Plate Evaporator Crystallizer With Jacketed Heating, 304L, 1.5kW Agitator, CIP Cleaning Design, 200L Working Volume
Product Spotlights
High-grade 304L stainless steel plate evaporator crystallizer with 200L working volume, jacketed heating for precise temperature control, 1.5kW agitator for uniform crystallization, and CIP design for easy cleaning. Ideal for pilot-scale chemical, pharmaceutical, and food processing with proven reliability from an ISO-certified manufacturer.
US$ 21800 - 853000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Application:
Other, Evaporation & Crystallization
Material:
304L Stainless Steel
Working Volume:
200L
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
50 days
Related Products
-
Plate Evaporator Crystallizer for Pharmaceutical Solvent Recovery, 304L Stainless Steel, FDA Compliant Design, 100L BatchUS$ 21800 - 853000MOQ: 1 Combo -
304 Stainless Steel Plate Evaporator Crystallizer, 220V, PLC Automatic Control, 50L Capacity for Industrial ConcentrationUS$ 21800 - 853000MOQ: 1 Combo
-
Continuous Plate Evaporator Crystallizer, PLC Logic Control, 220V/50Hz, Inlet Flow 20L/min, Stainless Steel 304US$ 21800 - 853000MOQ: 1 Combo
-
MVR Plate Evaporator Crystallizer, Mechanical Vapor Recompression, 380V, 60Hz, Energy Saving up to 30%, 316 SSUS$ 21800 - 853000MOQ: 1 Combo
-
Forced Circulation Plate Evaporator Crystallizer, 0.5MPa Design Pressure, IP65 Control Box, 3-Separation StagesUS$ 21800 - 853000MOQ: 1 Combo
Application
Other, Evaporation & Crystallization
Material
304L Stainless Steel
Working Volume
200L
Heating Type
Jacketed Heating
Agitator Power
1.5kW
Cleaning Design
CIP (Clean-in-Place)
Brand
Qingdao Conqinphi
Customization
Available upon request
Welcome to the world of efficient and reliable evaporation and crystallization technology. As a leading manufacturer based in Qingdao, China, Qingdao Conqinphi Environmental Technology Group Co., Ltd. specializes in high-performance process equipment. Our Plate Evaporator Crystallizer with Jacketed Heating, 304L, 1.5kW Agitator, CIP Cleaning Design, 200L Working Volume is engineered to meet the demanding requirements of chemical, pharmaceutical, food, and environmental industries. Combining robust construction with intelligent design, this unit ensures optimal heat transfer, consistent crystal formation, and easy maintenance, helping you achieve higher yields and lower operating costs.
Key Features and Technical Specifications
The Plate Evaporator Crystallizer is designed for maximum efficiency and durability. Below are the core features and specifications:
- Superior Material: Constructed from high-grade 304L stainless steel, offering excellent corrosion resistance and longevity, suitable for a wide range of aggressive media.
- Efficient Jacketed Heating: The jacketed design provides uniform and controlled heating, essential for precise temperature management during evaporation and crystallization processes.
- Powerful Agitation: Equipped with a 1.5kW agitator that ensures thorough mixing and uniform concentration distribution, promoting consistent crystal growth and preventing scaling.
- CIP Cleaning Design: The clean-in-place (CIP) capability allows for automated cleaning without disassembly, minimizing downtime and maintaining hygiene standards.
- Optimal Working Volume: With a 200L working capacity, this crystallizer is ideal for pilot-scale production or small batch processing, offering scalability and flexibility.
- Plate Configuration: The plate-type heat exchanger design enhances heat transfer efficiency, reducing energy consumption and accelerating process cycles.
| Parameter | Value |
|---|---|
| Material | 304L Stainless Steel |
| Working Volume | 200 L |
| Heating Media | Steam / Hot Water / Thermal Oil (jacketed) |
| Agitator Power | 1.5 kW |
| Agitator Speed | Variable (adjustable) |
| Cleaning System | CIP (Clean-in-Place) compatible |
| Design Pressure | Atmospheric / Optional vacuum |
| Operating Temperature | Up to 150°C (customizable) |
| Weight (approx.) | 350 kg |
Detailed Advantages and Customer Benefits
- Enhanced Heat Transfer: The plate-type heat exchange surface area is maximized, providing faster heating and cooling rates compared to traditional coils. This leads to shorter batch times and increased throughput.
