Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. As a leading manufacturer established in 2015, we specialize in advanced environmental solutions. Our Semi-Automatic Low-Temperature Evaporator is engineered to deliver efficient, safe, and reliable concentration and evaporation processes. Crafted from premium 304 stainless steel and featuring an IP65 waterproof enclosure, this 5L per batch unit is designed for demanding industrial environments where precision and durability are paramount.
This evaporator operates at low temperatures, making it ideal for heat-sensitive materials, reducing energy consumption, and minimizing thermal degradation. The semi-automatic control simplifies operation while maintaining high repeatability. Whether you are treating wastewater, concentrating chemical solutions, or processing pharmaceutical intermediates, our evaporator offers a compact yet powerful solution.
Key Features & Benefits
- 304 Stainless Steel Construction: Corrosion-resistant and hygienic, suitable for food, pharmaceutical, and chemical industries. Ensures long service life and easy cleaning.
- IP65 Waterproof Rating: Fully protected against dust and water jets, allowing operation in harsh, wet environments without risk of electrical failure.
- Low-Temperature Evaporation: Operates at temperatures typically below 60°C, preserving sensitive compounds and reducing scaling/fouling. Energy-efficient compared to traditional high-temperature evaporators.
- Semi-Automatic Control: User-friendly interface with preset programs for batch consistency. Reduces operator intervention while maintaining flexibility.
- 5L Batch Capacity: Ideal for small-scale production, pilot studies, or laboratory use. Compact footprint saves valuable floor space.
- Customizable Options: Available with PLC touch screen, data logging, and various heating methods (electric, steam, or hot water) upon request.
Technical Specifications
| Parameter | Details |
|---|---|
| Material | 304 Stainless Steel (SS304) |
| Capacity per Batch | 5 Liters |
| Enclosure Protection | IP65 (Waterproof & Dustproof) |
| Operation Mode | Semi-Automatic |
| Temperature Range | 30°C – 80°C (Low-Temperature customizable) |
| Heating Method | Electric / Steam / Hot Water (optional) |
| Power Supply | 220V / 50Hz, single phase (other voltages available) |
| Control System | Basic PLC + HMI (optional upgrade) |
| Dimensions (approx.) | 600mm × 500mm × 1200mm (customizable) |
| Weight | Approx. 45 kg |
Why Choose Our Semi-Automatic Low-Temperature Evaporator?
Our evaporator stands out due to its robust construction, precise control, and adaptability. The 304 stainless steel body ensures compatibility with a wide range of chemicals, while the IP65 rating guarantees reliable performance even in humid or wash-down environments. Low-temperature operation not only saves energy but also protects the quality of your product, making it an excellent choice for industries such as:
- Wastewater Treatment: Concentrate industrial effluents, reduce disposal costs, and recover valuable by-products.
- Chemical Processing: Evaporate solvents, concentrate solutions, or prepare high-purity intermediates.
- Pharmaceutical & Biotech: Handle heat-sensitive APIs, extracts, and fermentation broths with minimal degradation.
- Food & Beverage: Concentrate juices, dairy products, and flavorings while preserving natural taste.
The semi-automatic operation simplifies training and reduces human error, while the 5L batch size allows for easy scale-up studies or small-scale production. Each unit undergoes rigorous testing before shipment to ensure compliance with international quality standards.
Frequently Asked Questions (FAQ)
-
Q: What is the minimum and maximum temperature I can set?
A: The standard temperature range is 30°C to 80°C. For special low-temperature requirements (down to 20°C), we can customize the cooling system upon request. -
Q: Can I use this evaporator for corrosive liquids?
A: Yes, the 304 stainless steel construction provides good resistance to many corrosive media. For highly corrosive chemicals (e.g., strong acids), we recommend consulting our engineers for material upgrades (e.g., 316L or Hastelloy). -
Q: Is the IP65 rating sufficient for outdoor use?
A: IP65 means the enclosure is dust-tight and protected against water jets from any direction. It is suitable for outdoor use in rain or wash-down conditions, but not for submersion. For continuous outdoor exposure, we suggest adding a sun shield. -
Q: How long does one batch cycle take?
A: Cycle time depends on the liquid properties, desired concentration, and heating method. Typically, a 5L batch of water-based solution takes 2–4 hours. We can provide a detailed estimate based on your specific feed. -
Q: Do you provide installation and training support?
A: Yes, we offer remote or on-site commissioning and training for first-time users. Our technical team is available via email, phone, or video call to assist with setup and troubleshooting. -
Q: What is the warranty period?
A: Our standard warranty is 12 months from the date of shipment, covering manufacturing defects in materials and workmanship. Extended warranty options are available. -
Q: Can I get a custom capacity (e.g., 10L or 20L)?
A: Absolutely. We design and manufacture custom sizes based on your requirements. Please contact our sales team with your specifications. -
Q: How do I clean the evaporator between batches?
A: The 304 SS surface is easy to clean. We recommend a CIP (Clean-in-Place) system or manual rinsing with appropriate solvents. Detailed cleaning procedures are provided in the user manual.
Trust & Reliability
Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been a trusted name in environmental equipment since 2015. With a factory spanning 10,000–30,000 square meters and a dedicated team of 201–300 employees, we have the capacity and expertise to deliver high-quality solutions. Our annual export value exceeds US$10 million, serving markets across North America, South America, Europe, Asia, Africa, and Oceania. We are proud to hold multiple management system certifications including ISO9001, ISO14000, OHSAS18001, and HACCP, reflecting our commitment to quality, environment, and safety. Every evaporator is manufactured under strict quality control procedures and tested before shipment from the port of Qingdao.
We invite you to experience the performance and reliability of our Semi-Automatic Low-Temperature Evaporator. Contact us today to discuss your specific application, request a quotation, or arrange a live demonstration. Let us help you optimize your evaporation process with a solution that is built to last.
Qingdao Conqinphi Environmental Technology Group Co., Ltd. – Your Partner in Sustainable Environmental Solutions.
