As a leading manufacturer from Qingdao Conqinphi Environmental Technology Group Co., Ltd. (established 2015), we proudly introduce our Air-Cooled Freeze Crystallization System — a robust solution designed for efficient separation and purification in demanding industrial environments. Crafted from premium Stainless Steel 316L, this system offers exceptional corrosion resistance and longevity, while its air-cooled design eliminates the need for complex water cooling infrastructure. With a precise temperature control range from -20°C to -80°C and standard 3 Phase 400V power supply, it is ideal for applications in chemical, pharmaceutical, and wastewater treatment sectors where reliable low-temperature crystallization is critical.
Our freeze crystallization technology leverages controlled freezing to separate dissolved solids from liquids, achieving high purity and minimal energy consumption. The system's 316L stainless steel construction ensures compatibility with corrosive media and harsh chemicals, while the air-cooled condenser simplifies installation and maintenance. The wide temperature range allows precise control over crystal size and morphology, enhancing product quality and process efficiency.
Key Features & Benefits
- Premium Material: Stainless Steel 316L provides superior resistance to pitting, crevice corrosion, and chloride stress corrosion cracking, extending equipment lifespan.
- Air-Cooled Design: Eliminates need for cooling towers or chilled water systems, reducing auxiliary equipment costs and water consumption.
- Broad Temperature Range: From -20°C to -80°C enables processing of a wide variety of solutions with different freezing points, including brine, organic solvents, and waste streams.
- Industrial Power Supply: Standard 3 Phase 400V ensures compatibility with factory electrical systems worldwide (50/60 Hz available upon request).
- Customizable Capacity: Available in various sizes to match your production scale — from lab-scale to industrial-grade units.
- Automation Ready: Optional PLC control with touchscreen interface for recipe management, data logging, and remote monitoring.
Technical Specifications
| Parameter | Value / Range |
|---|---|
| Cooling Method | Air-Cooled (forced convection) |
| Operating Temperature Range | -20°C to -80°C (±1°C stability) |
| Material of Construction (wetted parts) | Stainless Steel 316L |
| Power Supply | 3 Phase, 400V, 50/60 Hz (other voltages optional) |
| Insulation | High-density polyurethane foam (100mm thick) |
| Compressor Type | Semi-hermetic / Scroll (optional) |
| Refrigerant | Environmentally friendly R404A / R508B (customizable) |
| Control Interface | Digital PID controller with safety alarms (PLC optional) |
Applications
- Chemical industry — recovery of valuable byproducts from mother liquor
- Pharmaceutical manufacturing — purification of active ingredients via crystallization
- Wastewater treatment — volume reduction and salt recovery from industrial effluents
- Food & beverage — concentration of juices or extracts through freeze concentration
- Environmental remediation — treatment of contaminated groundwater
Backed by Qingdao Conqinphi Environmental Technology Group Co., Ltd., a manufacturer with over 9 years of experience (since 2015), our factory spans 10,000-30,000 square meters and employs 201-300 skilled professionals. With an annual export value exceeding US$10 million, we serve clients across North America, Europe, Asia, and beyond. Our products adhere to rigorous quality management systems, including ISO9001 and other international certifications (available upon request).
Every system undergoes strict quality checks before shipment from Qingdao Port. We offer customized solutions to match your specific process requirements — whether it's adjusting capacity, adding automation, or integrating with existing lines. Our technical team provides comprehensive support from design to commissioning.
Choose our Air-Cooled Freeze Crystallization System for reliable, efficient, and low-maintenance performance. Contact us today to discuss your application and receive a tailored quotation.
Frequently Asked Questions
- What is the cooling capacity of this system? — Cooling capacity depends on the size and configuration. Standard units range from 5 kW to 50 kW at -40°C. Contact us with your required throughput for a custom specification.
- Can I use this system for corrosive liquids like acids? — Yes, the 316L stainless steel construction is resistant to many acids, chlorides, and harsh chemicals. For specific compatibility, please provide your process fluid details.
- How does the air-cooled condenser perform in high ambient temperatures? — Our system is designed to operate effectively up to 45°C ambient. For hotter climates, optional upgrades (e.g., oversized condenser or additional fans) are available.
- What is the typical delivery time? — Lead time varies from 30 to 60 days depending on customization and order volume. Standard models can be shipped faster.
- Do you provide installation support and training? — Yes, we offer on-site commissioning and training services for operators. Remote support is also available via video call.
- Is the system energy-efficient? — The air-cooled design eliminates water cooling energy, and the variable speed compressor (optional) can significantly reduce power consumption under partial load.
- Can the temperature range be extended beyond -80°C? — For lower temperatures (down to -100°C), a different refrigerant cascade system can be designed. Please inquire for ultra-low temperature requirements.
- What certifications does this equipment meet? — Our systems are manufactured under ISO9001 quality management system. Specific regional certifications (CE, ASME, etc.) can be arranged at extra cost, subject to your local regulations.
