Qingdao Conqinphi Environmental Technology Group Co., Ltd. is a professional manufacturer with over 9 years of experience in designing and producing advanced MVR Cooling Crystallization Systems. Our system is specifically engineered for ammonium chloride crystallization in fertilizer production lines, offering high efficiency, low energy consumption, and reliable performance. With a factory size of 10,000–30,000 square meters and a dedicated R&D team of 201–300 employees, we deliver tailored solutions that meet the rigorous demands of the global fertilizer industry.
This MVR (Mechanical Vapor Recompression) Cooling Crystallization System utilizes mechanical vapor compression to recycle latent heat, drastically reducing energy usage compared to traditional evaporation and cooling processes. It is ideal for recovering high-purity ammonium chloride crystals from mother liquor, improving overall production yield and reducing waste. Our system is designed for continuous operation, easy maintenance, and seamless integration into existing fertilizer production lines.
Below we outline the key features, technical specifications, and advantages of our MVR Cooling Crystallization System for ammonium chloride.
Key Features
- Energy Efficient: MVR technology reuses vapor latent heat, achieving energy savings of up to 60%–80% compared to multi-effect evaporation.
- High Crystal Purity: Controlled cooling curve and precise temperature management produce uniform, large crystals of ammonium chloride with minimal impurities.
- Fully Automated Control: PLC-based system with HMI touchscreen enables real-time monitoring of temperature, pressure, flow rate, and crystallization parameters.
- Corrosion-Resistant Materials: Constructed from high-grade stainless steel (304L/316L) or custom alloys to withstand the corrosive nature of ammonium chloride solutions.
- Compact Modular Design: Skid-mounted or modular configuration saves floor space and simplifies installation and scaling.
- Low Operating Costs: Reduced steam consumption, minimal chemical additives, and low maintenance requirements lower total cost of ownership.
- Flexible Capacity: Evaporation capacity can be customized from 500 kg/h to 5000 kg/h or more, based on client production needs.
- Environmental Compliance: Closed-loop system minimizes waste discharge and meets stringent environmental standards.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Range | Customizable (e.g., MVR-AC-500 to MVR-AC-5000) |
| Evaporation Capacity | 500 – 5000 kg water/h (other capacities available upon request) |
| Compressor Type | Centrifugal or Roots blower, oil-free option available |
| Operating Temperature | 50–90°C (crystallization temperature can be adjusted) |
| Power Consumption | 30–80 kWh per ton of evaporated water (depending on conditions) |
| Material of Construction | SS304, SS316L, or duplex stainless steel; titanium optional |
| Control System | PLC (Siemens or Mitsubishi) with remote monitoring capability |
| Dimensions (L×W×H) | Skid-mounted: e.g., 6m × 2.5m × 3m (customizable) |
Advantages for Your Fertilizer Production
- Increased Yield: High recovery rate of ammonium chloride crystals from process streams, reducing raw material losses.
- Superior Crystal Quality: Uniform crystal size distribution improves downstream handling, drying, and packaging efficiency.
- Energy Cost Reduction: MVR technology cuts steam consumption by up to 80%, significantly lowering operational expenses.
- Simplified Operation: Fully automated system requires minimal operator intervention; remote diagnostics available.
- Scalability: Modular design allows easy expansion as production demands grow.
- Durability: Robust construction ensures long service life even in harsh chemical environments.
Why Choose Qingdao Conqinphi?
With an annual export value of US$10 Million – US$50 Million and shipments to over 15 countries including North America, Europe, Southeast Asia, and Africa, our company has established a strong reputation for delivering reliable environmental and crystallization solutions. Our factory spanning 10,000–30,000 square meters is equipped with advanced fabrication and testing facilities. We hold multiple company-level certifications including ISO9001, ISO14001, OHSAS18001, HACCP, TL900, SA8000, and others, reflecting our commitment to quality, safety, and social responsibility. Our team of 201–300 employees includes experienced engineers who provide full technical support from design to commissioning and after-sales service. Choose Conqinphi for a partner that understands your fertilizer production challenges and delivers effective, economical crystallization solutions.
Frequently Asked Questions (FAQ)
Q1: What is MVR technology and how does it benefit ammonium chloride crystallization?
A: MVR stands for Mechanical Vapor Recompression. It compresses the vapor produced during evaporation, raising its temperature and pressure so it can be reused as a heating medium. This dramatically reduces energy consumption (by 60–80%) compared to traditional evaporators, making it ideal for energy-intensive crystallization of ammonium chloride in fertilizer plants.
Q2: Can your system handle high-concentration ammonium chloride solutions?
A: Yes. Our MVR cooling crystallization system is designed to process highly concentrated ammonium chloride mother liquor (up to saturation). The crystallization temperature and cooling rate are precisely controlled to prevent scaling and ensure stable operation. We recommend providing a detailed solution analysis for an optimized design.
Q3: What is the typical crystal size distribution you can achieve?
A: The system can produce ammonium chloride crystals with a mean particle size ranging from 200 to 800 microns, depending on your specific requirements. The cooling profile and residence time can be adjusted to achieve a narrow size distribution for better downstream handling.
Q4: How long does it take to install and commission the system?
A: For a standard skid-mounted unit, installation typically takes 2–4 weeks on-site, followed by 1–2 weeks of commissioning and training. The exact timeline depends on site conditions and customization. Our team provides on-site supervision to ensure smooth startup.
Q5: What maintenance is required for the MVR compressor?
A: The compressor requires periodic inspection of seals, bearings, and oil levels (if oil-lubricated). Oil-free compressors have lower maintenance. We recommend a preventive maintenance schedule every 6 months, which can be supported by our remote monitoring system. Spare parts are readily available.
Q6: Can you customize the system for existing fertilizer production lines?
A: Absolutely. We offer full customization in terms of capacity, materials, instrumentation, and footprint. Our engineers will visit your site or work with your technical drawings to design a seamless integration. Retrofitting existing evaporation equipment is also possible.
Q7: What safety features are included?
A: The system includes multiple safety interlocks such as high-pressure shutdown, temperature alarms, emergency stop, and relief valves. The PLC monitors all critical parameters and alerts operators in case of deviations. Our design complies with international safety standards.
Q8: Do you provide after-sales technical support?
A: Yes, we offer comprehensive after-sales support including remote troubleshooting, on-site service, and spare parts supply. Our team is available 24/7 for urgent issues. We also provide operator training and process optimization services to maximize your production efficiency.