- Consistent Crystal Quality: The combination of precise temperature control via jacketed heating and efficient agitation ensures uniform supersaturation, resulting in crystals with narrow size distribution and high purity.
- Low Maintenance: 304L stainless steel resists pitting and crevice corrosion, reducing the need for frequent repairs. The CIP design eliminates manual cleaning, saving labor and reducing chemical exposure risks.
- Energy Efficiency: The compact plate design requires less heat transfer fluid volume, and the high-efficiency jacket minimizes heat loss. These features contribute to lower energy bills and a smaller environmental footprint.
- Flexible Operation: The variable-speed agitator (optional) allows you to adjust mixing intensity based on product viscosity and crystal size requirements. The unit can be operated under atmospheric or reduced pressure (vacuum option available upon request).
- Safe and Robust: All welds are performed by certified technicians, and the vessel is hydrostatically tested before delivery. Pressure relief devices and temperature sensors can be integrated as needed.
- Easy Scale-Up: Data obtained from this 200L unit can be reliably used to design larger production-scale crystallizers, thanks to our proven engineering methodology.
Trust and Reliability from Qingdao Conqinphi
Since our establishment in 2015, Qingdao Conqinphi Environmental Technology Group has grown into a modern enterprise with a factory size of 10,000–30,000 square meters and a dedicated team of 201–300 employees. Our annual export value exceeds US$10 million, and our products are shipped to North America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and many other regions. We hold multiple internationally recognized management system certifications including ISO9001, ISO14000, OHSAS18001, HACCP, SA8000, and others, demonstrating our commitment to quality, safety, and social responsibility. Every Plate Evaporator Crystallizer is manufactured under strict quality control procedures and backed by our experienced technical support team. We invite you to experience the difference that reliable engineering and customer-centric service can make. Contact us today to discuss your specific application requirements or request a detailed quotation.
Frequently Asked Questions
-
Q: What materials can be processed in this crystallizer?
A: The 304L stainless steel construction is suitable for most aqueous solutions, acids (except strong chlorides), alkalis, and organic solvents. For highly corrosive media, we offer optional upgrades to 316L or Hastelloy. Please consult our engineers for compatibility. -
Q: Can the CIP system be fully automated?
A: Yes, the CIP design includes spray balls and return connections. We can integrate a programmable logic controller (PLC) to automate the cleaning cycles. Standard CIP control panels are available as an add-on. -
Q: What is the maximum temperature the jacket can handle?
A: Standard design allows up to 150°C with thermal oil or steam. For higher temperature requirements (up to 250°C), we can design with special gaskets and insulation. Contact us for custom solutions. -
Q: Do you provide installation and commissioning services?
A: Yes, we offer on-site installation guidance and commissioning support for overseas clients. Our technical team can also provide remote assistance via video calls. Additional service packages are negotiable. -
Q: What is the typical lead time for this crystallizer?
A: Standard lead time is 30–45 days after order confirmation and receipt of down payment. Shorter lead times may be possible for urgent orders depending on workshop capacity. -
Q: Does the unit comply with international pressure vessel codes?
A: Our vessels are designed according to ASME VIII Div.1 or GB150 standards, as per customer preference. Certificates such as PED, CE, or ATEX can be provided at additional cost. Please specify your required standard when ordering. -
Q: Can I test my product in your facility before purchasing?
A: Absolutely. We have a pilot testing center in Qingdao where we can run trials with your material. We can also rent out demonstration units for on-site evaluation. -
Q: What warranty do you offer?
A: We provide a standard 12-month warranty from the date of shipment covering defects in materials and workmanship. Extended warranty plans are available upon request.
