Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. We are a professional manufacturer established in 2015, with a factory covering 10,000-30,000 square meters and over 200 experienced employees. Our Industrial Low-Temperature Evaporation and Crystallization Equipment with 1000L capacity and automatic feeding represents the latest advancement in sustainable wastewater treatment. Designed to reduce energy consumption while achieving high-purity salt recovery, this equipment helps industries meet zero-discharge regulations and lower operational costs.
This system operates under low-temperature vacuum conditions, significantly reducing thermal degradation and scaling. The 1000L batch capacity is ideal for small to medium-volume applications, while the automatic feeding mechanism ensures continuous operation with minimal manual intervention. Whether you treat chemical, pharmaceutical, or food processing wastewater, our equipment delivers reliable performance.
Key Features & Benefits
- Low-Temperature Evaporation: Operates at 40-70°C, cutting energy use by up to 40% compared to traditional methods.
- Automatic Feeding System: PLC-controlled pumps maintain constant liquid level, reducing labor requirements.
- Crystallization Capability: Recovers reusable salts and water, supporting circular economy goals.
- Corrosion-Resistant Materials: Stainless steel 316L or optional titanium alloy for aggressive chemicals.
- Compact Design: Space-saving footprint suitable for indoor installation.
- Easy Maintenance: CIP (Clean-in-Place) nozzles included for routine cleaning.
Technical Specifications
| Parameter | Value |
|---|---|
| Evaporation Capacity | 1000 L/batch |
| Operating Temperature | 40 – 70°C (adjustable) |
| Vacuum Degree | -0.09 ~ -0.095 MPa |
| Material of Construction | SS304 / SS316L / Duplex SS |
| Power Consumption | Approx. 15 kW (including pumps & vacuum) |
| Control Mode | PLC + Touch Screen (automatic/manual) |
| Feeding Method | Automatic (centrifugal pump + level sensor) |
| Dimensions (L×W×H) | Customizable (standard: 3.0 × 1.8 × 2.5 m) |
| Certifications | ISO 9001, ISO 14000, OHSAS 18001 (company-level); product certification available on request |
Our equipment integrates advanced heat pump technology and efficient mist separators to deliver high-purity distillate (TDS < 30 ppm). The automatic feeding ensures stable operation even with fluctuating inlet concentrations. For customers requiring zero liquid discharge (ZLD), this unit works seamlessly with pre-treatment and post-treatment systems.
Why Choose Qingdao Conqinphi?
- Experienced Manufacturer: Since 2015, we have exported to North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East, with annual export value exceeding US$10 million.
- Global Quality Standards: Our factory holds multiple certifications including ISO 9001, ISO 14000, OHSAS 18001, and more, ensuring consistent product quality.
- Large Production Capacity: 10,000-30,000 m² factory with 200+ skilled workers enables fast delivery and order flexibility.
- Customization Support: We offer tailored solutions for special media, voltage, PLC software, and material upgrades.
- After-Sales Service: 12-month warranty, remote troubleshooting, and on-site installation guidance available.
Our team has completed hundreds of successful projects across various industries. For example, a chemical client in Eastern Europe reduced their wastewater disposal cost by 65% after installing our 1000L evaporator. With our strong R&D capabilities and commitment to innovation, we are confident in providing a reliable solution for your process needs.
Ready to optimize your wastewater treatment? Contact us today for a technical proposal or to schedule a factory visit. We are located in Qingdao, Shandong, China – a major port city for convenient global shipping.
Frequently Asked Questions (FAQ)
-
Q: Can this equipment handle high-salinity brine?
A: Yes, the low-temperature design minimizes scaling, and the crystallizer can recover salts like NaCl, Na₂SO₄, and NH₄Cl. For extremely high TDS, we recommend a pre-concentration step. -
Q: What is the typical energy consumption per batch?
A: For 1000L water evaporation, energy consumption is approximately 60-80 kWh (depending on inlet temperature and concentration). Our heat pump system recovers latent heat, saving over 30% energy versus traditional methods. -
Q: Is the automatic feeding system compatible with viscous liquids?
A: Yes, we can equip a progressive cavity pump or diaphragm pump for high-viscosity fluids. Please specify your medium during inquiry. -
Q: What maintenance is required?
A: Routine cleaning of the evaporator tube bundle every 1-2 months (CIP). The vacuum pump oil should be checked every 500 operational hours. Our manual provides detailed schedules. -
Q: Can the equipment be customized for explosion-proof environments?
A: Absolutely. We offer ATEX/IECEx certified electrical components and reinforced housing upon request. -
Q: What is the delivery time?
A: Standard units: 30-45 working days after deposit. Custom orders may take 50-60 days depending on complexity. -
Q: Do you provide on-site commissioning?
A: Yes, our engineers can travel to your site for start-up and training. Travel expenses and daily allowance apply. -
Q: How do I choose between 304 and 316L stainless steel?
A: For chloride-containing wastewater (e.g., seawater, pickling liquor), we strongly recommend SS316L or higher alloy. For general organic wastewater, SS304 is sufficient.
Note: All technical data is based on standard conditions. Actual performance may vary with specific feedstock. Please provide detailed water analysis for accurate sizing.
