Deqing Leixin Coating Equipment Co., Ltd. is proud to introduce our Energy-Saving Gas-Fired Powder Coating Line, specifically designed for mechanical equipment with a maximum operating temperature of 180°C. As a dedicated manufacturer since 2011, we combine over a decade of engineering expertise with advanced gas-fired technology to deliver a coating solution that reduces energy consumption while maintaining superior curing performance. This line is ideal for manufacturers seeking to lower operational costs, improve production efficiency, and achieve consistent, high-quality powder finishes on heavy-duty parts.
Our gas-fired powder coating system integrates a high-efficiency burner and optimized airflow design to ensure rapid heat transfer and uniform temperature distribution across the curing oven. The result is a significant reduction in natural gas usage compared to conventional electric ovens, directly translating to lower energy bills and a smaller carbon footprint. With a maximum temperature of 180°C, this line is perfectly suited for curing standard thermosetting powder coatings on mechanical equipment such as engine blocks, brackets, frames, and other industrial components.
Key Features & Technical Specifications
- Energy-Efficient Gas Heating: Utilizes advanced gas burners with up to 92% thermal efficiency, reducing energy costs by 30-40% compared to electric systems.
- Precise Temperature Control: PLC-based PID control ensures temperature accuracy within ±2°C, crucial for consistent curing and coating adhesion.
- High-Temperature Uniformity: Oven design with multi-zone circulation fans guarantees temperature deviation less than ±5°C across the entire workspace.
- Durable Construction: Oven panels made of anti-corrosion steel with 100mm thick rock wool insulation for minimal heat loss.
- Flexible Conveyor System: Overhead monorail or floor-mounted chain conveyors available, with adjustable speed from 0.5 to 5 m/min.
- Integrated Powder Booth: Cartridge or cyclone recovery system options to maximize powder utilization and minimize waste.
- Safety Compliance: Equipped with automatic flame failure detection, gas leak alarms, and emergency stop systems.
- Customizable Line Length: Standard modules from 10m to 30m, with expansion options to fit different production volumes.
| Parameter | Specification |
|---|---|
| Max Curing Temperature | 180°C (adjustable from 80°C to 180°C) |
| Heating Source | Natural gas / LPG (dual fuel optional) |
| Oven Dimensions (W x H) | Customizable, e.g., 1.5m x 2.0m (standard) |
| Conveyor Speed | 0.5 – 5.0 m/min (variable frequency drive) |
| Powder Recovery Efficiency | ≥ 95% (with cartridge filter system) |
| Control System | Siemens PLC + HMI touchscreen |
| Voltage | 380V/50Hz (customizable) |
| Certification | ISO9001:2015 |
Advantages for Your Production
By choosing our Energy-Saving Gas-Fired Powder Coating Line, you gain:
• Lower Operating Costs: Gas is generally more economical than electricity in many regions, and our efficient burner design reduces fuel consumption by up to 40% compared to standard gas ovens.
• Faster Heat-Up Time: The system reaches 180°C within 10-15 minutes, minimizing idle time between batches.
• Consistent Finish Quality: Uniform temperature eliminates hot spots, ensuring every part cures evenly for a smooth, durable coating.
• Scalability: Modular design allows easy expansion as your production needs grow.
• Reduced Environmental Impact: Lower CO₂ emissions and less powder waste contribute to a greener manufacturing process.
Company Trust & Reliability
Deqing Leixin Coating Equipment Co., Ltd. is a professional manufacturer with a factory spanning 1,000–3,000 square meters and a dedicated team of 51–100 employees. Since our establishment in 2011, we have exported coating lines to over 15 countries across North America, Europe, Southeast Asia, Africa, and Oceania, with an annual export value of US$1–1.5 million. Our products are ISO9001 certified, reflecting our commitment to quality management and continuous improvement. We ship from major ports like Ningbo and Shanghai, ensuring timely delivery worldwide.
Our team provides comprehensive after-sales support, including installation guidance, commissioning, and operator training. We are ready to customize the line to your specific mechanical equipment requirements — from conveyor layout to oven dimensions. Contact us today to discuss your project and receive a competitive quotation!
Frequently Asked Questions (FAQ)
-
What is the maximum workpiece size this line can handle?
Our standard oven opening is 1.5m wide x 2.0m high, but we can customize the oven dimensions to accommodate larger parts. Please provide your specific part dimensions for a tailored solution. -
Can I use this line for both liquid and powder coating?
This model is optimized for powder coating. If you need a combined liquid/powder system, we can discuss modifications such as adding a flash-off tunnel. -
How much natural gas does the burner consume per hour?
Consumption depends on oven size and temperature setpoint. For a typical 10m oven at 180°C, the consumption is approximately 15–25 m³/h. A detailed energy calculation can be provided based on your line configuration. -
Is the temperature control suitable for low-temperature curing powders?
Yes, the temperature can be precisely adjusted from 80°C to 180°C, making it compatible with both standard and low-cure powder coatings. -
Do you provide installation and training services?
We offer on-site installation supervision and training for your operators. Alternatively, remote technical support is also available. -
What is the typical payback period for the energy savings?
Based on customer feedback, the energy cost savings often pay back the investment in 12–18 months, depending on local gas prices and production volume. -
Can I integrate my existing conveyor system with this line?
Our design is modular and can be adapted to interface with most conveyor systems. We will work with your existing equipment to ensure seamless integration. -
What safety certifications does the line have?
Our equipment complies with general industrial safety standards and is built under ISO9001 quality management. Specific safety certifications for gas appliances can be provided as per your local regulations.
