Product Introduction
The TRX Series Tri-Shield Coaxial Cables (including TRX-178, TRX-179, TRX-316, TRX-180, TRX-142, TRX-400) are premium-grade RF interconnect solutions engineered for critical applications requiring exceptional signal integrity. The triple-shielded design provides superior protection against electromagnetic interference (EMI), ensuring low noise and stable performance in demanding environments.
Structure:
· Inner Conductor: Silver-plated Copper Alloy
· Insulation: PTFE (Polytetrafluoroethylene)
· Inner Shield: Silver-plated Copper Braid
· Inner Jacket: FEP (Fluorinated Ethylene Propylene)
· Outer Shield: Silver-plated Copper Braid
· Outer Jacket: FEP (Fluorinated Ethylene Propylene)
Core Features
· Precision PTFE Insulation: Delivers consistent electrical performance, low loss, and high-temperature resistance.
· High-Density Triple Shielding: Multi-layer braided shields achieve excellent shielding effectiveness, minimizing signal leakage and external interference.
· Low Noise & High Immunity: Advanced construction resists signal interference, reducing noise and ensuring clean signal transmission.
· Enhanced Signal Integrity: Optimized design improves data transmission accuracy and long-term stability.
Model |
Inner Conductor (Strand/mm) |
Insulation (mm) |
Inner Shield (mm) |
Inner Jacket (mm) |
Outer Shield (mm) |
Outer Jacket (mm) |
TRX-178 |
7/0.10 |
0.86 |
1.26 |
1.88 |
2.29 |
2.95 |
TRX-179 |
7/0.10 |
1.60 |
2.00 |
2.51 |
2.92 |
3.58 |
TRX-316 |
7/0.17 |
1.52 |
1.93 |
2.44 |
2.85 |
3.56 |
TRX-180 |
7/0.102 |
2.59 |
3.00 |
3.51 |
3.91 |
4.57 |
TRX-142 |
1/0.94 |
3.00 |
3.50 |
4.22 |
4.72 |
5.46 |
TRX-400 |
19/0.203 |
3.00 |
3.45 |
4.22 |
4.72 |
5.46 |
Typical Applications
These high-performance tri-shield cables are ideal for:
· RF & Microwave Systems: Transmitters, receivers, and antenna feeds
· Test & Measurement: High-frequency test benches and signal analyzers
· Aerospace & Defense: Avionics, radar systems, and military communications
· Telecommunications: Base stations, broadcast equipment, and high-speed data links
· Medical Equipment: MRI, RF surgical tools, and diagnostic instruments
