Help CenterDouble-Groove Tungsten Carbide Wire Guide Wheel
Product Spotlights
2.Mirror polished arc grooves, no scratch on wire surface
3.Ultra high wear resistance, long service cycle
4.Low rolling friction, stable wire running & less breakage
5.Excellent red hardness, fit high-speed wire production
6.Custom OD, ID, groove radius & thickness available
Related Products
1. Product Introduction
This double-groove carbide wire guide wheel is an integral hollow ring with two smooth R arc wire grooves on the outer circumference, manufactured by powder metallurgy sintering and precision mirror grinding. It is core wear-resistant spare part for wire drawing, stranding and cable machinery, realizing dual-wire synchronous traction to boost production capacity.
2. Material & Production Process
Optional Grades: YG6, YG6X, YG8, YG10
Production Flow: WC-Co powder pressing → High temperature sintering → Precision inner & outer cylindrical grinding → Double arc groove forming → Mirror polishing
Surface Feature: Burr-free ultra-smooth groove surface, uniform dimensional tolerance
3. Core Advantages
✅ Dual-groove structure supports two wires processing simultaneously, improve machine efficiency
✅ Mirror polished groove inner wall, effectively prevent wire scratch and surface damage
✅ Hardness up to 88–92 HRA, wear resistance 5–10 times higher than steel rollers
✅ Convert sliding friction to rolling friction, stabilize wire tension and reduce wire breakage rate
✅ Good red hardness, maintain stable performance under continuous high-speed friction heat✅ Fully customizable size parameters, groove radian and surface finish
4. Main Application
Metal wire processing: Copper wire, steel wire, aluminum wire, stainless steel wire drawing & stranding machines
Cable industry: Power cable, control cable, optical fiber sheath production lines
Precision wire products: Welding wire, spring wire, fine precious metal wire traction
Textile industry: High-speed filament textile yarn guide equipment
5. Customization Service
Dimension: Custom outer diameter, inner bore diameter, overall thickness
Groove parameter: Adjustable groove quantity, R arc radius, groove spacing
Alloy grade: Tune cobalt content to match hard/soft wire processing
Surface: Matte finish or mirror polishing optional
