Introducing the Compact Low-temperature MVR Evaporator – 10kW Power, PLC Automatic Operation for Industrial Use
As a leading manufacturer from Qingdao Conqinphi Environmental Technology Group Co., Ltd., we are proud to present our latest innovation in energy-efficient evaporation technology. This compact MVR (Mechanical Vapor Recompression) evaporator is specifically designed for industrial wastewater treatment and liquid concentration, offering low-temperature operation to preserve heat-sensitive materials. With 10kW power input and full PLC automatic control, our system reduces energy consumption by up to 80% compared to traditional evaporators, making it an ideal solution for factories seeking both environmental compliance and cost savings. Backed by our 10-year manufacturing expertise and a 10,000-30,000 m² smart factory, every unit is engineered for reliability and long service life.
Key Features & Technical Specifications
- Low-temperature Evaporation: Operates at 30-90°C, minimizing fouling and scaling while preserving volatile substances.
- High Energy Efficiency: Only 10kW electrical power per ton of water evaporated (vs. 50-80kW in conventional evaporators).
- PLC Automatic Control: Touchscreen HMI with one-touch start, real-time monitoring, and remote alarm via optional IoT module.
- Compact Footprint: Occupies less than 2 m² area, suitable for space-constrained workshops.
- Modular Construction: Skid-mounted design for quick installation and easy maintenance.
- Wide Application: Suitable for industrial wastewater, brine treatment, chemical concentration, and food processing.
- Durable Materials: Standard 304 stainless steel, with 316L or Duplex options for corrosive media.
Technical Parameters (Typical Model)
| Parameter | Value |
|---|---|
| Evaporation Capacity | 200-500 L/h (adjustable) |
| Operating Temperature | 30-90°C |
| Power Consumption | 10 kW (compressor + pumps) |
| Control System | PLC + 7-inch touchscreen |
| Voltage / Frequency | 380V/50Hz (or customized) |
| Material | Stainless steel 304 (316L optional) |
| Dimensions (L×W×H) | 1.8m × 1.2m × 2.0m |
| Weight | ~800 kg |
Advantages for Your Business
- Lower Operating Costs: With a specific energy consumption of only 10 kWh per ton of evaporated water, you can reduce electricity bills by over 60% compared to thermal evaporation.
- Minimal Maintenance: The low-temperature design prevents scaling and corrosion, extending the lifespan of the compressor and heat exchanger.
- Fully Automated: The PLC system automatically adjusts parameters based on inlet conditions. It includes self-diagnosis and safety alarms for pressure, temperature, and level.
- Environmental Compliance: Zero liquid discharge (ZLD) capability helps you meet increasingly stringent wastewater regulations worldwide.
- Flexible Customization: We offer optional pre-treatment modules, CIP cleaning systems, and remote monitoring via cloud.
Why Choose Qingdao Conqinphi?
Since 2015, our factory has grown to over 10,000 square meters with 201-300 skilled employees. We export to more than 20 countries across North America, Europe, Asia, and Africa, with an annual export value of US$10-50 million. Our quality management system is certified under ISO9001, ISO14000, and OHSAS18001, and we also hold numerous industry-specific certifications (e.g., HACCP, SA8000, TL900). Every MVR evaporator undergoes rigorous factory acceptance testing before shipment from Qingdao port. We provide 24/7 technical support, on-site commissioning services, and a standard 12-month warranty. Contact us today to discuss how our compact low-temperature MVR evaporator can transform your industrial wastewater treatment into a profitable sustainability project.
Frequently Asked Questions (FAQ)
Q1: What is the maximum evaporation capacity of the 10kW model?
A1: The standard capacity ranges from 200 to 500 liters per hour, depending on the feed concentration and temperature. Higher capacities can be achieved with multiple units or a customized design.
Q2: Can this evaporator handle corrosive liquids?
A2: Yes, we offer variants with 316L stainless steel or duplex materials for acidic or chloride-rich wastewater. Please provide a detailed analysis of your feed for the best recommendation.
Q3: What is the typical payback period?
A3: Based on an electricity cost of $0.10/kWh and a capacity of 300 L/h, the savings can offset the equipment cost within 1-2 years. Actual payback depends on local energy prices and operating hours.
Q4: Is the PLC system user-friendly for operators?
A4: Absolutely. The touchscreen interface displays all parameters in real time, and the machine can run in automatic mode with minimal intervention. We also provide training at your site.
Q5: Do you offer remote monitoring?
A5: Yes, an optional IoT module allows remote access via mobile app or web dashboard, enabling you to receive alerts and adjust settings from anywhere.
Q6: What is the warranty period?
A6: We provide a 12-month warranty from the date of commissioning, covering manufacturing defects. Extended warranty and service contracts are available upon request.
Q7: How long does delivery take?
A7: Standard delivery is 30-45 days after order confirmation. For urgent projects, we can expedite production after reviewing your schedule.
Q8: Can I test the evaporator with my own wastewater?
A8: Yes, we offer a pilot testing service at our facility or on-site using a rental unit. Contact our sales team to arrange a trial.
