Help CenterCIPP Pipe Liner Machine With 3.5kW Motor, Automatic Tensioning, and Digital Control for 50-600mm Pipes
Product Spotlights
Related Products
-
Hot Water Curing CIPP Liner Machine With Temperature Control up to 95°C for 150-800mm PipelinesNegotiableMOQ: 1 Piece -
CIPP Liner Machine for Sewer Pipe Rehabilitation, Suitable for 150-500mm Clay and Concrete PipesNegotiableMOQ: 1 Piece
-
UV CIPP Lining Machine PLC Automatic Control UV CIPP Equipment For Underground Sewer Pipe RenovationNegotiableMOQ: 1 Piece
-
CIPP Pipe Lining Machine for Industrial Wastewater Pipe Repair, With 1000m Liner Capacity and Heated DrumNegotiableMOQ: 1 Piece
-
Steam Curing CIPP Liner Machine With 6kW Heating Element and 0.8MPa Pressure for Municipal Sewer RepairNegotiableMOQ: 1 Piece
Qingdao Yongke Machinery Co., Ltd, established in 2010, is a professional manufacturer specializing in trenchless pipe rehabilitation equipment. With a factory area of 10,000–30,000 square meters and a team of 51–100 experienced employees, we have been delivering high-quality CIPP solutions to global markets. Our CIPP Pipe Liner Machine with 3.5kW Motor, Automatic Tensioning, and Digital Control is designed for efficient and precise lining of pipes ranging from 50mm to 600mm in diameter. This machine integrates advanced digital control technology, ensuring consistent tension and reliable operation, making it an ideal choice for contractors and municipal pipeline rehabilitation projects.
Key Features & Technical Specifications
- Powerful 3.5kW Motor: Provides ample torque and speed control for pulling liners through various pipe conditions, ensuring smooth installation.
- Automatic Tensioning System: Maintains constant tension during the lining process, preventing liner damage and ensuring uniform thickness.
- Digital Control Panel: Intuitive interface with real-time monitoring of tension, speed, and distance, allowing operators to adjust parameters easily.
- Wide Pipe Diameter Range: Suitable for pipes from 50mm to 600mm, covering residential, commercial, and municipal applications.
- Robust Construction: Built with heavy-duty steel frame and corrosion-resistant components, ensuring long service life even in harsh job sites.
- Portable Design: Compact dimensions (1200×800×900 mm) and manageable weight (approx. 350 kg) allow easy transportation and setup.
- Energy Efficient: The motor is designed to optimize power consumption while delivering high performance, reducing operational costs.
Technical Parameters
| Parameter | Value |
| Motor Power | 3.5 kW |
| Pipe Diameter Range | 50 – 600 mm |
| Tension Control | Automatic, digital feedback |
| Control System | PLC + Touch Screen |
| Voltage | 380V/50Hz (customizable) |
| Machine Weight | Approx. 350 kg |
| Dimensions (L×W×H) | 1200 × 800 × 900 mm |
Benefits for Your Business
- Higher Productivity: The automatic tensioning and digital control reduce manual intervention, speeding up the lining process by up to 30% compared to manual machines.
- Consistent Quality: Real-time tension monitoring ensures even liner placement, minimizing defects and rework.
- User-Friendly Operation: The digital interface with preset programs makes it easy for operators of all skill levels to achieve professional results.
- Versatility: Handles a wide range of pipe diameters, allowing you to take on diverse projects without needing multiple machines.
- Durability and Reliability: Built with high-quality components and backed by our ISO9001-certified manufacturing process, the machine delivers long-term performance.
Trust & After-Sales Support
Qingdao Yongke Machinery Co., Ltd has been serving the global trenchless market since 2010. With an annual export value of US$1 million to US$1.5 million, our machines are exported to North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and many other regions. We hold certifications including ISO9001, ISO14000, and OHSAS18001, reflecting our commitment to quality, environmental management, and occupational health. Our port of shipment is Qingdao, ensuring efficient logistics. We offer comprehensive after-sales support, including online technical assistance, spare parts supply, and optional training programs. Choose our CIPP Pipe Liner Machine to enhance your pipeline rehabilitation capabilities with confidence.
Frequently Asked Questions
Q1: What pipe materials can this machine handle?
A: The machine is designed for CIPP lining of various pipe materials including concrete, clay, PVC, and metal pipes, as long as the inner diameter is between 50mm and 600mm.
Q2: Is the digital control panel easy to use?
A: Yes, it features a touch screen interface with intuitive icons and preset parameters. Operators can learn the basic operation within a few hours.
Q3: Can the machine be used for curved pipes?
A: Yes, the machine is suitable for straight and slightly curved pipes. For pipes with severe bends, we recommend consulting our technical team for specific guidance.
Q4: What is the maximum pulling force of the machine?
A: The maximum pulling force is approximately 5000 N, adjustable via the digital control system to suit different liner thicknesses and pipe diameters.
Q5: Does the machine come with a warranty?
A: Yes, we offer a standard 12-month warranty from the date of shipment, covering manufacturing defects. Extended warranty options are available upon request.
Q6: What voltage options are available?
A: The standard voltage is 380V/50Hz, but we can customize the machine for 220V/60Hz or other voltages based on your local requirements. Please inform us when placing an order.
Q7: How long does delivery take?
A: For standard models, delivery is typically 15–20 working days after order confirmation. Customized machines may take longer. We ship from Qingdao port.
Q8: Do you provide installation and training?
A: Yes, we provide online video tutorials and remote technical support during installation. On-site training can be arranged as an additional service if needed.
