Introducing the Automated Low Temp Evaporator 100L Batch Tank 10kW – a cutting-edge solution from Qingdao Conqinphi Environmental Technology Group Co., Ltd., a trusted manufacturer established in 2015 with a 10,000-30,000 m² factory and an annual export value exceeding US$10 million. This evaporator is designed to efficiently reduce liquid waste volume by up to 90-95% under low-temperature conditions, preserving heat-sensitive components while minimizing energy consumption. With CE compliance and a 1-year warranty, it offers a reliable, automated approach for industrial wastewater treatment, cutting operational costs and environmental footprint.
Key Features & Technical Specifications
- Automated Batch Operation – PLC touch screen control with preset programs, allowing unattended processing cycles. Reduces labor costs and human error.
- Low Temperature Evaporation (30-45°C) – Uses heat pump technology to evaporate water at low temperatures, safe for heat-sensitive liquids and reducing scaling and corrosion.
- 100L Batch Tank Capacity – Ideal for small to medium volume treatment, flexible for various wastewater types (coolants, emulsions, rinse water, etc.).
- 10kW Heating Power – Energy-efficient compressor system with COP up to 3.5, achieving low operating cost per liter.
- Stainless Steel 304 Construction – Durable, corrosion-resistant, easy to clean, and compliant with food-grade standards (optional SS316L available).
- CE Compliant Electrical Design – Meets European safety and electromagnetic compatibility standards, ensuring safe operation in industrial environments.
- Compact & Mobile Design – Footprint less than 1.5 m², equipped with casters for easy relocation within the plant.
- Integrated Concentrate Discharge – Automatic or manual discharge of concentrated residue, simplifying waste management.
- Energy Recovery System – Built-in heat exchanger recovers latent heat, further improving efficiency.
| Parameter | Value |
|---|---|
| Model | CLT-100E |
| Max Batch Volume | 100 Liters |
| Evaporation Capacity | ~80-100 L/day (depending on liquid type) |
| Power Consumption | 10 kW (heating) + 1.5 kW (auxiliary) |
| Operating Temperature | 30-45°C (adjustable) |
| Material of Construction | SS304 (SS316L optional) |
| Control System | PLC + 7-inch Touch Screen |
| Dimensions (L×W×H) | 1200 × 800 × 1500 mm |
| Weight | ~450 kg |
| Noise Level | < 65 dB(A) |
Benefits to Your Business
- Reduce Waste Disposal Costs – By concentrating liquid waste, you cut hauling and disposal fees by up to 75%.
- Environmentally Friendly – Low-temperature operation reduces carbon footprint; distilled water can be reused or safely discharged.
- Minimal Maintenance – Self-cleaning cycles and anti-scaling design reduce downtime. The heat pump compressor requires little service.
- Easy to Operate – Intuitive touch screen interface with real-time monitoring of temperature, pressure, and cycle status.
- Customizable for Various Liquids – Suitable for coolants, cutting oils, emulsions, plating solutions, and more. Adjustable parameters for different viscosities.
- Fast Return on Investment – Typical payback period of 6-12 months, depending on current waste disposal costs.
Trust & Quality Assurance
As a Qingdao Conqinphi Environmental Technology Group product, this evaporator benefits from over 9 years of manufacturing experience, a 201-300 person team, and a 10,000-30,000 m² production base. Our CE compliant design ensures that safety and performance meet rigorous international standards. We have served clients across North America, Europe, Southeast Asia, and the Middle East, with annual export value between US$10 million and US$50 million. Each unit comes with a 1-year warranty, and our after-sales support includes remote troubleshooting, spare parts availability, and optional on-site commissioning. We are ISO9001, ISO14001, and OHSAS18001 certified, reflecting our commitment to quality and environmental management.
Don't let wastewater costs drain your profits. Contact us today for a quote or technical consultation. Our team can customize the evaporator to match your specific batch volume and liquid characteristics. With fast shipping from Qingdao port and a proven track record, you can rely on Conqinphi for sustainable, cost-effective waste reduction solutions.
Frequently Asked Questions
Q1: What types of liquids can this evaporator handle?
A: It is designed for aqueous solutions such as metalworking coolants, emulsions, rinsing water, cleaning solutions, cutting fluids, and similar industrial wastewater. It is not recommended for highly flammable or explosive liquids.
Q2: How much electricity does it consume per batch?
A: For a 100L batch, typical energy consumption is about 10-15 kWh, depending on the liquid's boiling point and ambient temperature. The heat pump system recovers energy, making it very efficient.
Q3: Does it require any special installation?
A: No, it is a plug-and-play unit. Connect to a 380V/50Hz (or customized voltage) power supply, and provide a drain connection for the distilled water. Ensure proper ventilation for the heat pump condenser.
Q4: What is the warranty period and coverage?
A: The standard warranty is 1 year, covering manufacturing defects in materials and workmanship. Extended warranty options are available upon request.
Q5: Can the batch tank size be customized?
A: Yes, we offer custom tank sizes from 50L to 500L. Please contact our sales team with your specific requirements.
Q6: How often does the unit need maintenance?
A: Recommended maintenance every 6 months, including cleaning the evaporator chamber, checking refrigerant pressure, and inspecting filters. The PLC system will alert you when maintenance is due.
Q7: Is the distilled water safe to discharge?
A: The distilled water typically contains less than 50 ppm of total dissolved solids, making it suitable for most industrial reuse or safe discharge under local regulations. For sensitive applications, a post-treatment filter can be added.
Q8: What is the lead time for delivery?
A: Standard lead time is 30-45 days after order confirmation. We ship via Qingdao port, and can arrange express delivery for urgent orders at additional cost.
