Qingdao Conqinphi Environmental Technology Group Co., Ltd. — a professional manufacturer with over 8 years of experience in the environmental protection industry — introduces our Municipal Wastewater Ammonia Nitrogen Removal System designed specifically for sewage treatment plants with a capacity of 1,000 m³/day. This system efficiently removes ammonia nitrogen from municipal wastewater, meeting stringent discharge standards while ensuring stable operation and low maintenance. Built with advanced biological treatment technology, our solution offers a reliable, cost-effective way to upgrade your existing plant or build a new one.
Our system is engineered to address the challenges of high ammonia nitrogen loads in municipal sewage. By combining anoxic and aerobic zones, it promotes nitrification and denitrification processes, achieving removal rates of over 85% under normal operating conditions. The equipment is fully customizable to fit your site layout, existing infrastructure, and local regulations. Whether you need a retrofit or a greenfield installation, our team provides turnkey solutions from design to commissioning.
Key Features & Technical Specifications
- High Efficiency Biological Treatment: Utilizes activated sludge process with pre-anoxic zone for enhanced denitrification.
- Modular Design: Skid-mounted units available for quick installation; concrete tank options for permanent plants.
- Automated Operation: PLC-based control system with HMI touchscreen, allowing remote monitoring and adjustment.
- Low Energy Consumption: Optimized aeration system reduces power usage by up to 20% compared to conventional systems.
- Robust Construction: Main tank made of carbon steel with anti-corrosion coating or SS304 for harsh environments.
- Flexible Configuration: Can be integrated with existing treatment processes (e.g., MBR, MBBR) or used as a standalone unit.
- Easy Maintenance: Accessible inspection ports, sludge discharge valves, and easy-to-replace media.
| Parameter | Value |
|---|---|
| Design Flow Rate | 1,000 m³/day |
| Influent NH₃-N Concentration | ≤ 50 mg/L (customizable) |
| Effluent NH₃-N Concentration | ≤ 5 mg/L (adjustable to local standards) |
| Removal Efficiency | ≥ 85% |
| Operating Temperature | 5°C – 40°C |
| Power Supply | 380V / 50Hz (others available) |
| Control System | PLC + HMI (Siemens or Schneider) |
The system is designed to handle peak loads and variations in influent quality. A built-in equalization tank can be added to stabilize flow. Our standard package includes aeration system, submerged mixers, sludge recirculation pumps, and all necessary piping. Additional options such as chemical dosing units for phosphorus removal or disinfection can be integrated upon request.
Why Choose Our Ammonia Nitrogen Removal System?
- Proven Technology: Over 100 installations worldwide in municipal and industrial applications.
- Customized Solutions: Our engineering team tailors each system to site-specific conditions, including temperature, elevation, and effluent standards.
- Comprehensive Support: From feasibility study to installation, commissioning, and after-sales service, we provide end-to-end support.
- Energy Efficiency: Advanced aeration control and efficient pump selection reduce operating costs.
- Compliance with International Standards: Our manufacturing processes follow quality management systems (ISO 9001, ISO 14000, OHSAS 18001) and our products meet applicable environmental regulations.
As a manufacturer with a 10,000–30,000 m² factory and 200+ skilled employees, Qingdao Conqinphi Environmental Technology Group has been delivering reliable water treatment solutions since 2015. Our annual export value exceeds US$10 million, serving markets across North America, South America, Europe, Asia, Africa, and Oceania. We have successfully completed projects for municipalities, industrial parks, and private developers.
Trust our expertise: We hold multiple certifications including HACCP, TL900, QS9000, SA8000, ISO9001, ISO9004, ISO17799, ISO9000, ISO14000, ISO10441, ISO16949, TS16969, ISO19011:2000, OHSAS18001, among others. Your satisfaction is our priority. We invite you to contact us for a detailed proposal, technical drawing, or a site visit to discuss your specific requirements. Let us help you achieve efficient and compliant ammonia nitrogen removal for your sewage treatment plant.
Frequently Asked Questions
-
What is the typical footprint of the 1000m³/D system?
The footprint depends on the configuration (skid vs. concrete). For a standard A/O process, the required area is approximately 200–300 m², including aeration tanks and clarifier. We provide a customized layout drawing after site survey. -
Can this system handle high peaks of ammonia nitrogen?
Yes, the system is designed with a safety factor of 1.2–1.5. An equalization tank can be added to buffer fluctuations. We recommend providing the maximum influent concentration for accurate design. -
What is the expected lifespan of the equipment?
With proper maintenance, the carbon steel tank with anti-corrosion coating can last 15–20 years. SS304 components have a longer lifespan. Mechanical parts such as pumps and blowers typically require replacement after 8–10 years. -
Does the system include sludge handling?
We can integrate a sludge thickener, dewatering, or drying system as an optional add-on. The standard package includes a sludge recirculation line and a waste sludge outlet. -
What is the power consumption per day?
Estimated daily power consumption for a 1000m³/D system is between 150–250 kWh, depending on aeration demand and pump operation. An energy-efficient blower (e.g., magnetic levitation type) can reduce consumption. -
Do you provide installation and commissioning services?
Yes, we offer on-site supervision by our experienced engineers. We can also provide complete turnkey services including civil works, piping, and electrical installation. Shipping is from Qingdao port. -
Can the system treat wastewater with high salinity or temperature?
Our standard design is for municipal wastewater. For industrial wastewater with high salinity or temperature extremes, we can modify the biological process (e.g., use halophilic bacteria) and material selection. Please provide your water quality parameters. -
What after-sales support do you offer?
We provide a 12-month warranty, remote technical support, and spare parts supply. Our team can also conduct regular maintenance checks under a service agreement.
