Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015 with a factory area spanning 10,000–30,000 square meters and a dedicated team of 201–300 employees, presents the Cross Flow MVR Evaporator 316L SS Semi-Auto 220V 3Phase 1500L/h CIP Design. This advanced evaporator is engineered to deliver high-efficiency concentration and recovery across demanding industrial sectors, including wastewater treatment, chemical processing, and food manufacturing. By combining cross-flow technology with mechanical vapor recompression (MVR), our equipment significantly reduces energy consumption while maintaining consistent output of 1500 liters per hour. The semi-automatic operation, 316L stainless steel construction, and integrated CIP design ensure durability, ease of maintenance, and compliance with rigorous hygiene standards.
Product Highlights & Technical Specifications
- Cross Flow Configuration – Optimizes heat transfer and prevents fouling, extending operational life and reducing downtime.
- MVR (Mechanical Vapor Recompression) – Cuts steam consumption by up to 70% compared to traditional evaporators, lowering operating costs.
- 316L Stainless Steel Construction – Superior corrosion resistance for aggressive chemicals and high-temperature processes.
- Semi-Automatic Control – PLC-based panel with user-friendly interface; manual override available for flexibility.
- 220V 3Phase Power Supply – Compatible with common industrial electrical grids.
- 1500 L/h Capacity – Ideal for medium-scale production lines or pilot projects.
- CIP (Clean-in-Place) Design – Enables automated cleaning cycles without disassembly, maintaining hygiene and reducing labor.
- Compact Footprint – Space-saving layout for easy integration into existing facilities.
| Parameter | Value |
|---|---|
| Model | CF-MVR-1500 (customizable) |
| Material | 316L Stainless Steel |
| Evaporation Capacity | 1500 L/h |
| Power Supply | 220V, 3 Phase, 50/60 Hz |
| Automation | Semi-Automatic (PLC + manual backup) |
| Cleaning Method | CIP integrated |
| Operating Pressure (Evaporator) | -0.02 ~ 0.02 MPa (optional vacuum) |
| Temperature Range | 60–120°C (adjustable) |
| Dimensions (L×W×H) | Approx. 3000×1800×2500 mm (customizable) |
| Weight | ~2500 kg |
Key Advantages for Your Process
- Energy Efficiency: The MVR system recycles vapor heat, achieving a specific energy consumption as low as 20–30 kWh per ton of water evaporated, cutting utility bills significantly.
- Product Quality: Gentle cross-flow evaporation minimizes thermal degradation, preserving sensitive compounds in food and pharmaceutical applications.
- Reduced Maintenance: 316L SS resists pitting and crevice corrosion; CIP design eliminates manual cleaning inside the vessel.
- Scalability: Multiple units can be paralleled for higher throughput; customization options allow adaptation to specific feed characteristics.
- Environmental Compliance: Closed-loop operation reduces emissions and waste; concentrated byproducts can be further processed or disposed of efficiently.
Trust & Reliability from Qingdao Conqinphi
As a manufacturer with an annual export value of US$10–50 million and serving markets across North America, South America, Europe, Asia, Africa, and Oceania, Qingdao Conqinphi has built a reputation for delivering robust environmental equipment. Our factory holds multiple management system certifications — including ISO9001, ISO14000, OHSAS18001, TL900, and SA8000 — ensuring that every product meets stringent quality, safety, and social responsibility standards. With over 200 skilled employees and a dedicated R&D team, we provide comprehensive after-sales support, including installation guidance, spare parts supply, and remote troubleshooting. Choose the Cross Flow MVR Evaporator to reduce your operating costs while maintaining high throughput and reliability. Contact us today for a customized solution tailored to your specific process requirements.
Frequently Asked Questions (FAQ)
1. What is the main advantage of cross flow design in MVR evaporators?
Cross flow configuration minimizes fouling and scaling by maintaining high velocity across the heat transfer surface, which improves heat transfer efficiency and extends cleaning intervals.
2. Can this evaporator handle highly viscous or particulate-laden liquids?
Yes, the cross flow design is well-suited for liquids with moderate viscosity or suspended solids. For extreme cases, we can customize the geometry and pre-filtration to ensure stable operation.
3. How does the CIP system work?
The CIP system circulates cleaning solution (e.g., hot water, caustic soda) through internal piping and chambers automatically. The program can be set via the PLC, and the process takes 30–60 minutes depending on fouling level.
4. What is the typical payback period for energy savings from MVR?
Under normal operating conditions (e.g., concentration of saline wastewater), energy savings can reduce operating costs by 40–60%, leading to a payback period of 12–24 months. Exact figures depend on local electricity prices and running hours.
5. Do you provide training for semi-automatic operation?
Yes, we offer on-site or remote training for operators, covering start-up, shutdown, parameter adjustment, and basic troubleshooting. Detailed manuals are included.
6. What materials are compatible with 316L SS?
316L SS is resistant to chlorides, acids, and alkalis within moderate concentrations. For highly corrosive media (e.g., HCl, HF), we recommend alternative materials like duplex stainless steel or titanium, which can be offered as options.
7. Can the voltage and phase be changed for different regions?
Yes, we can configure the compressor and electrical system for 380V, 415V, or 440V at 50Hz or 60Hz. Please specify your local power supply upon ordering.
8. What is the warranty period and after-sales support?
We provide a standard 12-month warranty from the date of commissioning, with extended options available. Our after-sales team responds within 24 hours for remote support and can dispatch engineers for on-site service if needed.
