As a leading manufacturer based in Hengshui, Hebei, China, Anping County Boli Hardware Wiremesh Products Factory (established in 1998) takes pride in offering high-quality filtration solutions for global industrial clients. Our Customized Dust Filter Cartridge 304 Stainless Steel Pleated 0.5μm Efficiency 99.99% is engineered to deliver exceptional performance in demanding dust collection systems. With over two decades of expertise and an annual export value of US$5 million to US$10 million, we combine precision manufacturing with flexible customization to meet your specific requirements.
This filter cartridge is constructed from premium 304 stainless steel, offering excellent corrosion resistance, high strength, and durability even in harsh industrial environments. The pleated design significantly increases the filtration surface area, allowing for higher dust holding capacity and longer service life. With a filtration precision of 0.5 microns and an efficiency of 99.99%, it effectively captures fine dust particles, ensuring clean air discharge and compliance with stringent environmental regulations. Whether you need a standard size or a fully customized solution, our factory is ready to deliver.
Key Features & Technical Specifications
- Material: 304 Stainless Steel – resistant to rust, high temperature, and chemical corrosion, suitable for food, pharmaceutical, chemical, and heavy industries.
- Filtration Precision: 0.5 μm – captures sub-micron particles, including dust, smoke, and powder.
- Filtration Efficiency: 99.99% – tested according to industry standards, ensuring minimal emissions.
- Pleated Structure: Increases effective filtration area by 3–5 times compared to standard flat filters, reducing pressure drop and energy consumption.
- Customizable Dimensions: Outer diameter, inner diameter, length, and flange type can be customized to fit your dust collector housing.
- High Temperature Resistance: Standard working temperature up to 200°C; higher temperature options available upon request.
- Easy Maintenance: The pleated metal mesh can be cleaned by backwashing or ultrasonic cleaning, extending service life and reducing replacement costs.
- Sealing Options: Available with gasket, O-ring, or other sealing methods to prevent bypass leakage.
Technical Parameters (Standard & Custom)
| Parameter | Standard Value | Customizable Range |
| Outer Diameter | 100 mm, 150 mm, 200 mm | 50–500 mm |
| Length | 500 mm, 1000 mm | 200–2000 mm |
| Filtration Area | Up to 2.5 m² per cartridge (depending on size) | Custom |
| Pleat Height | 20 mm, 30 mm, 40 mm | 10–60 mm |
| Mesh Count | 200 mesh, 300 mesh, 400 mesh | 50–500 mesh |
| Max Working Temperature | 200°C | Up to 400°C (with special material) |
| Max Working Pressure | 0.6 MPa | 0.1–1.0 MPa |
Advantages for Your Business
- Cost-Effective: The pleated design extends the interval between cleanings, reducing downtime and maintenance costs. The reusable stainless steel structure eliminates frequent replacement expenses.
- Energy Saving: Lower pressure drop means less energy consumption for your dust collector fan, resulting in operational savings.
- Environmentally Friendly: The high efficiency (99.99%) ensures that fine particles are captured, helping you meet emission standards and protect the environment.
- Versatile Application: Suitable for various dust types: metal powders, chemical powders, food ingredients, cement, wood dust, and more. Compatible with most industrial dust collectors (baghouse, cartridge, or cyclone systems).
- Customization: We offer complete customization – size, mesh count, sealing type, end caps, and surface finish. You provide the requirements, we deliver the perfect fit.
Why Choose Anping County Boli Hardware Wiremesh Products Factory?
With our factory established in 1998, we have accumulated extensive experience in wire mesh and filtration manufacturing. Our products are exported to major markets including North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East, with an annual export value of US$5 million to US$10 million. We ship from multiple ports (Tianjin, Qingdao, Shanghai, Foshan) to ensure fast and cost-effective logistics. Every filter cartridge undergoes strict quality control from raw material to final inspection. We are not just a supplier – we are your long-term partner in air quality control.
Our 0.5μm 99.99% efficiency dust filter cartridge is the result of continuous innovation and customer feedback. Whether you require a standard size or a fully customized design, we are ready to provide samples and support. Contact us today to discuss your specific needs and receive a competitive quotation.
Frequently Asked Questions
-
Q: Can you customize the dimensions of the dust filter cartridge?
A: Yes, we offer full customization. You can specify outer diameter, inner diameter, length, flange type, and sealing method. We will produce according to your drawings or samples. -
Q: What is the typical lifespan of this stainless steel filter cartridge?
A: The lifespan depends on the dust concentration, cleaning frequency, and maintenance. Under normal conditions, it can last 1–3 years or more. The pleated stainless steel mesh can be cleaned by backwashing or ultrasonic cleaning, extending its service life. -
Q: Is this filter cartridge suitable for high-temperature applications?
A: The standard 304 stainless steel can withstand temperatures up to 200°C. For higher temperatures (up to 400°C), we can use 316L stainless steel or other heat-resistant materials. -
Q: How do I clean the filter cartridge?
A: Depending on the dust type, you can use compressed air blowback, water washing, or ultrasonic cleaning. We recommend following the instructions provided with the product. The cartridge is designed for easy removal and cleaning. -
Q: What types of dust can this filter handle?
A: It is suitable for a wide range of dry dusts, including metal powders, chemical powders, cement, coal, wood dust, food ingredients, and pharmaceutical powders. For sticky or oily dust, please consult us for special surface treatment options. -
Q: Do you offer samples for testing?
A: Yes, we provide samples. You can order a small quantity for trial before mass production. Sample cost is negotiable, and we can deduct it from the formal order. -
Q: What is the minimum order quantity (MOQ)?
A: Our MOQ is flexible. For standard sizes, we can accept small orders. For custom designs, the MOQ depends on the complexity. Please contact us for details. -
Q: How do you ensure the filtration efficiency of 99.99%?
A: We use precision weaving and quality control processes. Each batch is tested using particle counters to verify the 0.5μm efficiency. Test reports are available upon request.
Contact us today to get a customized solution for your dust collection system. We are ready to serve you with professional support and competitive pricing.
