Help CenterCustomized Dust Filter Cartridge for Welding Fume Extraction High Dust Holding Capacity
Product Spotlights
Related Products
-
Customized Dust Filter Cartridge 350mm x 660mm Pulse Jet Cleaning With Increased AirflowUS$ 0.8 - 1MOQ: 1 Unit -
Customized Dust Filter Cartridge 304 Stainless Steel End Caps 260°C Heat Resistant for Industrial Dust CollectorUS$ 0.8 - 1MOQ: 1 Unit
-
Customized Dust Filter Cartridge With Technical Installation Support and Mill Test ReportUS$ 0.8 - 1MOQ: 1 Unit
-
Customized Dust Filter Cartridge 1 Micron Pleated PTFE Coated Filter Media 100% PolyesterUS$ 0.8 - 1MOQ: 1 Unit
-
Customized Dust Filter Cartridge 300°C Heat Resistant With Mill Test Report for Baghouse Dust CollectorUS$ 0.8 - 1MOQ: 1 Unit
Welcome to Anping County Boli Hardware Wiremesh Products Factory – a trusted manufacturer since 1998, specializing in filtration solutions for industrial environments. Our Customized Dust Filter Cartridge for Welding Fume Extraction is engineered to capture fine welding fumes, grinding dust, and other airborne particles with exceptional efficiency. With a high dust holding capacity, this cartridge reduces replacement frequency and maintenance downtime, delivering consistent performance even in heavy-duty applications. Backed by decades of manufacturing expertise and a strong export track record to global markets, we offer tailor-made solutions that fit your exact system requirements.
Every cartridge is built with premium materials and advanced pleating technology to maximize surface area. The result is a robust filter that combines high filtration efficiency with low airflow resistance. Below are the key features and technical specifications:
- High Dust Holding Capacity – Up to 15 kg of dust per cartridge, significantly extending service life compared to standard filters.
- Customizable Dimensions – Diameter, length, end cap style, and gasket material can be tailored to your existing housing or extraction system.
- Advanced Filtration Media – Polyester/cellulose blend with optional anti-static or oleophobic treatment for welding fume applications.
- Filtration Efficiency – 99.9% at 0.5 micron particle size, ensuring clean air discharge and worker safety.
- Low Pressure Drop – Optimized pleat design maintains airflow while capturing contaminants, reducing energy consumption of your extraction system.
- Wide Temperature Range – Operates continuously up to 135°C, suitable for hot welding fumes.
- Easy Installation – Compatible with most standard cartridge collectors; retrofit kits available upon request.
- Eco-Friendly – Fully incinerable or recyclable construction, minimizing waste disposal costs.
| Parameter | Standard Value | Customizable Range |
| Outer Diameter | 325 mm | 200–450 mm |
| Length | 660 mm | 400–1200 mm |
| Filtration Area | 22 m² | 15–35 m² |
| Initial Pressure Drop | 60 Pa | Depends on media |
| Weight | ~5.5 kg | Varies with size |
Why choose our customized dust filter cartridge? The welding fume extraction process demands a filter that can handle heavy loads, fine particles, and high temperatures without clogging. Our cartridge addresses these challenges with a rugged construction and high dust holding capacity that reduces the number of filter changes required. This translates to lower operational costs, less downtime, and improved productivity for your facility. Additionally, the customizable nature ensures perfect compatibility with both new and existing dust collection systems, eliminating the need for costly modifications.
Our factory has been serving the global market for over 25 years, exporting to North America, Europe, Southeast Asia, Africa, and many other regions. With an annual export value of US$5–10 million, we have established a reputation for reliable quality and on-time delivery. We ship from ports including Tianjin, Qingdao, Shanghai, and Foshan, ensuring efficient logistics to any destination. Whether you need a standard cartridge or a fully customized design, our engineering team will work closely with you to meet your specific requirements.
Ready to improve your welding fume extraction efficiency? Contact us today for a quote or technical consultation. Our dedicated sales team will provide prompt support, sample availability, and detailed drawings. Trust Anping County Boli Hardware Wiremesh Products Factory – your partner in clean air solutions.
Frequently Asked Questions
-
What is the typical lifespan of this filter cartridge?
Lifespan depends on dust concentration and maintenance. With high dust holding capacity, you can expect 2–4 times longer service life than standard cartridges under similar conditions. -
Can I get a sample before bulk order?
Yes, samples are available. We can provide a customized sample for testing, with lead time typically 7–10 working days. -
What filter media options are available for welding fume?
We offer polyester, cellulose, and blended media. Anti-static or oleophobic treatments are optional for oil-mist or explosive dust environments. -
How do I know the correct dimensions for my system?
Please provide the inner/outer diameter, length, and end cap type of your current cartridge. We can also work from a drawing or photo of your housing. -
Is this cartridge suitable for high-temperature welding fumes?
Yes, the standard media can withstand continuous temperatures up to 135°C. For higher temperatures, we can recommend specialized media (e.g., aramid fiber). -
What is the minimum order quantity (MOQ)?
Our MOQ for standard sizes is 10 pcs. For customized dimensions, MOQ may be 50 pcs. Please contact us for details. -
Do you provide pulse-jet cleaning compatibility?
Yes, the cartridge is designed for pulse-jet cleaning systems. We can also supply pre-assembled cages or venturi if needed. -
What certifications do you have?
Our manufacturing process follows strict quality control standards. Specific certifications can be discussed upon request; we comply with international filtration norms.
