Help CenterTube-type Skid-mounted MVR Evaporator With IP55 Electrical Cabinet, Programmable Logic Controller, 380V 50Hz
Product Spotlights
Related Products
-
Tube-type Skid-mounted MVR Evaporator With 1-year Warranty, On-site Installation Guidance and Operator Training IncludedUS$ 27500 - 639000MOQ: 5 Combos -
Tube-type Skid-mounted MVR Evaporator With Mill Test Report, Factory Tested, Free Technical Support for First YearUS$ 27500 - 639000MOQ: 5 Combos
-
Tube-type Skid-mounted MVR Evaporator With 95% Heat Recovery Efficiency, Self-cleaning CIP System, 10 Tons/dayUS$ 27500 - 639000MOQ: 5 Combos
-
316L Stainless Steel Tube-type Skid-mounted MVR Evaporator With Energy-saving Compressor, 30kW Power, Automatic OperationUS$ 27500 - 639000MOQ: 5 Combos
-
Tube-type Skid-mounted MVR Evaporator for Pharmaceutical Wastewater Treatment, 304 Stainless Steel, Automatic ConcentrationUS$ 27500 - 639000MOQ: 5 Combos
As a leading manufacturer from Qingdao Conqinphi Environmental Technology Group Co., Ltd. (established in 2015 with a 10,000-30,000 sqm factory and over 200 skilled employees), we proudly present our Tube-type Skid-mounted MVR Evaporator. This equipment integrates an IP55-rated electrical cabinet and a programmable logic controller (PLC) for precise automation, operating at 380V 50Hz. It is engineered to deliver high-efficiency evaporation for industrial wastewater treatment, reducing energy consumption by up to 70% compared to traditional evaporators. Our year of expertise and global export experience (US$10-50 million annually) ensure a reliable, cost-effective solution tailored to your needs.
Key Features and Technical Specifications
- Tube-type Heat Exchanger: Utilizes a robust tube bundle design for efficient heat transfer and easy cleaning. Suitable for scaling or fouling liquids.
- Skid-mounted Construction: All components (evaporator, condenser, compressor, control panel) are pre-assembled on a single steel skid. This reduces installation time and footprint, making it ideal for modular projects.
- IP55 Electrical Cabinet: Protects sensitive electronics from dust and water jets, ensuring reliable operation in harsh industrial environments.
- Programmable Logic Controller (PLC): Fully automatic operation with touchscreen HMI. Monitors temperature, pressure, flow, and liquid level. Supports remote monitoring and data logging.
- Power Supply: 380V 50Hz (other voltage/frequency options are available upon request).
- High Efficiency: Mechanical vapor recompression (MVR) technology recycles latent heat, achieving a specific energy consumption as low as 20-40 kWh per ton of evaporated water.
- Customizable Capacity: Evaporation rates from 1 to 50 tons per day, adaptable to different feed concentrations.
| Parameter | Value |
| Evaporation Capacity | 1-50 tons/day (custom) |
| Operating Temperature | 40-100°C |
| Compressor Power | 7.5-250 kW |
| Dimensions (L×W×H) | Varies by capacity; skid-mounted for easy transport |
| Material of Construction | SS304, SS316L, or other alloys |
| Control System | Siemens/Allen-Bradley PLC, 7-inch touchscreen |
Comprehensive Benefits: The tube-type design minimizes fouling and allows for easy maintenance. The skid-mounted configuration drastically cuts site preparation and piping work. With the IP55 cabinet, the system can be installed outdoors without additional shelters. The PLC enables unattended operation, reducing labor costs and human error. MVR technology significantly lowers operating expenses—for every 1 kWh of electrical energy, 4-8 kWh of thermal energy is recovered.
Trust and Credibility
Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been a reliable manufacturer since 2015, with factory size of 10,000-30,000 square meters and a team of 200+ professionals. We hold multiple certifications including ISO9001, ISO14000, OHSAS18001, and are compliant with international standards. Our annual export value reaches US$10-50 million, serving markets across North America, Europe, Southeast Asia, Africa, and more. Every MVR evaporator undergoes rigorous quality testing before shipment from Qingdao port. We offer after-sales support, spare parts, and on-site commissioning services. Contact us today for a customized proposal—we are committed to providing sustainable and efficient evaporation solutions for your business.
Frequently Asked Questions (FAQ)
- What types of wastewater can this evaporator handle? It is suitable for high-salinity brine, industrial effluent, landfill leachate, chemical process streams, and dairy/ food industry wastewater. The tube-type design is resistant to scaling.
- What is the typical energy consumption? Energy consumption is approximately 20-40 kWh per ton of water evaporated, depending on feed concentration and temperature. This is 60-80% less than conventional evaporators.
- Can you customize the voltage or frequency? Yes, we can configure the system for 380V 50Hz (as standard) or other voltages (e.g., 440V 60Hz) and frequencies. Please specify your requirements.
- How long does installation take? Since it is skid-mounted, installation typically requires 3-5 days for piping and electrical connections. Our technical team can assist remotely or on-site.
- What maintenance is required? Regular inspection of the tube bundle (cleaning if scaling), compressor oil check, and PLC system updates. A maintenance manual is provided.
- Do you provide certifications? Yes, we can provide ISO9001, ISO14000, OHSAS18001, and other certifications as requested. The product is CE compliant (optional).
- What is the delivery time? Lead time is typically 30-45 days for standard capacities. Customized orders may take 50-60 days.
- Can the PLC connect to a SCADA system? Yes, the PLC supports Modbus TCP/IP, Profibus, or Ethernet/IP protocols for integration with higher-level control systems.
