industrial catwalks and walkways above production lines
- Mezzanine floors for storage or workstations
- Maintenance platforms around machinery or tanks
- Observation decks in warehouses or logistic centers
- Outdoor platforms for valve access, pipe racks, etc.
At Anping Xinye Metal Wire Mesh Products Co., Ltd, we have over 15 years of experience in the metal fabrication industry. Our factory is equipped with advanced welding and galvanizing lines, ensuring consistent quality and timely delivery. We have supplied similar platforms to clients in Europe, Southeast Asia, and the Middle East, receiving positive feedback on product performance and after-sales service. We offer flexible customization options, from simple standard sizes to complex multi-level structures. All products undergo strict quality inspection before shipment. Contact us today for a competitive quotation and technical support. Let us help you build a safer and more efficient working environment.
Frequently Asked Questions
1. What is the maximum load capacity of this platform?
Our platform can be engineered to support 200-500 kg/m² as standard, and higher capacities are available upon request. We will calculate the profile size and grating thickness based on your specific load requirements.
2. Can the platform be used outdoors?
Yes, when finished with hot-dip galvanizing, it is suitable for outdoor use, resisting corrosion from rain, humidity, and UV exposure. We also offer painted options for indoor use.
3. How is the platform installed?
Most components are pre-drilled and bolted together for quick assembly. Detailed installation drawings and instructions are provided. Welding can also be used for permanent installations.
4. Are the handrails removable or adjustable?
Handrails are fixed during installation but can be designed as detachable sections for easy maintenance access. Custom heights are available.
5. Do you offer custom sizes?
Absolutely. We can manufacture any length, width, and height to fit your project. Please provide dimensions and load requirements for a tailored solution.
6. What is the lead time for a standard order?
For standard sizes, lead time is typically 15-20 working days after order confirmation. Custom orders may take 20-30 days depending on complexity.
7. Do you provide certificates or test reports?
We can provide material certificates, galvanizing thickness test reports, and load test reports upon request. Please indicate your requirements when placing an order.
8. How do I maintain the platform?
Galvanized platforms require minimal maintenance – occasional cleaning with water. For painted platforms, touch-up paint may be needed after years of use.
